- Page 1 57” ROUGH CUT WITH ELECTRIC CLUTCH BLADE ENGAGEMENT OWNER’S MANUAL With Assembly Instructions For Model: MR55KE KUNZ ENGINEERING, INC. MENDOTA, IL 613 PH (815) 539-6954 1/09...
-
Page 2: Safety Introduction
SAFETY INTRODUCTION Your safety, and the safety of others, is very important. To help you make informed decisions about safety, we have provided operating procedures and other information on labels and in this manual. This information alerts you to potential hazards that could hurt you or others. -
Page 3: Important Safety Information
IMPORTANT SAFETY INFORMATION WARNING: Do not allow anyone to operate this equipment who has not fully read and comprehended the safety manual and who has not been properly trained in the safe operation of the equipment. WARNING: Operator should be familiar with all functions of the unit. DANGER: Keep hands, feet, hair and clothing away from moving parts. - Page 4 275002 – Warning Decal, General Serial # and Model # Decal Clean or R eplace Any Safety Signs That Are not Readable or Damaged Replacement decals can be purchased from your local dealer or Kunz Engineering Inc. Mendota, IL 61342 (815) 539-6954...
-
Page 5: Assembly Instructions
ASSEMBLY INSTRUCTIONS Read the complete assembly instructions before starting the assembly. You should have: - one mower deck assembly - two carrier arm assemblies - two rear tire assemblies - one ATV tongue assembly A. ASSEMBLY OF MOWER WHEELS 1. Set the mower deck assembly on wood blocks so that it is suspended off the ground. Note: The operator controls are on the front of the deck. - Page 6 rrier Arm Rear Tire Bolt sembly Hex Nut and Lock Washer Cup Washer Flat Washer Figure 1: Rear Tire Assembly Installation Hitch Pivot – Attach to Tongue Height Adjust Either Left or Right Screw Carrier Arm Assy. Front (Rubber Flap Side) Rear Tire As Carrier Arm (Attach on outside for...
- Page 7 Direction of Travel Screw Pin Shackle Clevis Shift Tong ue Left or Right Between Hol Tongue 5/16” Wire Lock Pins Wire Lock Section of Wire Lock Pin (Placed Back From Direction of Travel) Figure 3: ATV Tongue Assembly OPERA TIONS AND ADJUSTMENTS This safety alert symbol is used to indicate safety instructions.
- Page 8 The tongue is equipped with a screw pin shackle clevis to provide movement in all directions on rough uneven ground. To prev ent loss of the screw pin due to vib ration or debris, place the screw pin through the tow vehicle hitch and clevis and turn the screw pin until snug. The tongue is designed to adjust from left to right within the hitch pivot.
- Page 9 The cutting height can be adjusted in a range from 2.0" to 8.0". This is accomplished by turning the height adjust cranks on both sides of the mower. See Figure 5. Turn the cranks clockwise to raise the mower cutting height and counter-clockwise to lower the mower cutting height. DANGER: Shut off tow vehicle engine and allow mower blades to stop completely before attempting to measure the cutting height.
- Page 10 C. START ING ENGINE WARNING : Set parking brake on tow vehicle. Attach mower tongue to tow vehicle. WARNING: Do not start rough cut mower unless it is attached to the tow vehicle. n on fuel shut off valve which is located on the underside of the gas tank.
- Page 11 MOWER OPERATION DANGER: Keep hands, feet, hair and clothing away from moving parts. CAUTION: Clean or replace any safety signs that are not readable or damaged. WARNING: Remove all object s from the work area that might be picked up and thrown by the blades.
- Page 12 Do not allow material to build up on the air inlet to the engine cooling system. Special care should be taken to make sure the engine is getting enough inlet air. Do not allow the engine cooling fins under t he shroud to be blocked.
- Page 13 The Model MR55KE uses the Kunz Engineering Part # (202141) blade bolt. This particular hex head bolt is a 3/4” – 16NF x 1-1/4” long, grade 5 and it’s proper torque is 300 ft-lbs.
- Page 14 ACREASE ROUGH CUT MOWER SPECIFICATIONS Model MR55KE ENGINE: Engine Make Kohler Engine Model Command OHV CV20 Cylinders Cycles Crank shaft Vertical Engine HP Bore 3.03" Stroke 2.64" Di lacement 38.1 cubic inches Oil Ca pacity 2 U.S. qts. Crank shaft Dia. 1"...
- Page 15 Control Panel Decal, Starting Instructions 275002 Warning Decal General 275003 Danger Decal, Cut Finger 275007 Warning Decal, Belt Sheild 275019 Name Decal, Kunz 275021 Name Decal, AcrEase 275022 Name Decal, 57" Rough Cut 277002 Rubber Gromet 277010 Fuel Tank, 3.75 Gal. (Plastic)(Use Gas Cap 277013)
- Page 16 Click on part numbers for pricing and ordering information from www.jsesc.com Item Part # Description Quantity 00049 Battery Box Assy. 900058 Hitch Pivot 900061 Pivot Arm 900062 Height Adjust Nut 900066 Screw Adjuster 900069 Mower Deck 600172 Engine Support Bracket 900079 Tank Support 900082...
- Page 17 A CREASE ROUGH CUT MOWER PARTS...
-
Page 18: Optional Equipment
OPTIONAL EQUIPMENT OPTIONAL WETLANDS KIT The optional wetlands kit features an extra set of tires for added ground support in soft or water saturated areas. The following are applications and features that the wetlands kit works best in. • Great for wetlands or marshy areas that stay wet all year around. •... - Page 19 OPTIONAL EQUIPMENT TIONAL ELECTRIC LIFT KIT The optional electric lift kit consists of all of the mounting hardware, brackets, electric actuator an wiring with remote control panel. • Great for constantly changing terrain and grass/brush heights. • Allows for quick cutting height changes on the go from the seat of the tow vehicle. •...
