Cub Cadet 59A30044150 Operator's Manual

Cub Cadet 59A30044150 Operator's Manual

Pto driven - grass collection system
Hide thumbs
Table of Contents

Advertisement

Quick Links

MODEL YEAR:
2014-2015
TANK
DESIGNED
TO FIT:
SERIES
COLLECTION SYSTEM
MODEL #
ALTERNATE
21131508
MODEL #
OF ADDED WEIGHT KIT P# 59A30037150 (A1149) FOR SAFE OPERATION!
MANUAL PART#: Q04
74
S
- 60"
DECKS
59A30044150
*LZ MODELS:
COLLECTION SYSTEM REQUIRES INSTALLATION
OPERATOR
ASSEMBLY
OPERATION
COLLECTION SYSTEM
SZ
- 54" & 60"
- 48", 54" & 60"
DECKS
Tank S Models:
53RN2RUD050
Tank SZ Models:
53AI2PUC050
53BI2PUD050
53YI2PUC050
53YI2PUD050
53RE2PUD050
53AI2PUD330
'
S MANUAL
MAINTENANCE
PTO DRIVEN -
GRASS
LZ
L
- 54" & 60"
DECKS
DECKS
Tank L Models:
53AN2RTB050
53AI2RTC050
53AN2RTD050
53AI2RTD050
53AN2RTD009
53YI2RTD050
Tank LZ Models:
53AI2PTC050
53BI2PTD050
53YI2PTC050
53YI2PTD050
53BH2PTD330
REV:
4 - June 13th 2018

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 59A30044150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cub Cadet 59A30044150

Summary of Contents for Cub Cadet 59A30044150

  • Page 1 TO FIT: - 60” - 54” & 60” - 54” & 60” SERIES - 48”, 54” & 60” DECKS DECKS DECKS DECKS 59A30044150 COLLECTION SYSTEM MODEL # ALTERNATE 21131508 Tank L Models: Tank S Models: MODEL # 53RN2RUD050 53AN2RTB050 53AI2RTC050...

  • Page 2: Table Of Contents

    PECO GRASS COLLECTION SYSTEM TABLE OF CONTENTS SECTION PAGE SECTION PAGE Safety - - - - - - - - - - - - - - - - - - - - - - - - - - - - - - 2 2-14 Length Of Hose Adjustment - - - - - - - - - - - - - - 15 Safety Alert Symbols - - - - - - - - - - - - - - - - - - - - - - 3 2-15 Upper Hose Installation - - - - - - - - - - - - - - - - 15...

  • Page 3: Safety Alert Symbols

    SAFETY WARNING! NEVER operate the mower unless the discharge guard and either the deflector assembly or the vacuum collector adapter are fastened securely in place. WARNING! Do not work around the mower deck boot or the blower area until you are certain that the mower blades and the blower impeller have stopped rotating.

  • Page 4: Warranty

    PECO LIMITED WARRANTY FOR NEW PRODUCTS A. WHAT IS UNDER WARRANTY? PECO extends the following warranties to the original purchaser of each new PECO consumer product subject to the following limitations. 1. PRODUCT WARRANTY: Any part of any consumer product, which is defective in material or workmanship as delivered to the purchaser will be repaired or replaced, as PECO elects, without charge for parts or labor, if the defect appears within 12 months from the date of delivery of the product to the original purchaser.

  • Page 5: Introduction And Description

    LZ Models: Collection system requires installation of added weight kit 59A30037150 (A1149) for safe operation! SZ models do not require a weight kit. Refer to Section 2-21 in this manual for weight kit installation instructions. Contact your Cub Cadet dealer to order weight kit 59A30037150 (A1149).

  • Page 6: Installation For Use

    Engine Pulley NOTE: The mower deck PTO belt must be removed Bushing from the electric clutch before continuing with the installation. Refer to your Cub Cadet mower owner’s Pulley manual for instructions on PTO belt removal. Clamp Washer From the underside of the engine, disconnect the wiring harness attached to the electric clutch.

  • Page 7: Pto Mount Plate Assembly Installation

    2-2 PTO Mount Plate Assembly Installation Secure the PTO mount plate assembly P#(A1108) to the chassis of the mower using (4) 3/8”-16 x 1” carriage bolts P#(K1182) and (4) 3/8-16 nylon flange locknuts P#(K2038). Leave the hardware loose until the lower mount assembly is installed in the next section. Refer to Figure 2-2.

  • Page 8: Pto Assembly Installation

    2-4 PTO Assembly Installation Insert the PTO assembly P#(A1821) into the slots on the PTO mount plate assembly. Secure the PTO assembly with (1) mount pin P#(B0274) and (1) hair pin clip P#(K0086). Remove the belt guard P#(B0679) and hardware in preparation for the belt installation.

  • Page 9: Drive Belt Installation And Adjustment

    Connect the drive belt A59K P#(M0254) from the engine 2-5 Drive Belt Installation and pulley to the lower gear box pulley (Figure 2-5d). Adjustment Figure 2-5d Loosen the (4) bolts P#(K1191), (2) on each side, that Connect Belt secure the gear box assembly to the PTO assembly To Both Pulleys P#(A1803) (Figure 2-5a and 2-5b).

  • Page 10: Cam Assembly Adjustment

    2-6 Cam Assembly Adjustment 2-7 Blower Cone Installation The cam assembly P#(A0422), which controls the A30K Thread (1) 5/16”-18 jam nut P#(K0120) onto each end of blower belt P#(M0250) tension, comes from the factory (2) 5/16”-18 x 2-1/2” HHCS P#(K0125) as shown in pre-adjusted.

  • Page 11: Safety Interlock Harness Installation

    Installation Safety Interlock Harness To obtain access to the mower’s safety interlock switch, lift the operator’s seat on the mower as shown in Figure 2-8a. Refer to your Cub Cadet operator’s manual for reference. Safety Interlock Connect ROPS Figure 2-8a Switch Location Mower’s...

  • Page 12: Lower Mount Tube Installation

    2-10 Upper Frame Assembly 2-9 Lower Mount Tube Installation Installation Secure the (2) lower mount tubes P#(B0640) to the lower main frame using (2) 5/16”-18 u-bolts P#(K1098) Position the upper frame assembly P#(A1058) above the and (4) 5/16”-18 nylon flange locknuts P#(K2516) PER lower mount tubes as shown in Figure 2-10.

  • Page 13: Top Assembly To Upper Frame Assembly Installation

    2-11 Top Assembly To Upper Frame Assembly Installation Position the top assembly P#(A1139) above the upper frame assembly as shown in Figure 2-11. Fasten the top assembly to the upper frame assembly using (2) 5/16”- 18 x 2-1/2” HHCS P#(K0125) and (2) 5/16”-18 nylon flange locknuts P#(K2516).

  • Page 14: Boot To Mower Deck Installation

    2-13 Boot To Mower Deck Installation Secure the boot plate assembly P#(A1961) to the NOTE: The boot kit assembly is designed to fit the 48”, aluminum boot P#(E0026) using (2) 3/8”-16 x 1” carriage 54” and 60” decks. To ensure a snug fit between the bolts P#(K1182) and (2) 3/8”-16 nylon flange locknuts boot and the mower deck, follow the instructions in this P#(K2038).

  • Page 15: Length Of Hose Adjustment

    2-14 Length Of Hose Adjustment 2-16 Lower Hose To Blower Cone The hoses in steps 2-15 and 2-16 must be cut to fit your Installation machine. Follow steps 2-15 and 2-16. Do not cut the Slide a 8” hose clamp P#(J0080) over both ends of the hoses until you have tried to fit them on your machine.

  • Page 16: Impeller Blade Removal/Replacement

    2-18 Impeller Blade Removal/Replacement To gain impeller blade (#1) access, first remove the Tips on removing impeller blade; blower cone (#2) from the blower housing, located on 1 - Try carefully hitting the base of the impeller blade the PTO assembly P#(A1821), by removing two blower (#1), between each vein (#12), with a rubber mallet to loosen the taper-lock bushing hold.

  • Page 17: Weight Kit Installation

    2-19 Installation/Removal Of Figure 2-19c Collection Bags Plastic Top IMPORTANT! To prevent bag wear, install (2) red plastic end caps P#(J0274), as shown in Figure 2-19a, on each bag ring before installing bags. Figure 2-19a Bag Ring Red Plastic End Caps Fasten Draw -Latch Here &...
  • Page 18 2-20 Weight Kit Installation Figure 2-20c 2012-2014 Tank LZ Models - Installing a weight kit is mandatory for safe operation of the collection system. SZ models do not require a weight kit. Completely thread (2) 3/8”-16 flange nuts P#(K1215) onto (1) 3/8”-16 U-bolt P#(K0407). Repeat process again to create two sets.

  • Page 19: Exploded Part Views And Assemblies

    3/16" x 1-1/2" FENDER WASHER, Z K1265 BLACK PANEL RETAINER V1120 SCREEN V1118 DUST GUARD R0006 CUB CADET LOGO R1057 2" x 4" Red Reflector Label R1069 Warning - Turn Off Blower Label R1065 Made In USA Label R1054 Important Check Hoses...
  • Page 20 A1841_01 PTO Arm Assembly...
  • Page 21 A1941_01 PTO Base Assembly Exploded Parts View...
  • Page 22 A1941_01 PTO Base Assembly Exploded Parts List...
  • Page 23 A1623 PTO Assembly w/ Pulley Guard Exploded Parts List...
  • Page 24 A1821 PTO Assembly w/ Safety Interlock Exploded Parts List...

  • Page 26: Safety Interlock Harness Wiring Schematic

    Wiring Diagram P0208 Safety Interlock Wiring Harness...

  • Page 27: Operating Instructions

    SECTION III 3-3 Disengagement Of The Blower OPERATING A. To disengage the blower, rotate the engagement INSTRUCTIONS handle towards the mower. 3-1 General Safety WARNING: The blower will continue to spin. DO NOT TOUCH the blower, pulleys, or the belt until the tractor is Only qualified people familiar with this operator’s manual turned off.

  • Page 28: Lubrication

    ASSEMBLY Center will be happy to supply replacement parts, accessories, and do any service or repairs to your MODEL: 59A30044150 collection system. If for any reason your Service Center is unable to service your collection system or supply replacement parts, contact New PECO, Inc. and include SERIAL: ____________ the following information on the chart below.

  • Page 29: Safety Decals

    To promote safe operation, PECO supplies safety decals on all products manufactured. Damage can occur to safety decals either through shipment, use or reconditioning. Contact your local Service Center for replacement decals. Part #: R0006 - Cub Cadet Label Part #: R1051...
  • Page 31 NOTES...
  • Page 32 Cub Cadet LLC P.O. Box 361131 Cleveland, Ohio 44136-0019 Phone: 1-877-282-8684 MTD Products Limited Kitchener, ON N2G 4J1 1-800-668-1238...
