ROUGH-IN DRAWINGS RD113
GEM3XN - Dispenser
5.28 in
[13.4 cm]
13.65 in
[34.7 cm]
5.02 in
0.25 in
12.79 in
[12.8 cm]
[0.6 cm] [32.5 cm]
17.61 in
[44.7 cm]
GEM3XN, ROUGH-IN DRAWING 040720NC
