Maintenance And Care - Black & Decker Price Pfister 16 Series Manual

11
11 UNIT START UP
Turn on hot and cold water supplies, and check all connections for leaks.
FAUCET FUNCTIONS
12
12B
12 HAND SHOWER FUNCTIONS
Hand Shower (12A) can be adjusted to 8 different spray patterns. To adjust spray, turn
switch (12B) to a desired spray pattern.
13
13C
13 SHOWER DIVERTER FUNCTION
By turning Diverter Switch (13A) clockwise until it stops, water will flow from both Hand
Shower (13B) and Shower Head (13C). By turning Diverter Switch (13A) one quarter
counterclockwise, water will flow from Hand Shower (13B). By turning Diverter Switch
(13A) counterclockwise until it stops, water will flow from Shower Head (13C).
Warning: Slide Bar can become extremely hot while in use.
12A
13A
13B
ENGLISH
14
14C
14A
14 HAND SHOWER HOLDER FUNCTION
By pressing Bottom (14A) on Hand Shower Holder (14B) the vertical position of Hand
Shower (14D) can be adjusted along Slide Bar (14C). The angle position of Hand Shower
(14D) an be adjusted by turning the Hand Shower Holder (14B).
MAINTENANCE & CARE
CAUTION: Maintenance
DISASSEMBLY
1. Replacement parts may be available at the store where you purchased
your faucet.
2. When replacement parts are not available, please write or call Price Pfister
Consumer Service.
3. Always turn off water and relieve pressure before working on your
faucet.
NOTE: Trim Care
Cleaning Instructions:
For all Handles and decorative finishes, use only a soft damp cloth
to clean and shine. Use of polish, detergents, abrasive cleaners,
organic solvents or acid may cause damage. Use of other than
a soft damp cloth will nullify our warranty!
Special Trim:
Trim products which contain Porcelain or other similar substance
are not acceptable for public areas or Commercial use. Installation
of Said Trim is at Users Risk!
1–800–PFAUCET (1–800–732–8238)
For Toll-Free Pfaucet information call
1–800–PFAUCET (1–800–732–8238)
or visit www.pricepfister.com
• Installation Support
• Care and Warranty Information
4
14D
14D
14B
14B
