Stop the mower blades on the mower if the tow vehicle becomes stuck or stops going
forward because of loss of traction. Shut off the engine on the mower before
attempting to push or pull the tow vehicle.
Inspect the ATV Tongue Assembly and tow vehicle hitch before each use. If any
parts of the tongue or hitch look damaged or severely worn, discontinue use of the
mower until the damaged or worn parts are replaced.
Engine exhaust contains carbon monoxide. Do not run engine indoors or in a small
confined area where dangerous carbon monoxide fumes can collect.
Wear hearing protection when operating this mower.
Engine components and exhaust can develop excessive heat. Keep the mower
clean of debris and other flammable material to avoid fires.
Follow all safety precautions outlined by the manufacturer of the tow vehicle being
used to pull this product.
Listen to the rough cut mower engine while mowing. The engine should run free and not work too
hard. Working the engine too hard will cause overheating and premature failure.
If the mower's engine dies while in use, remove the rough cut mower from the uncut
area before attempting to engage the clutch. Inspect the blades for any obstructions
that may prevent blade engagement. Failure to follow these instructions may result
in premature belt failure or a fire.
Do not allow material to build up on the air inlet to the engine cooling system. Special care should
be taken to make sure the engine is getting enough inlet air. Do not allow the engine cooling fins
under the shroud to be blocked. If air flow over the engine is restricted, the engine could
overheat.
A. DRIVE BELT REMOVAL AND TENSION – Refer to Figure 7
Shut off engine and allow mower blades to stop turning before making any
adjustments or repairs.
Remove the safety shields.
Loosen the nuts on the spring-loaded idler; adjust bolt until the belt can be slipped off the idler and
drive sheaves.
Slip the belt down under the drive sheave and off the blade spindle sheaves.
