Open Date Thermocode 2 Series Setting Instructions Manual page 5

Ethernet & USB-B Board
Changing System Variables using Codesoft (Continued)
Changing System Variable XSYSIPMASK
Enter the required Variable name and the address. (see below)
Variable name Space Numeric value.
XSYSIPMASK
This dialog box appears Click on "YES"
Once all system variables are set for TCP/IP, turn off the printer and then re-start the printer. To ensure the
settings are configured correctly, before attempting to connect to the Ethernet.
Please Note! You cannot check the system variables from Codesoft.
(
Issue 1.03)
255.255.255.0
Once the variable has been entered, then click on "Send"
11 January 2010 Page No- 5 -
