Fieldtrial Version
GSM Terminal on Ascotel® IntelliGate®
Quick User's Guide
With your GSM terminal you can dial in into the telephone system using a special
call number. Once authentication is effected you have the possibility to make
internal or external calls or to carry out specific */# procedures. Your system
administrator provides you with an internal call number to be reached by other
internal subscribers.
Enter both call numbers in the following table (just click and write in the empty
field in the PDF).
GSM dial in number
My internal GSM call number
Depending on how the integration of your GSM terminal is configured, the
authentication is effected automatically by transmitting the GSM call number
(CLIP) or manually by entering the internal GSM call number and the terminal PIN.
Automatic authentication
1. Select the GSM dial in number.
2. After a ring back tone you obtain the internal dialling tone and you can now
make internal and external calls (provided you are authorized) or carry out the
*/# procedures below.
Manual authentication
1. Select the GSM dial in number.
2. After a ring back tone you obtain the authentication tone.
3. Enter your internal GSM call number and press the * key.
4. Enter your terminal PIN and press the # key.
5. You obtain the internal dialling tone and you can now make internal and
external calls (provided you are authorized) or carry out the */# procedures
below.
No.:
No.:
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Ascotel IntelliGate 150 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Aastra Ascotel IntelliGate 150

  • Page 1 Fieldtrial Version GSM Terminal on Ascotel® IntelliGate® Quick User’s Guide With your GSM terminal you can dial in into the telephone system using a special call number. Once authentication is effected you have the possibility to make internal or external calls or to carry out specific */# procedures. Your system administrator provides you with an internal call number to be reached by other internal subscribers.
  • Page 2 Ascotel® IntelliGate® 150/300/2025/2045/2065 Supported Procedures for GSM Terminals There are 2 levels of integration for GSM terminals: • With level 1 you can only carry out */# procedures in prefix dialling, i. e. when you have not yet set up a call. •...
  • Page 3 Ascotel® IntelliGate® 150/300/2025/2045/2065 • Protect against C a l l f o r w a r d i n g ( C F U ) • Allow to own set C a l l f o r w a r d i n g ( C F U ) Call Forwarding on No Reply (CFNR) C a l l F o r w a r d i n g o n N o R e p l y ( C F N R ) *61 <...
  • Page 4 Ascotel® IntelliGate® 150/300/2025/2045/2065 *31# • Suppress call number display for all calls (permanent CLIR) D i s p l a y i n g y o u r o w n c a l l n u m b e r t o t h e d e s t i n a t i o n s u b s c r i b e r ( C L I P a n d C L I R ) •...
  • Page 5 Ascotel® IntelliGate® 150/300/2025/2045/2065 Park P a r k *** *76 • Park subscribers in suffix dialling P a r k • Connect with parked subscriber P a r k *86 < SC No.> Picking Up a Call P i c k i n g U p a C a l l *88 <...
