- Page 1 PAG4.1ZpZtAR PAG4.1ZpZtAW PAG4.1ZpZtAS PAG5.0ZpZtAR INSTRUCTION MANUAL GAS HOB IO-HOB-0001 / 8061613 (11.2015./1)
-
Page 2: Basic Information
DEAR CUSTOMER, Your hob is exceptionally easy to use and extremely efficient. After reading these Operating Instructions, operating the appliance will be easy. Before being packaged and leaving the manufacturer, the appliance was thoroughly checked with regard to safety and functionality. Before using the appliance, please read these Operating Instructions carefully By following these instructions carefully you will be able to avoid any problems in using the appliance. -
Page 3: Table Of Contents
TABLE OF CONTENTS Basic Information....................2 Safety instructions....................4 Description of the appliance................10,11 Specification..................10,11 Installing (instructions for the installer)...............12 Operation.........................19 Cleaning and maintenance..................23 Troubleshooting.....................24... -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS FOR USE Note.The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concern-... - Page 5 SAFETY INSTRUCTIONS FOR USE ● This appliance must be installed in accordance with the applicable regulations and used only in a well-ventilated room. Before you install and use the appliance, carefully read the operating instructions. ● Children shall not play with the appliance. Hot burners, grids, pots with hot liquids may cause burns to children.
- Page 6 SAFETY INSTRUCTIONS FOR USE ● IF YOU SUSPECT A GAS LEAK, DO NOT: light matches, smoke, turn on or off any electrical devices (door bell, light switch, etc.) and use other electrical or mechanical equipment that can produce an electrical or impact spark. In such a case, immediately close the valve on the gas cylinder or the gas system shut-off valve, ventilate the room and call a qualified person to remove the cause of the leak.
- Page 7 SAFETY INSTRUCTIONS GAS & ELECTRICAL CONNECTION Please refer to installation instructions for the Gas & Electrical Safety Regulations and the Ventilation Requirements. In your own interest, and that of safety, it is the law that all gaś appliances be installed by competent persons, who will ensure that the installation is in accordance with „The Gas Safety (Installation &...
- Page 8 HOW TO SAVE ENERGY Using energy responsibly not only saves money but also helps the environment. So let’s save energy! And this is how you can do it: ● Use proper pans for cooking. Pans with thick, flat bases can save up to 1/3 on electric energy.
- Page 9 DISPOSAL OF THE APPLIANCE UNPACKING The appliance was packed In accordance with European to protected it from damage Directive 2012/19/UE and Pol- during of transport. After ish legislation regarding used unpacking, please dispose electrical and electronic goods, of all elements of packaging this appliance is marked with in a way that will not cause the symbol of the crossed-out...
-
Page 10: Description Of The Appliance
DESCRIPTION OF THE APPLIANCE Gas hob PAG 4.1* 1,2,3,4 - top burners 5 - burner knobs with igniter switch 6 - grids SPECIFICATION height 52 mm depth 520 mm width 590 mm weight of the appliance 10,5 kg The appliance is equipped with burners: 1 - wok burner, heat load - 2.8 kW 2 - medium large burners, heat load... - Page 11 DESCRIPTION OF THE APPLIANCE Gas hob PAG 5.0* 1,2,3,4,5 - top burners 5 - burner knobs with igniter switch 6 - grids SPECIFICATION height 52 mm depth 520 mm width 890 mm weight of the appliance 15 kg The appliance is equipped with burners: 1 - large burner, heat load - 2.8 kW 2 - wok burner, heat load...
-
Page 12: Installing (Instructions For The Installer)
INSTALLING Ventilation Requirements Before you start: Please read the instructions. Planning your installation will save you time The room containing the appliance sho- and effort. uld have an air suppły in accordance with BS5440: Part2: 1989: Prior to installation, ensure that the local distribution conditions (nature of the gas l Ali rooms require an openable window, or and gas pressure) and the adjustment of the... - Page 13 INSTALLING The following instructions are intended for a qualified professional installer. These instructions are intended to provide the most professional installation and maintenance of the appliance. l Before you install the appliance, make sure that the local distribution conditions (gas type and pressure) and the appliance configuration is appropriate. l Configuration details are given on the appliance nameplate.
- Page 14 INSTALLING Install gas hob ● prepare an opening in the worktop of a kitchen cabinet, as per the installation drawing ● Ensure a minimum clearance of 130 mm below the gas or gas-electric hob. ● connect the hob to a gas and electrical system in accordance with the instructions supplied, ●...
- Page 15 INSTALLING The appliance has an G 1/2" threaded pipe Tips for the installer connector to connect it to the gas system. The LPG (propane-butane) hob version has The installer must: the connector terminated with a hose tip ● Have appropriate qualification ∅...
- Page 16 INSTALLING Adapt the hob to a particular type of gas This may be performed by an installer with the appropriate qualifications only. If the gas, which the hob will be supplied with is different from the gas type specified by the manufacturer, i.e.
- Page 17 INSTALLING SOMIPRESS burner. (indicated "SOMIPRESS." on the burner body) Burner auxiliary medium large Type of gas 0,72 0,98 1,17 0,55 + 2 x 0,75 G20 2H 20 mbar G30/31 3+ 28-30/37 mbar 0,52 0,67 0,83 0,37 + 2 x 0,55 Once converted, place a sticker indicating the gas type for which the appliance is intended.
- Page 18 INSTALLING In order to check the flame, heat up the burner Adjust the valves on a full flame for about 10 min., and then turn the burner knob to an economic flame To adjust the valves turn the burner knob to position.
-
Page 19: Operation
OPERATION Cookware lid: Burner operation Lid prevents heat from escaping and thus reduces heating time. To achieve significant energy savings, use the appliance as instructed in these operating instructions, make the appropriate adjustments and use suitable pots. Do not use cookware that protrude Potential energy savings: over the edges of the hob. - Page 20 OPERATION Using the hob equipped with igniter knobs Repeat the above step if flame does ("Zp" model) not ignite. If flame is extinguished, the flame- ● push down the knob of a selected burner failure device will cut off gas supply until you feel resistance and turn left to within about 60 seconds.
- Page 21 OPERATION Adjust flame Flame from a properly adjusted burner is pale blue with a clearly outlined inner cone. You can adjust flame by setting the knob to different positions. large flame small flame ( "economic") lburner off (no gas supply) INCORRECT CORRECT This example shows you and to operate the...
- Page 22 OPERATION In the event a gas leak risk 1 gas system 2 gas system shut-off valve A valve "open" B valve "closed" In the event of a fault ● turn off the burners ● close the gas system shut-off valve ●...
-
Page 23: Cleaning And Maintenance
CLEANING AND MAINTENANCE Make sure that burner is correctly re- Proper routine maintenance and cleaning assembled after cleaning. of the appliance can significantly extend its trouble-free operation. CORRECT B e f o r e c l e a n i n g o r o t h e r maintenance work, always unplug the appliance or use the main electrical system circuit breaker... -
Page 24: Troubleshooting
TROUBLESHOOTING In the event of any fault: ● turn off the appliance ● disconnect the power supply ● have the appliance repaired ● based on the instructions given in the table below, some minor issues can be corrected by the user. Please check the consecutive points in the table before you refer the repair to customer service. - Page 28 Service Help Line 0844 815 8880 For the UK: please call 0818 46 46 46 For Ireland: please call...
