Open Date Thermocode 2 Series Setting Instructions Manual page 3

Ethernet & USB-B Board
Changing System Variables using Codesoft
To enter or change the System variables form Codesoft the proceeding "XSYS" is required.
XSYSIPADDR 192.168.2.101 (example)
XSYSIPGW 192.168.2.1 (example but not required)
XSYSIPMASK 255.255.255.0 (example)
Changing System Variable XSYSIPADDR
Enter the Password 650070 or 999999
Enter the required Variable name and the address. (see below)
This dialog box appears Click on "YES"
(
Issue 1.03)
Codesoft Driver, Version: - V11.10.19 or higher.
(Available on the web site
Variable name Space Numeric value.
XSYSIPADDR
Once the variable has been entered, then click on "Send"
11 January 2010
http://www.opendateinfo.com/
192.168.2.101
Page No- 3 -
)
