- Page 1 QUICK START GUIDE/USER MANUAL KV6224DPH DUAL-MONITOR HDMI/DP USB 3 KVM SWITCH 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM 24/7 TECHNICAL SUPPORT AT 1.877.877.2269 OR VISIT BLACKBOX.COM...
-
Page 2: Table Of Contents
2. OVERVIEW ........................................6 2.1 INTRODUCTION ......................................6 2.2 FEATURES ........................................6 2.3 WHAT’S INCLUDED ....................................6 2.4 HARDWARE DESCRIPTION ..................................7 KV6224DPH ............................................7 3. INSTALLATION ......................................9 4. OPERATION......................................... 10 A.1 FCC STATEMENT ..................................12 A.2 CE STATEMENT ..................................12 A.3 ROHS ...................................... -
Page 3: What's Included
QUICK START GUIDE TECHNICAL SUPPORT 1.877.877.2269 WHAT’S INCLUDED Your package should include the following items. If anything is missing or damaged, contact Black Box Technical Support at 877-877-2269 or info@blackbox.com Š (1) KV6224DPH unit Š Š (1) 12-VDC power adapter Š... - Page 4 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 QUICK START GUIDE TECHNICAL SUPPORT 1.877.877.2269 OPERATION COMMANDS FOR HOTKEYS/FRONT-PANEL BUTTONS (CONTINUED) COMMAND HOTKEYS FRONT-PANEL BUTTON DESCRIPTION Scr-Lock, Scr-Lock +”Fy” Select Audio and Mic Port Select the active audio and mic port Fy =F5–F6 (for 2-port) or F5–F8 (Jointly select PC port and (for 4-port) (Fy is a Function Key)
-
Page 5: Specifications
CHAPTER 1: SPECIFICATIONS TECHNICAL SUPPORT 1.877.877.2269 1. SPECIFICATIONS TABLE 1-1. SPECIFICATIONS SPECIFICATION KV6224DPH Number of Ports Number of Consoles PC Keyboard/Mouse Connectors (4) USB Type B female PC Video Connectors (4) HDMI 2.0 female, (4) DisplayPort 1.2 female PC Audio/Mic (8) 3.5-mm audio/mic Jack female... -
Page 6: Overview
4K monitors between four multimedia computers with dual-monitor HDMI/DP display. It is the perfect solution for computers using mixed DisplayPort/HDMI graphics cards. With KV6224DPH, you can fully control four dual-monitor PCs using only one keyboard, mouse and two 4K monitors; essential for saving valuable desktop space. -
Page 7: Hardware Description
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 2.4 HARDWARE DESCRIPTION KV6224DPH FIGURE 2-1. FRONT PANEL OF THE KV6224DPH 4, 5 2B 2A 2B 2A FIGURE 2-2. BACK PANEL OF THE KV6224DPH 1.877.877.2269 BLACKBOX.COM... - Page 8 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 2: OVERVIEW TECHNICAL SUPPORT 1.877.877.2269 TABLE 2-1. KV6224DPH COMPONENTS NUMBER IN FIGURE 2-1 OR 2-2 COMPONENT DESCRIPTION PC Keyboard/Mouse Connectors (4) USB Type B female PC Video Connectors (2) HDMI female...
-
Page 9: Installation
NOTE: The two left-side white USB ports are for keyboard and mouse and two blue USB 3.0 ports are for other USB devices. FIGURE 3-1. KV6224DPH – REAR VIEW 3. Connect each KVM PC port to a computer, using one HDMI 2.0 video cable (male-to-male) and one DP 1.2 video cable (male-to-male), one USB cable (type A to type B), and one audio and mic combo cable (male-to-male). -
Page 10: Operation
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: OPERATION TECHNICAL SUPPORT 1.877.877.2269 4. OPERATION A keyboard hotkey sequence consists of at least three specific keystrokes: Hotkey sequence = [ScrLk]* + [ScrLk] * + Command key(s) * User-definable = SCROLL LOCK, CAPS, ESC, F12 or NUM LOCK Hotkey preceding sequence configuration: For users who want to use a preceding sequence other than two consecutive Scroll Locks, there is also one convenient way to configure it. - Page 11 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 CHAPTER 4: OPERATION TECHNICAL SUPPORT 1.877.877.2269 TABLE 4-1 (CONTINUED). OPERATION COMMANDS FOR HOTKEYS/FRONT-PANEL BUTTONS COMMAND HOTKEYS FRONT-PANEL BUTTON DESCRIPTION Unbind PC and Hub Port Disable the binding of PC port and hub Scr-Lock, Scr-Lock + “X”...
-
Page 12: Fcc Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.1 FCC STATEMENT This equipment has been tested and found to comply with the regulations for a Class B digital device, pursuant to Part 15 of the FCC Rules. -
Page 13: Nom Statement
NEED HELP? LEAVE THE TECH TO US LIVE 24/7 APPENDIX A: REGULATORY INFORMATION TECHNICAL SUPPORT 1.877.877.2269 A.4 NOM STATEMENT 1. Todas las instrucciones de seguridad y operación deberán ser leídas antes de que el aparato eléctrico sea operado. 2. Las instrucciones de seguridad y operación deberán ser guardadas para referencia futura. 3. -
Page 14: Disclaimer
B.1 DISCLAIMER Black Box Corporation shall not be liable for damages of any kind, including, but not limited to, punitive, consequential or cost of cover damages, resulting from any errors in the product information or specifications set forth in this document and Black Box Corporation may revise this document at any time without notice. - Page 15 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 1.877.877.2269 BLACKBOX.COM...
- Page 16 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 1.877.877.2269 BLACKBOX.COM...
- Page 17 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 NOTES TECHNICAL SUPPORT 1.877.877.2269 1.877.877.2269 BLACKBOX.COM...
- Page 18 NEED HELP? LEAVE THE TECH TO US LIVE 24/7 TECHNICAL SUPPORT 1.877.877.2269 © COPYRIGHT 2021. BLACK BOX CORPORATION. ALL RIGHTS RESERVED. K V6224DPH_QSG_USER_REV1.PDF...
