FORM 100.50-SU8

ISSUE DATE:1/28/2016

The Series 100 unit is a large tonnage rooftop unit, with

sizes ranging from 50-150 tons. It can be configured to

run as a Constant Volume unit, a Multizone Variable

Air Volume (VAV) unit, Single Zone VAV, or as a Flex-

Sys (underfloor air) unit. There are many different op-

tions that can be added to the machine, which will add

to its complexity.

This start up guide indicates control sequences to pro-

vide proper unit operation. This guide does not include

installation information. Please refer to the proper In-

stallation, Operation, and Maintenance (IOM) manual

for this information.

JOHNSON CONTROLS

SECTION 1 - INTRODUCTION

In addition, any system alarms indicated by the User

Interface should be diagnosed as referenced in the ap-

propriate IOM. You can refer to the Fault Description

Table located in the Service section of the IOM.

• 50-65 ton units, Mod F: Form 100.50-NOM5

(1115)

• 70-105 ton units, Mod F: Form 100.50-NOM9

(1115)

• 120-130 ton units, Mod F: Form 100.50-NOM10

(1115)

• 120-150 ton units, Mod G: Form 100.50-NOM11

(1115)
