Summary of Contents for Coredy R380

  • Page 1 Owner’s Manual...

  • Page 2: Table Of Contents

    2.6 LED Indication........................ Operating and Programming 3.1 Notes Before Cleaning ....................3.2 Quick Start ........................3.3 Use Your R380 with the “Coredy Robot” APP ............3.4 How Coredy R380 Cleans Your Home ..............3.5 Floor Mopping Cleaning ....................3.6 Cleaning Schedule .......................

  • Page 3: Important Safety Information

    Cleaning and user maintenance shall not be touched by children without supervision. The robot must be used in accordance with the directions of this Instruction Manual. Coredy Inc cannot be held liable or responsible for any damages or injuries caused by improper use.

  • Page 4: Battery And Charging

    1.2 Battery and Charging Use only rechargeable battery packs with the correct specification approved by Coredy. To use a standard outlet for charging only, the product may not be used with any type of power converter. Use of other power converters will immediately void the warranty.
  • Page 5 Before every use, check the battery pack for any sign of damage or leakage. Do not charge damaged or leaking battery packs. If the battery pack were leaking, please don’t hesitate to contact Coredy. The battery pack must be removed from the robot before disposal.

  • Page 6: Product Diagram

    Indicator Lights or Blinks Red: Troubleshooting Indicator Blinks Rapid Green: Wi-Fi Pairing Mode Dock Button To send R380 Robot back to the Charging Dock, press on robot or press on Remote Control. Power On / Off Press to start / stop cleaning...
  • Page 7 Middle Cover Dust Bin Bumper Remote Control Receiver Anti-Collision Sensors Surface Case Anti-Drop Sensors Charging Contacts Universal Wheel Side Brushes Battery Pack Suction Channel Dust Scraping Driving Wheels Power Switch Bottom Case...

  • Page 8: Accessories

    2.2 Accessories 1 x Charging Dock 1 x Adapter 1 x Remote Control (With 2 x AAA Batteries) 1 x Dust Bin 1 x High Efficiency Filter 4 x Side Brushes 1 x Water Tank (Sold Separately) 1 x Mop Cloth and Holder (Sold Separately) 1 x Cleaning Brush...

  • Page 9: Charging Dock

    2.3 Charging Dock Charging Indicator Location for Remote Control Signal Transmission Area Charging Contacts...

  • Page 10: Remote Control

    2.4 Remote Control Display Screen Automatic Cleaning Automatic Re-charging Button Direction Buttons Start / Pause Button Clock Setup Button Scheduling Button Spot Cleaning Button Edge Cleaning Button Small-space Button Lower Suction Cleaning Button Three Optional Suction Level...

  • Page 11: Dust Bin

    2.5 Dust Bin Handle Dust Bin Cover Primary Holder Dust Bin High Efficient Filter High Efficient Filter Frame...

  • Page 12: Led Indication

    2.6 LED Indication You can see the status of Coredy R380 Robot from the LED indicators. Lights Status Status Solid green Standby / Cleaning / Fully charged / Wi-Fi connected Rapidly flashing green Wi-Fi pairing mode (EZ) Slowly flashing green...

  • Page 13: Operating And Programming

    3 Operating and Programming 3.1 Notes Before Cleaning Before using this device, pick up the objects scattering on the floor, including but not limited clothes and important papers, curtains, cords. If the room to be cleaned contains a balcony that a physical barrier should be used to separate from the balcony and ensure safe operation.

  • Page 14: Quick Start

    Install Side Brushes Note: Failure to place the remaining wire into the trunking, may cause Robot to Attach Side Brushes to the bottom of Coredy R380 by pressing become stuck while charging or cleaning. a brush into each slot until clicked.
  • Page 15 Charging Dock to recharge. Note: The actions listed above, you can also manage to do in Coredy App. If the Charging Dock is inaccessible, Robot will not be able to recharge, please place the robot manually on Charging Dock for charging.

  • Page 16: Use Your R380 With The "Coredy Robot" App

    3.3 Use Your R380 with the “Coredy Robot” APP To enjoy all available features, it is recommended to control your Robot via the Coredy Robot App. Scan the QR code as below or from the App Store (iOS devices) or Google Play (Android devices).
  • Page 17 Create A User Account 1. Open the App and create 2. Agree to the "Privacy Policy". 3. Create your account with the 4. Enter verifica�on code. mobile phone number or E-mail a user account. address.
  • Page 18 Add Device Wi-Fi Connec�on 1. Check and set your phone 1. Press “Add Device” or “+” on 2. Add a Coredy R380 Robot 5. Set your password with Wi-Fi se�ng first, then select the upper right corner for next. to your Coredy account.
  • Page 19 2. Turn on the main power 3. Wait for the connec�on 4. Device added successfully, 5. Wait 1-2 seconds for the then press“Done”. switch on the bo�om of the progress to reach 100%. Robot to go on standby. Robot, then press and hold &...
  • Page 20 "Alexa, turn on Coredy R380" "Alexa, turn off Coredy R380" 6. If you add two or more Robot devices to Coredy Robot App, you can edit name for each Coredy Robot in either the Coredy App or Alexa App. A�er named, give commands by saying the Robot name.
  • Page 21 (Note: Only supports the commands above word for word presently.) Repeat your ques�on. Speak naturally and clearly to Alexa. 5. If you add two or more Robot devices to Coredy Robot App, you Make sure your Coredy device is at least eight inches away from...

  • Page 30: Cleaning Robot's Side Brush

    4.4 Cleaning Robot’s Side Brush Wipe the charging contacts on Robot and the Charging Base with a clean, dry cloth. Remove the brush. Clean the brush and the brush stand, and reinstall the brush. 4.5 Cleaning Robot’s Cliff Sensors and Charging Contacts Wipe Robot’s Cliff Sensors with a clean, dry cloth.

  • Page 31: Cleaning Robot's Floor Tracking Sensor

    4.6 Cleaning Robot’s Floor Tracking Sensor Use a clean, dry microfiber or soft cotton cloth to wipe any debris accumulated in the round sensor that can be opened on the right side of the bottom surface. Do not spray cleaning solution directly into the sensor entrance.

  • Page 32: Battery And Charging Information

    If storing robot off of the Charging Dock, remove the battery first. Then store robot and the battery in a cool, dry place. Battery Disposal Contact your local waste management authority for battery recycling and disposal regulations in your area. Battery Replacement You can visit Coredy’s website http://shop.coredy.com to purchase the battery or other accessories for the robot.
  • Page 33 Battery Removal Reinstall the battery with the battery label and tabs facing up. Follow these instructions to remove and reinstall robot’s battery: Unscrew two screws on the battery door, then remove the door. Reinstall the battery door and the two screws. Take care not to pinch the side brush in the battery door when re-installing the battery.

  • Page 34: Troubleshooting

    5 Troubleshooting Robot will tell you something is wrong with a two-tone distress sound followed by message. The indicator will also blink or illuminate red. Refer to the chart as below to resolve Robot’s problem. If the problem is not resolved, please contact our COST FREE customer service team for more assistance.
  • Page 35 Indicator Flashing Red Robot Blinks and Sounds Likely Cause What to Do Tap robot's bumper several times to dislodge any debris that might be trapped underneath. Two beeps Robot's bumper is stuck. Press robot's bumper 5-10 times to ensure bumper contracts freely. Clean robot's cliff sensors gently with a dry cloth.
  • Page 36 Dust off the charging contact pins with a dry cloth. be charged. Check if you can hear a beep when Coredy R380 is docked onto the Charging Base. If not, contact the Coredy Customer Care to repair or replace the Charging Base.
  • Page 37 Remove objects within 3ft/1m to the left and right side and within 6ft/2m of the front of the Charging Base. Coredy R380 cannot When Coredy R380 is in the vicinity of the Charging Base (distance within 26ft/8m), it returns more quickly. return to the Charging However, if the Charging Base is located far away (distance over 26ft/8m), Coredy R380 needs more time to Base.

  • Page 38: Wi-Fi Connection

    - The FCC requires that all wireless devices in the United States operate on the 1-11 wireless spectrum channels. - Coredy R380 Robot is fully charged and the main power switch on the bottom of Coredy R380 Robot is turned on.

  • Page 39: Specifications

    7 Specifications Product Model R380 Input 19 V 0.6 A Battery Voltage DC 14.4 V Power Consumption 28 W DC 14.4 V Battery Type Li-ion 2600 mAh Dust Collector Capacity 0.3 L Cleaning Time Max. 110 mins Charging Time 180-240 mins...
  • Page 40 MODEL: R380 US COST FREE Tech Support: UK COST FREE Tech Support: E-mail: support@coredytech.com +44 (808) 134 9909 +1 (800) 999 8470 Website: http://shop.coredy.com (PST Mon-Sun 06:00-24:00) (GMT Mon-Sun 14:00-08:00) @CoredyOfficial @CoredyOfficial @coredy_robotvacuum @Coredy Official V1.0...
