Bison SC04WKU Instruction Manual

—— Instruction Manual ——
SC04WKU
Universal Portable Soccer Goal Wheel Kit
P A R T S L I S T
Item Qty Description
A 4 Wheel
B Wheel Lever
4
C 4 Lever Bracket
D 4 Safety Channel
E 4 Hand Knob
F 4 Wing Nut
G 4 5/8" X 3" Carriage Bolt
♦
Inspect all contents prior to installation. Report any missing parts to dealer immediately.
♦
Read all instructions before proceeding.
1. Determine the size of your back stay material, these wheel kits will work on 1.66" and 2" round or 2"
square. Select to appropriate Clamp Assemblies (P, Q or R).
2. Install Lever Bracket (C) and Safety Channel (D) onto the back stay with The Clamp Assembly selected
from instruction #1. This wheel assembly works the best when you install as close to the vertical
uprights as possible. Make sure the vertical leg of the Lever Bracket (C) is positioned to the outside of
the goal and level. See illustration on page #2.
3. Attach Wheel (A) to Wheel Lever (B) in the larger of the two square holes with the 5/8" X 3" Carriage
Bolt (G) and 5/8" Lock Nut (I). One side of the Wheel (A) has a hub that allows clearance for the Wheel
Lever (B) and you want the Lock Nut (I) on the outside of the wheel. Keep in mind that you will need a
right and left assembly, it is best to lay all of the parts out next to each upright, orient prior to assembly.
Once you have both wheels assembled onto the wheel levers you can now attach the wheel lever to the
Lever Bracket (C) with the 1/2" X 1" Carriage Bolt (H) and the 1/2 Lock Nut (O). Make sure the
Carriage Bolt is firmly seated in the square hole on the Lever. Tighten 1/2" hardware and back off 1/2
turn until the Wheel Lever (B) can rotate freely. See illustration on page #2
4. Use the Hand Knob (E) and Wing Nut (F) to lock Wheel (A) in position for transport. Once goal is
positioned for play remove Hand Knob (E) and Wing Nut (F). Rotate Wheel up and back until resting
on the playing surface away from the front of the goal. Replace Hand Knob (E) and Wing Nut (F) into
the Wheel Lever (B) for storage. See illustration on page #2.
Date: 11/02/06 Rev: I.R. B.A. N.J.C.
Item Qty Description
H 4 1/2" X 1 Carriage Bolt
I 4 5/8" Lock Nut
O 4 1/2" Lock Nut
P 12 1.66" Round Clamp Assembly
Q 12 2" Round Clamp Assembly
R 12 2" Square Clamp Assembly
File: \drive.f\pub\sc04wkinst
1
Customer Service
(800) 247-7668
Ref#: 860127
