- Page 1 MODEL: 22MM10691 INSERT MODEL: 22II026FGL www.tsicustomerservice.com 1-888-674-7517 Twin-Star International, Inc; Delray Beach, FL 33445 Made in China • Printed in China A549 www.tsicustomerservice.com...
- Page 2 Thank you for purchasing a Nous vous remercions d’avoir acheté Gracias por comprar un producto Twin-Star International product, un produit Twin-Star International, de Twin-Star International, designed in the U.S.A. We hope conçu aux États-Unis. Nous espérons diseñado en los E.U.A.
- Page 3 SERVICIO DEPENDABLE UN SERVICE À DE ATENCIÓN CUSTOMER LA CLIENTÈLE AL CLIENTE SERVICE FIABLE FIABLE ¿Tiene preguntas? Nuestro Centro Questions? Nos centres d’appels sont Questions? Our message centers de mensajes está disponible 7 días disponibles 7 jours sur 7 et 24 heures are available 7 days a week 24 de la semana, 24 horas del día con sur 24 avec notre ligne d’assistance...
- Page 4 MAXIMUM LOAD 13.6 kg / 30 lb MAXIMUM LOAD CHARGE MAXIMALE DE 6.8 kg / 15 lb 13.6 kg / 30 lb CHARGE MAXIMALE DE CARGA MÁXIMA 6.8 kg / 15 lb 13.6 kg / 30 lb CARGA MÁXIMA 6.8 kg / 15 lb WARNING: For use with most LCD/Plasma televisions weighing 13.6 kg / 30 lb or less.
- Page 5 SAFETY INFORMATION INFORMACIÓN DE INFORMATION DE SÉCURITÉ SEGURIDAD Please read and understand Assurez-vous de lire et de Lea y comprenda this entire manual before comprendre l’intégralité du completamente este manual attempting to assemble, présent manuel avant de tenter antes de intentar ensamblar, operate or install the product.
- Page 6 HARDWARE/QUINCAILLERIE/FERRETERÍA [x1] [x1] Touch-Up pen PH-BKTWHT003 (NOT TO SCALE) REPLACEMENT PARTS 22MM10691 PIECES DE REMPLACEMENT 22MM10691 PARTES DE REPUESTO 22MM10691 PH-GLDBRW001 PH-BKTZNC001 MP#MG 22MM10691REV.0 www.tsicustomerservice.com...
- Page 7 Wall Pared WARNING: You must install the tipping restraint hardware to help prevent any accidents or damage to the unit. We strongly recommend mounting this hardware to a wall stud and your unit. AVERTISSEMENT: Il est nécessaire d’installer les pièces d’arrimage anti basculement pour prévenir les accidents ou les dommages à...
-
Page 8: Getting Started
GETTING STARTED 1. Remove the product identification sticker from the front of the insert. Product Identification Sticker 2. Attach the Product Identification Sticker to the Manual below for future reference. This information is used for product registration and also is necessary for customer service. Attach Product Identification Sticker Here 3. -
Page 9: Important Instructions
IMPORTANT INSTRUCTIONS When using electrical appliances, basic precautions should always be followed to reduce the risk of fire, electrical shock, and injury to persons including the following: 1. Read all instructions before using this appliance. 2. DANGER – High temperatures may be generated under certain abnormal conditions. Do not partially or fully cover or obstruct the front of this heater. - Page 10 OPERATION INSTRUCTIONS Control Panel Display The heater can be operated by either the remote control or the control panel. www.tsicustomerservice.com A549...
- Page 11 OPERATION INSTRUCTIONS FUNCTION ICON DESCRIPTION The power button supplies power to all of the functions POWER of the fireplace. The power button will put the insert in a standby mode. This will turn off all functions at once but will hold the settings in the memory. By pressing the Power button again the unit will turn on at the same settings.
-
Page 12: Troubleshooting
TROUBLESHOOTING Problem Root Cause Corrective Action Unplug the fireplace, remove the back panel of the fireplace and check that The thermostat sensor is Display shows “ ” the thermostat is plugged into the main circuit board. If this does not solve broken or disconnected. -
Page 13: Exploded View
EXPLODED VIEW Part Part Name Part Number Front Glass with Frame Y17-S215-P27 Emberbed with Logset Y17-S215-P02 Y17-S215-P44E Emberbed Circuit Board Flame Circuit Board Y17-S215-P40 Flame Generator Drive Motor P10-6-Q Control Panel Circuit Board Y17-S215-P32 Y17-S215-P15 Main Circuit Board Thermostat Sensor INS-NTC Heater/Blower Assembly Y17-S215-P01... -
Page 14: Fcc/Ic Information
FCC/IC INFORMATION Warning: Changes or modifications to this unit not expressly approved by the party responsible for compliance could void user’s authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for Class B digital device, pursuant to part 15 of the FCC Rules. -
Page 15: Year Limited Warranty
1-YEAR LIMITED WARRANTY The manufacturer warrants that your new Electric Fireplace is free from manufacturing and material defects for a period of one year from date of puchase, subject to the following conditions and limitations. 1. Install and operate this appliance in accordance with the installation and operating instructions furnished with the product at all times. - Page 16 www.tsicustomerservice.com www.tsicustomerservice.com A549...
