- Page 1 DVD/DIVX PLAYER GDVD161DX INSTRUCTION MANUAL Read this manual before installation and use Goodmans Product Information Helpline 0870 873 0080...
-
Page 2: Table Of Contents
CONTENTS IMPORTANT SAFEGUARDS .....................3 SOME DOS AND DON’TS......................4 PACKAGE CONTENTS........................4 GENERAL INFORMATION......................5 ........................5 NFORMATION DVD R :........................6 EGION ODES DVD F :..........................6 EATURES DVD D ........................7 ISCS SYSTEM CONNECTIONS ......................8 1. CONNECTING TO TV SET ....................8 2. CONNECTING TO TV & STEREO AMPLIFIER ..............9 3. -
Page 3: Important Safeguards
Important Safeguards... -
Page 4: Some Dos And Don'ts
Some Dos and Don’ts This equipment has been designed and manufactured to meet European safety standards but like many electrical equipment, care must be taken if you are to obtain the best results and safety to be assured.DO read the operating instructions before you attempt to use the equipment. DO ensure that all electrical connections (including the mains play, extension leads and interconnections between pieces of equipment) are properly made in accordance with the supplied instructions. -
Page 5: General Information
General Information Disc Information Disc types DIVX Recording Digital / MPEG II Digital / MPEG I MPEG 4 Digital method Capacity Single layer 650MB 650MB 650MB Single side 74min 74min 4.7GB = 2 hr Single layer Double sides 8.5GB =4 hr Disc size 12cm / 8cm 12cm... -
Page 6: Dvd Region Codes
DVD Region Codes DVD discs and DVD players are manufactured under the worldwide agreed DVD Regional Code System that ensure the player will only operate with DVDs of the same Regional Code. Regional Code Region Canada, USA Europe (incl. Poland, Romania, The Czech republic), Japan, Middle East (incl. -
Page 7: Care O Fdvd Discs
Care of DVD Discs Video disc contains high density compressed data and therefore require proper handling. Hold the disc with fingers, using one of the two methods shown below, do not touch the disc surface. Do not bend or press the disc, Never place the disc on other equipment or near any heat source. Avoid positions where the disc would be subjected to direct sunlight for long periods. -
Page 8: System Connections
System Connections Please ensure that the unit is disconnected from the mains supply until all connections have be made 1. CONNECTING TO TV SET Connect the player to the TV using the SCART cable as shown below PLAYER... -
Page 9: Connecting To Tv & Stereo Amplifier
2. CONNECTING TO TV & STEREO AMPLIFIER Connect the player to the TV using the SCART cable as shown below Connect the Audio output (Front Left and Front Right) of the DVD player, to the audio input terminals of the stereo amplifier.(cable not supplied) PLAYER... -
Page 10: Connecting To 5.1 Channel Amplifier (Without Dolby Digital Decoder)
3. CONNECTING TO 5.1 CHANNEL AMPLIFIER (without DOLBY DIGITAL decoder) This player is equipped with built-in DOBLY DIGITAL decoder and 6 analog audio outputs Connect the player to the TV using the supplied SCART cable as shown below. Connect each of the 6 output sockets to the relevant inputs on the amplifier (cables not supplied) (An amplifier with 6 channels input and output is required, AC3 decoder is NOT required). -
Page 11: Connecting To 5.1 Channel Amplifier (With Dolby Digital Decoder)
4. CONNECTING TO 5.1 CHANNEL AMPLIFIER (with Dolby Digital Decoder) Connect the player to the TV using the supplied SCART cable as shown below. Connect the digital output (optical or coaxial leads/cables not supplied) from the player to the amplifier with DOLBY DIGITAL decoder. -
Page 12: Location Of Controls
Location of Controls 1. FRONT PANEL 1. POWER STANDBY 6. HEADPHONE 1 VOLUME 2. DISC TRAY 7. HEADPHONE 2 VOLUME 3. DISPLAY 8. OPEN / CLOSE 4. HEADPHONE SOCKET 1 9. PLAY 5. HEADPHONE SOCKET 2 10. STOP 2. REAR PANEL Sub-woofer Output (for connection to amplifier without digital decoder) Surround Right Output (for connection to amplifier without digital decoder) Front Right Output (for connection to amplifier without digital decoder) -
Page 13: Remote Control
3. REMOTE CONTROL... -
Page 14: Inserting Batteries Into The Remote Control
INSTALATION OF BATTERIES Remove the battery compartment cover of the remote control. Insert two AAA batteries into the battery compartment. Make sure that the batteries have been inserted observing the correct polarity When replacing batteries, replace both batteries. Do not mix new and used batteries together If you are not going to use the DVD Player for a long time remove the batteries from the remote control to prevent against damage due to leaking batteries... -
Page 15: Getting Started
Getting Started Read through this instruction manual. Unpack the unit. Load batteries into the remote control. Connect the unit to the TV (and amplifier if required) make sure the connections are correct following instructions on pages 6-9. Connect to the mains supply, turn on the power switch on the rear of the player. Check the settings of the player, TV and amplifier (if connected) are correct (check with relevant instruction manual). -
Page 16: Skip/Search
3. SKIP/SEARCH • Press the NEXT button to skip forwards to the next track/chapter on the disc. Press repeatedly to skip to subsequent tracks/chapters. • Press the PREVIOUS button to skip backwards to the previous track/chapter on the disc. Press repeatedly to skip to earlier tracks/chapters. •... -
Page 17: Setup Menu
Setup Menu Press the SETUP button on remote control during STOP or PLAY mode to enter the SETUP MENU. The navigation keys are used to navigate the menus. Use the UP and DOWN keys to highlight the required menu item. Use the RIGHT and LEFT keys to enter and return from submenus. - Page 18 ANGLE MARK -- GENERAL PAGE -- (DEFAULT: ON) The angle mark will be shown if there are multiple TV DISPLY angles recorded on the DVD for a particular PIC M ODE scene. If this option is set to ON the angle mark ANGLE M ARK will appear.
-
Page 19: Speaker Setup
2. SPEAKER SETUP SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP DIVX(R) REGISTRATION PREFERENCES EXIT SETUP DOWNMIX (DEFAULT: OFF) -- SPEAKER SETUP PAG E -- If the player is connected only to the TV, i.e. no DO W NM IX LT/RT external 5.1 channel amplifier is connected the CENTER... - Page 20 SUBWOOFER -- SPEAKER SETUP PAG E -- (DEFAULT: ON) DO W NM IX CENTER This option will turn the subwoofer output on or REAR off. SUBW O O FER CNTR DELAY O FF REAR DELAY TEST TO NE M AIN PAG E CENTRE DELAY -- SPEAKER SETUP PAG E -- (DEFAULT: OFF)
-
Page 21: Audio Setup
3. AUDIO SETUP SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP DIVX(R) REGISTRATION PREFERENCES EXIT SETUP SPDIF OUTPUT (DEFAULT: OFF) Controls the output signal from the DIGITAL -- AUDIO SETUP PAGE -- AUDIO COAXIAL and OPTICAL outputs. - Select OFF when connecting only to the TV or SPDIF OUTPUT connecting using a analogue amplifier DUAL M ONO... - Page 22 PRO LOGIC (Optional function) -- AUDIO SETUP -- (DEFAULT: OFF) SPDIF OUTPUT Pro Logic is an advanced decoder that creates OP M ODE five-channel surround output (Left, Center, Right, DUAL M ONO Left Surround, and Right Surround) from any 2- COM PRESSION channel (STEREO) source.
-
Page 23: Divx(R) Registration
4. DivX(R) REGISTRATION SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP DIVX(R) REGISTRATION PREFERENCES EXIT SETUP DivX® Registration allows use of this player with the DivX® Video On Demand service. This will allow the purchase and renting of videos using the DivX® Video On Demand format. To learn more visit www.divx.com/vod... -
Page 24: Preferences
5. PREFERENCES SETUP MENU MAIN PAGE GENERAL SETUP SPEAKER SETUP AUDIO SETUP DIVX(R) REGISTRATION PREFERENCES EXIT SETUP TV TYPE -- PREFERENCE PAGE -- (DEFAULT: PAL) TV TYPE M ULTI This player can play discs recorded in either PAL VIDEO OUTPUT NTSC or NTSC format. - Page 25 -- P R E F ER EN C E P AG E -- DISC MENU LANGUAGE (DEFAULT: ENGLISH) T V TY P E V ID E O O U TP U T Select the default MENU language to be used AU D IO E N G LIS H when viewing DVD.
- Page 26 DEFAULTS -- PREFERENCE PAGE -- VIDEO OUTPUT Select RESET to restore the factory settings AUDIO (DEFAULTS) for the player. SUBTITLE DISC MENU LOCALE PARENTAL PASSW ORD DEFLAUTS RESET SMART NAVI -- PREFERENCE PAGE -- AUDIO (DEFAULT: WITH MENU) SUBTITLE Select WITH MENU to display the folder and DISC M ENU track list.
-
Page 27: Jpeg Picture Cds
JPEG Picture CDs SMART NAVI MENU If the SMART NAVI option in the setup menu is set to ‘With Menu’ the following smart navi menu will be shown SM ART NAVI RO O T JPEG 1 JPEG 2 JPEG 3 JPEG 4 JPEG 5 JPEG 6... -
Page 28: Mp3 Operation
MP3 OPERATION SMART NAVI MENU If the SMART NAVI option in the setup menu is set to ‘With Menu’ the following smart navi menu will be shown SM ART NAVI ROOT M P3 1 M P3 2 M P3 3 M P3 4 M P3 5 M P3 6... -
Page 29: Divx/Mpeg4 Operation
DivX-encoded content such as this GDVD161DX. This means that videos can be downloaded from the Internet and then played using this player. For more information about the DivX® codec visit the DivX website at www.divx.com. -
Page 30: Function Descriptions
FUNCTION DESCRIPTIONS Function Key Description POWER POWER ON / OFF Always turn the Power OFF after use) OPEN / CLOSE DISC TRAY Press this button to open or close the DISC TRAY. PLAY/ PAUSE Press to start playback. During playback press to pause. To resume normal playback from pause mode press this button again SEARCH FORWARD SEARCH BACKWARD... - Page 31 Function Key Description PRE-STOP / STOP Press the STOP button once to stop the unit in PRESTOP mode. In this mode when the PLAY/PAUSE button is pressed playback will resume at the position playback was stopped. Press the STOP button twice to completely stop playback. When the PLAY/PAUSE button is pressed playback will resume from the start of the disc.
- Page 32 Function Key Description GOTO SEARCH GOTO Press the GOTO button to enter the GOTO mode, to search for a desired section. To GOTO a specific Chapter/track press GOTO key once. Press again to enter a specific time to go to. Use the NUMERICAL KEYS to enter the chapter/track/time to go to in the highlighted area.
- Page 33 REPEAT A – B REPEAT A SECTION (A Start Press the REPEAT A-B button at the start of the section to be repeated. “A-B SET A” will be shown on the screen B End Press the REPEAT A-B button at the end of the section to be repeated “A-B SET B” will be shown on the screen Cancel the setting Press the button again to cancel A-B REPEAT and to resume normal playback “A-B...
- Page 34 Function Key Description ZOOM PICTURE ZOOM Enlarge the picture up to 4 times original size. Press the ZOOM button then use the FORWARD/BACKWARDS search buttons to adjust the level of zoom When in the ZOOM mode, use the NAVIGATIONAL keys to pan across the picture. SLOW MOTION SLOW Playback the movie in slow motion.
- Page 35 Function Key Description TO CHANGE THE AUDIO TRACK (VCD only) DISPLAY THE SETUP MENU SETUP CHANGE THE VIDEO OUTPUT BETWEEN PAL AND NTSC. VIDEO NOTE : the video output varies according to the DVD. Press “ ” and “v“ to increase or decrease the audio volume.
-
Page 36: Troubleshooting
TROUBLESHOOTING Please check below if there is a problem with the player. If the problem is not listed below please call the Goodmans Product Information Helpline: 0870 873 0080 Symptom Check and Action No Power 1. Check the power cord has been properly connected to the wall outlet 2. -
Page 37: Troubleshooting (Continue)
TROUBLESHOOTING (continue) Symptom Check and Action No surround 1. Check if the DOWNMIX option has been turned off. sound MP3 disc no 1. If there are other types of file on the same disc as MP3s, the MP3 files may not sound or noise be recognised. -
Page 38: Specifications
SPECIFICATIONS Type of Disc DIVX Version 3.11 / 4.xx / 5.xx CD-DA CD-R / CD-RW PHOTO CD (JPEG) Video Format MPEG 1, MPEG 2, MPEG 4 Audio Format MPEG 1, LAYER 1, LAYER 2 Signal Output Color System : NTSC / PAL Audio System : AC3 decoded 5.1 channels output / digital output / DTS digital output Video Output : 1Vpp (at 75 ohm)
