PANA-C84103
500 lb
MAX
(227 kg)
ENG
1
2015-06-30
#:126-9068-2
(2018-06-15)

Advertisement

loading
Need help?

Need help?

Do you have a question about the PANA-C84103 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for peerless-AV PANA-C84103

Summary of Contents for peerless-AV PANA-C84103

  • Page 1 PANA-C84103 500 lb (227 kg) 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 2 WARNING ENG - Do not begin to install product until you have read and understood the instructions and warnings contained in this user guide. Always use an assistant or mechanical lifting equipment to safely lift and position equipment. This product must be installed onto flat, hard, level surface to prevent tipping. Use with heavier displays may result in instability causing tip over resulting in death or serious injury.
  • Page 3 This page was intentionally left blank 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 4 Parts (Before beginning, make sure you have all parts shown below). Parts List Description Part # caster, 5" swivel 600-0026 caster support 145-T1799 cover 145-T1809 base leg 145-T1767 horizontal leg support 145-T1785 base support tube 145-T1812 base support 560-T1261 vertical leg support 146-T1131 adaptor bracket left 146-T1298...
  • Page 5 L ( 1 ) M ( 1 ) X ( 2 ) computer shelf rail vertical support weldment bracket K ( 1 ) computer cover O ( 4 ) locking tab W ( 2 ) lock tab AA ( 2 ) M5 x 30mm R ( 24 ) P ( 84 )

  • Page 6: Side View

    P (4) Do not fully tighten hardware Q (2) P (2) SIDE VIEW 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 7 Q (4) Q (4) P (4) Q (4) P (4) 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 8 FLUSH TIGHTEN EDGES CONNECTING HARDWARE Casters must be flush to end of horizontal leg support. SIDE VIEW Q(4) Do not fully tighten hardware P(4) 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 9 TIGHTEN CONNECTING HARDWARE LOCK WHEELS TIGHTEN CONNECTING HARDWARE 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 10 TIGHTEN CONNECTING HARDWARE TIGHTEN CONNECTING HARDWARE 38.0" 96.5cm 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 11 1/8" 1/8" (3mm) (3mm) Q (4) P (6) X (2) 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 12 Tighten. Tighten. Cross support must center on vertical leg supports. 2015-06-30 #:126-9068-2 (2018-06-15)

  • Page 13: Top View

    O (4) N (4) T (4) TIGHTEN CONNECTING HARDWARE OPTIONAL: Unlock wheels to move cart to desired location; Lock wheels before hanging screens. TOP VIEW LOCK WHEELS 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 14 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 15 14-1 W (2) S (2) 14-2 Z (2) AA (2) 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 16 15-1 15-2 Secure screw in "locked" position. Unlocked Locked Z (2) 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 17 1/8" (3mm) S (2) TIGHTEN CONNECTING HARDWARE 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 18 Repeat for each cover. R (24) C (6) 2015-06-30 #:126-9068-2 (2018-06-15)
  • Page 19 Route cables through cord brackets. 2015-06-30 #:126-9068-2 (2018-06-15)

  • Page 20: Limited Five-Year Warranty

    (from date of the original installation of the product). At its option, Peerless-AV will repair or replace, or refund the purchase price of, any product which fails to conform with this warranty.
