ROUGH-IN DRAWINGS
GEM3XIFT - Satellite Server
9.17 in
[23.3 cm]
4.68 in
[11.9 cm]
11.09 in
[28.2 cm]
GEM3XIFT, ROUGH-IN DRAWING
9.04 in
[23.0 cm]
11.42 in
[29.0 cm]
0.24 in
[0.6 cm]
RD72
082118A
