Goodmans 355881 User Manual

Compact dvd player
Hide thumbs Also See for 355881:
Table of Contents

Advertisement

Quick Links

COMPACT DVD PLAYER
USER MANUAL
MODEL: 355881

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 355881 and is the answer not in the manual?

Questions and answers

Related Manuals for Goodmans 355881

Summary of Contents for Goodmans 355881

  • Page 1 COMPACT DVD PLAYER USER MANUAL MODEL: 355881...

  • Page 2: Table Of Contents

    1 Welcome 2 Your DVD Player In the box Front View Rear View Remote Control 3 Quick Setup SCART cable connection to the TV Install the remote control batteries Remote control working range. Connecting the mains power Standby mode Play a DVD 4 Standard Functions Controls during playback Adjust the volume...
  • Page 3 Audio Subtitles (DVD) Numeric keypad (DVD/CD) 5.10 DVD/USB 5.11 Programming (DVD/CD) 6 System setup TV system Last Memory Screensaver TV Type Password Rating Angle Mark Default Language options 6.10 Video 6.11 Audio 7 Technical Information Technical specification USB Port Supported Media 8 Help and Support Troubleshooting EC Declaration of Conformance...

  • Page 4: Welcome

    1 Welcome Thank you for choosing this Goodmans product. We’ve been making electrical products for the British people for over 90 years. Each of our projects has been carefully designed to be great at what it does and this one is no exception. We hope you enjoy your new DVD Player.

  • Page 5: Front View

    Front View B C D E F G H DVD disc drawer Remote control sensor Press the button to OPEN/ STANDBY button CLOSE the drawer for disc Press to power on or enter playback or removal. STANDBY mode. OPEN/CLOSE button Power on/Standby LED Press to OPEN/CLOSE the disc Green LED in Power on mode and...

  • Page 6: Remote Control

    Remote Control DVD/USB...
  • Page 7 REPEAT button OPEN/CLOSE button During a movie, press repeatedly to Press to open or close the disc switch to different repeat options. drawer. A-B button Numeric buttons During a movie (if available), press 0-9 and 10+. to define the start point, press MENU button again to define the end point;...

  • Page 8: Quick Setup

    TITLE button SLOW button Press to display the DVD TITLE During a movie, press repeatedly menu (if available). to set a different playback speed. Press Play/Pause to resume AUDIO button normal playback. During a movie, press repeatedly to GOTO button. select the language/audio channels required (if available).

  • Page 9: Install The Remote Control Batteries

    RCA sockets White Yellow (audio right) (audio left) (video) Install the remote control batteries 1. Press down the tab on the remote control battery door, in the direction of the arrow, to remove it. 2. Insert the 2 x AAA batteries supplied, taking care to note the + and –...

  • Page 10: Connecting The Mains Power

    Connecting the mains power 1. Connect the mains power lead into the DC 5V socket on the back of the DVD Player. 2. Plug the power adapter into the mains power wall socket and switch on. Note: Do not connect the mains power until ALL other connections have been made.

  • Page 11: Standard Functions

    4 Standard Functions Controls during playback Play/Pause. Skip back. Fast backward. During playback each press increases the fast backward speed from 2X, 4X, 8X & 20X. The next press of the button will resume normal playback. Skip forward. Fast forward. During playback each press increases the fast forward speed from 2X, 4X, 8X &...

  • Page 12: Advanced Functions

    5 Advanced Functions Menu button (DVD only) Press the MENU button during DVD playback to display the Movie main menu. Press the MENU button again to resume playback. Title (DVD only) Press the TITLE button during DVD playback to display the DVD title menu (not all DVDs contain a TITLE menu and so this option may not be available).

  • Page 13: Multi-Angle (Dvd)

    2. When you are in Zoom mode, you can use the down, left and right buttons to scroll to the part of the picture that you wish to Zoom into. 3. To turn the Zoom feature off, repeatedly press the ZOOM button until ZOOM: OFF is displayed.

  • Page 14: Dvd/Usb

    2. For chapter or track number 10, press the 10+, followed by the 0 button. For chapters or tracks higher than 10, such as track 24, press the 10+ button twice and then the 4 button. 5.10 DVD/USB You can switch between DVD and USB mode to view images or play music files from a USB stick.

  • Page 15: System Setup

    6 System setup The SETUP menu enables you to set your preferences for the different options available on your DVD Player. You can use the Down, Left and Right buttons to highlight each function or option and then press the ENTER button to confirm.

  • Page 16: Tv Type

    TV Type The TV type option enables you to set the aspect ratio of the DVD Player to match to the connected TV. The following options are available: • 4:3/PS (pan and scan) • 4:3/LB (letter box) • 16:9 (widescreen) Password You can set the viewing rating for your DVD Player and protect this with your own password:...

  • Page 17: Angle Mark

    Angle Mark There are two options available, ON or OFF. If you set the Angle Mark feature to ON and you play a disc that has multi angle viewing options, the Angle icon will appear in the display when this option is available. You can press the Angle button on the remote control to select your required viewing angle.

  • Page 18: Technical Information

    7 Technical Information Technical specification Model Number 355881 Power Input 100-240V 50/60Hz Power Output DC 5.0V 1.5A 7.5W Frequency response CD: 20HZ-20KHz DVD: 20Hz-44KHz Audio S/N ratio >70dB Power consumption 7W MAX Video/picture MPEG1 V2.0 MPEG2 Video resolution Up to 720*480/576 (30 frames per...

  • Page 19: Usb Port Supported Media

    USB Port Supported Media Max. USB storage device memory capacity: 32GB Picture format: JPG File type Video Codec Audio Codec Resolution MP4V Dolby Digital 720*480/576 (AC3) (.avi/.divx) Xvid (30fps) WMA/PCM/ MPEG-1 LPCM AAC-LC(2ch) MPEG-Audio (MP1/MP2/MP3) MPEG-1/MPEG-2 Dolby Digital 720*480/576 (AC3) (.mpg/.mpeg) (30fps) LPCM...

  • Page 20: Help And Support

    8 Help and Support Troubleshooting Problem What to do No power Check the mains power plug connection at the wall socket and ensure that it is switched on. Check that the DVD player is not in Standby mode. The LED on the front of the DVD Player will be green when the product is powered on and red in Standby mode.
  • Page 21 Problem What to do The remote control is not working The batteries may be exhausted. Replace with new good quality batteries. The remote signal may not be received if there is an obstacle between the remote control and the remote sensor on your DVD Player. Direct sunlight or other bright light sources shining on the remote sensor may affect the performance of the...

  • Page 22: Ec Declaration Of Conformance

    EC Declaration of Conformance This product is intended for use within the UK. This Product complies with the below listed EU directives. 2014/30/EU Electromagnetic Compatibility Directive 2014/35/EU Low Voltage Directive 2011/65/EU Restriction of Hazardous Substances The complete declaration of conformity is available upon request for relevant enquiries.
  • Page 23 This page is intentionally blank...
