Guidance and Manufacturer's Declaration-Electromagnetic Emissions
Guidance and Manufacturer' s declaration - electromagnetic emission.
The Pulse Oximeter is intended for use in the electromagnetic environment specified below.
The customer or the user of the Pulse Oximeter should assure that it is used in such an environment.
Emission Test
RF Emissions CISPR11
RF Emissions CISPR11

Technical Specifications

Display Type: OLEO Display
SP02 display range: 70-100%
PR Display Range: 30-235 BPM
PR Display Mode: Bargraph
Data Update Time: < 15 s
LED Wavelengths
Red: 660nm
Infrared: 940nm
Measurement range:
SP02: 70-100% - 100% ±3%; s 70%
Pulse Rate: 30-235 BPM, ±2 bpm during the
Accuracy: ±2% on the stage of 80%-100%
Accuracy: ±2 BPM or ±2% (larger)
Pulse Intensity: Bargraph Indicator
Power Requirements: Two AAA alkaline Batteries
Power consumption: Less than 40mA

Standards

Declaration: EMC of this product comply with IEC60601-1-2 standard.
Measurement Performance in Low Perfusion Condition: required the test equipment (BIO-TEK INDEX Pulse Oximeter tester) the pulse wave is
available without failure when the simulation pulse wave amplitude is at 6%.
Interference Resistance Capacity against Ambient Light: Device works normally when mixed noise produced by BIO-TEK INDEX Pulse Oximeter
tester.
Compliance Level
Electronic Environment Guidance
The PULSE OXIMETER uses RF energy only for its internal function. Therefore, its
Group 1
RF emissions are very low and are not likely to cause any interference in nearby
electronic equipment.
The PULSE OXIMETER is suitable for use in all establishments.including domestic
Class B
establishments and those directly connected to the public low-voltage power
supply, network that supplies buildings used for domestic purposes.
no definition
pulse rate range of 30-99 bpm
and ±2% during the pulse rate
range of 100-235 bpm.
±3% on the stage of 70%-79%
Low power indication:
Battery Life: (2) "AAA" 1.5V, 600mAh alkaline
Dimension:
Length: 1.9" (50mm)
Width: 1.1" (28mm)
Height: 1.1" (28mm)
Weight: 1.2 - 1.?oz. (35 - 50g) (Including
Environment:
Operation Temperature: 41
Storage Temperature: -4
Relative Humidty: 15%-80% in operation/ 10%-
Finger Range: .3" - .44" (7.64mm-11.19mm)
�
batteries could be continuously
operated as long as 30 hours.
2 AAA batteries)
° ° ° °
F- 104 F (5 C - 40 C)
° ° ° °
F- 131 F (-20 C - 55 C)
80% in storage
