Before driving Introduction Instrumentation Controls and features Seating and safety restraints Starting and driving Starting Driving Roadside emergencies Servicing Maintenance and care Capacities and specifications Customer assistance Reporting safety defects Index All rights reserved. Reproduction by any means, electronic or mechanical including photocopying, recording or by any information storage and retrieval system or translation in whole or part is not permitted without written authorization from Ford Motor Company.
Page 2: Introduction
Introduction The following warning may be required by California law: CALIFORNIA Proposition 65 Warning WARNING: Engine exhaust, some of its constituents, and certain vehicle components contain or emit chemicals known to the State of California to cause cancer and birth defects or other reproductive harm.
Page 3: Breaking-In Your Vehicle
Introduction BREAKING-IN YOUR VEHICLE There are no particular breaking-in rules for your vehicle. During the first 1 600 km (1 000 miles) of driving, vary speeds frequently. This is recommended to give the moving parts a chance to break in. INFORMATION ABOUT THIS GUIDE The information found in this guide was in effect at the time of printing.
Page 4 Introduction These are some of the symbols you may see on your vehicle. Safety Alert Fasten Safety Belt Air Bag-Side Child Seat Installation Warning Brake System Brake Fluid - Non-Petroleum Based Master Lighting Switch Fog Lamps-Front Fuel Pump Reset Windshield Defrost/Demist Power Windows Front/Rear...
Page 5 Child Safety Door Lock/Unlock Panic Alarm Engine Coolant Do Not Open When Hot Avoid Smoking, Flames, or Sparks Explosive Gas Power Steering Fluid Emission System Passenger Compartment Air Filter Check fuel cap Vehicle Symbol Glossary Interior Luggage Compartment Release Symbol Engine Oil Engine Coolant Temperature...
Page 6: Instrumentation
Instrumentation Turn signal and wiper/washer control (pg. 73) Headlamp control (pg. 27) Autolamp control (pg. 29) Instrument cluster (pg. 8) TRIP kmiles Speed control (pg. 77) Driver air bag (pg. 122) BRAKE...
Page 7 Instrumentation Audio system Message Center* (pg. 42) Dual Automatic (pg. 17) Temperature Control system (pg. 31) Heated seat controls Electronic sound (pg. 107) system control (pg. 75) * if equipped...
Page 8: Warning Lights And Chimes
Instrumentation WARNING LIGHTS AND CHIMES TRIP kmiles Engine coolant temperature Illuminates when the engine coolant temperature is high. Stop the vehicle as soon as safely possible, switch off the engine and let it cool. Never remove the coolant recovery cap while the engine is running or hot.
Page 9 malfunctioning. The light may illuminate without a driveability concern being noted. The vehicle will usually be drivable and will not require towing. What you should do if the check engine light illuminates Light turns on solid: This means that the On Board Diagnostics System system has detected a malfunction.
Page 10 Instrumentation the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with the parking brake released. Turn signal Illuminates when the left or right turn signal or the hazard lights are turned on.
Page 11 Instrumentation Engine oil pressure Momentarily illuminates when the ignition is turned to the RUN position and the engine is off. Illuminates when the oil pressure falls below the normal range. Stop the vehicle as soon as safely possible and switch off the engine immediately.
Page 12 Instrumentation Low washer fluid (if equipped) Illuminates when the ignition is turned to RUN and when the windshield washer fluid is low. Bulb Warning (if equipped) Illuminates when the ignition is in the RUN position and one of the exterior bulbs has burned out. Traction Control active Flashes when the Traction Control...
Page 13 Speed control This light comes on when the vehicle speed control is engaged and actively controlling the vehicle speed. It turns off when the speed control OFF or CANCEL controls are pressed or the brake is applied. Door ajar (if equipped) Illuminates when the ignition is in the RUN position and any door or the trunk is open.
Page 14 Instrumentation If an “E” character is displayed, this indicates a transmission malfunction. If the “E” character flashes or remains on, contact your dealer immediately. Operating the transmission with the “E” character illuminated may cause additional damage to the transmission. Headlamps on warning chime Sounds when the headlamps or parking lamps are on, the ignition is off (and the key is not in the ignition) and the driver’s door is opened.
Page 15 GAUGES TRIP kmiles Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the center of the gauge. If it enters the “H” (hot) section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine immediately and let the engine cool.
Page 16 Instrumentation Tachometer Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine. BRAKE Speedometer Indicates the current vehicle speed. Fuel gauge Displays approximately how much fuel is in the fuel tank (when the key is in the RUN position).
Page 17: Message Center (If Equipped)
Odometer Registers the total kilometers (miles) of the vehicle. Trip odometer Registers the kilometers (miles) of individual journeys. To reset, depress the control. To switch the display from Trip A to the Trip B feature, depress the A/B control. MESSAGE CENTER (IF EQUIPPED) With the ignition in the RUN position, the message center, located on your instrument cluster,...
Page 18 Instrumentation SETUP Press this control for the following displays: Language Units (English/Metric) Autolocks Easy Entry/Exit (if equipped) Lock Chirp (if equipped) STATUS Selecting this function from the STATUS control causes the message center to cycle through each of the systems being monitored. For each of the monitored systems, the message center will indicate either an OK message or a warning message for four seconds.
Page 19 under normal driving conditions. Remember to turn the ignition OFF when refueling your vehicle. Otherwise, the display will not show the addition of fuel for a few kilometers (miles). The DTE function will display LOW FUEL LEVEL and sound a tone for one second when you have 80 km (50 miles) to empty.
Page 20 Instrumentation 3. Press the RESET control to clear the system memory. Actual highway fuel economy is now displayed. This current average measure will change as the speed control system changes the engine speed to maintain a constant vehicle speed. This is most noticeable in hilly environments.
Page 21 Autolocks 1. Select this function from the SETUP control for the current display mode. 2. Press the RESET control to turn the autolocks ON or OFF. Easy entry/exit (if equipped) 1. Select this function from the SETUP control for the current display mode.
Page 22 Instrumentation Warnings Engine power reduced Pull off road safely Turn off ignition Driver’s door ajar Passenger door ajar Driver rear door ajar Passenger rear door ajar Check engine temp Check charging system Transmission overheated Check transmission Low fuel level Check fuel cap Low brake fluid level Check tail lamps Check brake lamps...
Page 23 Instrumentation TURN OFF IGNITION. Displayed when the engine is overheating. Turn off the engine. If this warning stays on, contact your dealer as soon as possible. DRIVER’S DOOR AJAR. Displayed when the driver’s door is not completely closed. PASSENGER DOOR AJAR. Displayed when the passenger side door is not completely closed.
Page 24 Instrumentation CHECK FUEL CAP. Displayed when the fuel filler cap is not properly installed. Check the fuel filler cap for proper installation. Refer to Fuel Filler Cap in the Maintenance and care chapter. LOW BRAKE FLUID. Indicates the brake fluid level is low and the brake system should be inspected immediately.
Page 25 Instrumentation LOW WASHER FLUID. Indicates the washer fluid reservoir is less than one quarter full. Check the washer fluid level. Refer to Checking and adding washer fluid in the Maintenance and care chapter. CHECK AC (cabin) FILTER. Displayed when the A/C cabin filter life remaining is 5 percent or less.
Page 26 Instrumentation 2. Press and hold the RESET control to set to 100%. 3. After a successful reset, the message center will display OIL LIFE SET TO 100%. To reset the oil monitoring system to your personalized oil life %: 1. Press the STATUS control to access the System Check function.
Page 27: Headlamp Control
HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Daytime running lamps (DRL) (if equipped) Turns the highbeam headlamps on with a reduced output. To activate with automatic transmission: the ignition must be in the RUN position;...
Page 28 Controls and features High beams Pull toward you until control stops to activate. Control will return to original position. Repeat to deactivate. Flash to pass Pull toward you to activate and release to deactivate. Foglamp control The headlamp control also operates the foglamps.
Page 29: Panel Dimmer Control
AUTOLAMP CONTROL The autolamp system provides light sensitive automatic on-off control of the exterior lights normally controlled by the headlamp control. The autolamp system also keeps the lights on for a preselected period of time after the ignition switch is turned to OFF.
Page 30 Controls and features 2. Move the control in the direction you wish to tilt the mirror. 3. Return to the center position to lock mirrors in place. Heated outside mirrors Both mirrors are heated automatically to remove ice, mist and fog when the rear window defrost is activated.
Page 31: Fuel Door Release
Controls and features FUEL DOOR RELEASE Press the remote fuel door release control on the instrument panel to open the fuel door. The fuel door has a manual override release located in the trunk. Pull the tab to open the fuel door. CLIMATE CONTROL SYSTEM Dual Automatic Temperature Control (DATC) system AUTO...
Page 32 Controls and features Turning the DATC system on AUTO Press AUTO, any of the override controls, the fan speed control, or either of the temperature selection controls. The DATC system will only operate when the ignition is in the RUN position. Turning the DATC system off Press OFF.
Page 33 Controls and features engine is not warm enough to provide heat, the fan will operate at a low speed and the airflow will be directed to the windshield or to the floor. In 3 ⁄ minutes or less, the fan speed will start to increase and the airflow location will change to the floor area.
Page 34 Controls and features To control the temperature, select any temperature between 19°C (65°F) and 29°C (85°F) by pressing the temperature control on the driver side of the system. For continuous maximum cooling, press the temperature control until 16°C (60°F) is shown in the display window. The DATC will continue maximum cooling (disregarding the displayed temperature) until a warmer temperature is selected by pressing the temperature control.
Page 35 Controls and features Temperature conversion Press the Fahrenheit/Celsius (°F °C) control to switch between Fahrenheit and Celsius temperature on the DATC display only. The set point temperatures in Celsius will be displayed in half-degree increments. The English/Metric control on the AUTO trip computer and message center (if equipped) will not change the...
Page 36 Controls and features AUTO A/C control (air conditioning) — Used to manually enable or disable the operation of the air conditioning in all modes except defrost. In all modes, the air conditioning will only function if the outside temperature is about 2°C (35°F) or higher. When manual A/C is selected (ON) the indicator will be lit.
Page 37 Controls and features AUTO Recirculation control (air recirculation) — Used to manually enable or disable the operation of the recirculated air operation in all modes except defrost. The use of recirculated air when the air conditioning is operating helps to reduce the amount of time to cool down the interior of the vehicle in very hot conditions.
Page 38 Controls and features Manual override controls AUTO The manual override controls allow you to manually determine where airflow is directed. To return to fully automatic control, press AUTO. When a manual airflow override control is selected, the DATC system will turn off the AUTO indicator and display the indicators of all operating override controls.
Page 39 When floor/defrost is selected, if the outside temperature is about 2°C (35°F) or higher, the air conditioner will automatically dehumidify the air to reduce window fogging. For added customer comfort, the air distributed through the floor ducts may be slightly warmer than the air sent to the windshield defroster ducts.
Page 40 Controls and features Displaying outside temperature AUTO Press EXT to display the outside air temperature. It will remain selected until the EXT control is pressed again. If the driver or passenger temperature or the fan speed is changed, or the AUTO or modes selected while the outside temperature is displayed, the driver and passenger temperature display will be displayed for 4 seconds.
Page 41 Remove any snow, ice or leaves from the air intake area at the base of the windshield. If your vehicle has been parked with the windows closed during hot weather, the air conditioner will do a much faster job of cooling if you drive for two or three minutes with the windows open.
Page 42: Using Your Audio System
Controls and features With the ignition in the OFF position after operating the vehicle, some vehicle sounds related to the climate control system may be heard. Approximately two minutes after key off, the air distribution doors may adjust their positions as part of the normal operating process. To aid in side window defogging: 1.
Page 43 Premium AM/FM Stereo/Cassette PUSH ON MUTE Alpine Audio System with AM/FM Stereo/Cassette VOLUME PUSH ON MUTE Volume/power control Press the control to turn the audio system on or off. TAPE SEEK SIDE 1-2 TAPE SEEK SIDE 1-2 Controls and features BASS TREB FADE...
Page 44 Controls and features Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on. Speed sensitive volume With this feature, radio volume changes automatically and slightly with vehicle speed to compensate for road and wind noise.
Page 45 AM/FM select in tape mode Press this control to stop tape play and begin radio play. AM/FM select in CD mode (if equipped) Press this control to stop CD play and begin radio play. Tune adjust The tune control works in radio or CD mode (if equipped). Tune adjust in radio mode Press to move to the next...
Page 46 Controls and features Seek function in tape mode Press to listen to the previous selection on the tape or return to the beginning of the current selection. Press to listen to the next selection on the tape. Seek function for CD changer (if equipped) Press to seek to the previous track of the current disc.
Page 47 Radio station memory preset The radio is equipped with six station memory preset controls. These controls can be used to select up to six preset AM stations and twelve FM stations (six in FM1 and six in FM2). Setting memory preset stations 1.
Page 48 Controls and features Bass adjust The bass adjust control allows you to increase or decrease the audio system’s bass output. Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers.
Page 49 To begin CD play (if CD[s] are loaded), press the CD control. The first track of the disc will begin playing. After that, CD play will begin where it stopped last. Rewind The rewind control works in tape and CD modes. In tape mode, radio play will continue until rewind is stopped (with the TAPE control) or the...
Page 50 Controls and features Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby reduces the amount of hiss and static during tape playback. Press the control to activate (and deactivate) Dolby noise reduction. Dolby noise reduction is manufactured under license from Dolby Laboratories Licensing Corporation.
Page 51 Radio data system (RDS) feature This feature allows your audio system to receive text information from RDS-equipped FM radio stations. Press the RDS control until the display reads RDS OFF. Press the SEL control to engage this feature (RDS ON). Once the RDS feauture is on, press the RDS control to scroll through the following selections: Traffic Press the RDS control until...
Page 52 Controls and features R & B Religious Rock Soft Top 40 Show With RDS activated, press the RDS control until SHOW is displayed. Use the SEL control to select TYPE, NAME or NONE. Phone/mute mode This feature allows you to control the factory-installed cellular phone (if equipped) through the radio controls.
Page 53 Use the SEL control to select the desired signal mode (the selected mode will appear in the display). The following signal modes can be selected: JAZZ CLUB—jazz club with clearly reflected sounds HALL—rectangular concert hall capacity of about 2 000 CHURCH—church with a high vault STADIUM—outdoor stadium with a capacity of about 30 000 NEWS—”voice-only”...
Page 54 Controls and features Alpine Audiophile AM/FM Stereo In-Dash Six CD Radio Alpine Sport Audio AM/FM Stereo In-Dash Six CD Radio Premium Alpine Audio AM/FM Stereo In-Dash Six CD Radio Premium AM/FM Stereo In Dash Six CD Radio...
Page 55 Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal” listening level when the ignition switch is turned back on.
Page 56 Controls and features Tune adjust in radio mode Press to move to the next frequency down the band (whether or not a listenable station is located there). Hold the control to move through the frequencies quickly. Press to move to the next frequency up the band (whether or not a listenable station is located there).
Page 57 Controls and features Scan function The scan function works in radio or CD mode. Scan function in radio mode Press the SCAN control to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to stop the scan mode.
Page 58 Controls and features Autostore Autostore allows you to set the strongest local radio stations without losing your original manually set preset stations. This feature is helpful on trips when you travel between cities with different radio stations. Starting autostore 1. Press and momentarily hold the AM/FM control. 2.
Page 59 Controls and features Display description Six circles are always lit in the digital display. These signify the six CD slots in the audio system. When a disc is loaded into a particular slot (1–6), the number inside that specific circle lights. If the circle is empty, there is no CD in that particular slot.
Page 60 Controls and features Eject Press the EJ control to stop and eject a CD. You can choose which CD will be ejected by pressing the EJ control and the desired preset number (1–6). For example, to eject CD#2, press the EJ control and then press the preset #2 control.
Page 61 When in fast forward mode, your audio system will automatically lower the volume level of the playing media. Shuffle feature Press the SHUF control until the desired shuffle mode is displayed. The audio system will then engage the desired shuffle mode. When engaged, the shuffle feature has two different modes: SHUFFLE DISC and SHUFFLE TRK.
Page 62 Controls and features Treble adjust The treble adjust control allows you to increase or decrease the audio system’s treble output. Press the TREB control. Use the SEL control to increase or decrease the amount of treble. Speaker balance adjust Speaker sound distribution can be adjusted between the right and left speakers.
Page 63 SHOW (NAME, TYPE, NONE)-Refer to Radio data system. RDS ON— Refer to Radio data system. SELECT HOURS — Refer to Setting the clock. SELECT MINUTES —Refer to Setting the clock. When in CD mode, you can access: SELECT HOURS, SELECT MINUTES or COMP ON/OFF.
Page 64 Controls and features When in this mode, traffic announcements will interrupt radio and CD play. Press the MENU control until TRAFFIC is displayed. Press the SEL control to engage the feature. The display will read TRAFFIC ON. This feature also allows you to control the volume of traffic announcements.
Page 65 Show This feature allows you to select the type of RDS broadcast information the radio will regularly show in the display. With RDS activated, press the MENU control until SHOW is displayed. Use the SEL control to select TYPE (displays the RDS program type: rock, jazz, etc), NAME (displays the name of the radio station) or NONE (deactivates the RDS display).
Page 66 Controls and features Press the DSP control again to access the occupancy modes. Use the SEL control to optimize the sound based upon the occupants in the vehicle. The following occupancy modes can be selected: ALL SEATS DRIVER SEAT REAR SEATS Phone mode This feature allows you to control the factory-installed cellular phone...
Page 67 Controls and features CD changer (if equipped) The CD changer is located in the glove compartment. Press to eject the magazine. 1. Pull the lever to remove a CD tray from the magazine. 2. Insert one disc into each CD tray of the magazine (up to 6 discs).
Page 68 Controls and features 3. Insert each CD tray, with the disc loaded, all the way into the CD magazine. 4. Insert the CD magazine into the changer. Use only compact discs containing this mark. Ensure that the disc is inserted label side up. The magazine does not need to be full for the changer to operate.
Page 69 If sound skips: You may be traveling on a rough road, playing badly scratched discs or the disc may be dirty. Skipping will not scratch the discs or damage the player. If your changer does not work, it may be that: A disc is already loaded where you want to insert a disc.
Page 70 Controls and features Tighten very loose tapes by inserting a finger or pencil into the hole and turning the hub. Remove loose labels before inserting tapes. Do not leave tapes in the cassette player for a long time when not being played.
Page 71: Removal/Installation Of Ashtray
Controls and features REMOVAL/INSTALLATION OF ASHTRAY Before removing and installing the ashtray, make sure the ignition is in the off position, and move the floor mounted automatic shifter from the park position. In order to prevent damage, follow these instructions when removing/installing the ashtray.
Page 72: Positions Of The Ignition
The master key will actuate the driver’s door, trunk, glove box and ignition. If equipped, the valet key (the key without the Lincoln logo) will actuate door and ignition only. Refer to the Securilock Passive Anti-Theft System section for more information on Securilock keys.
Page 73: Turn Signal Control
TURN SIGNAL CONTROL Push down to activate the left turn signal. Push up to activate the right turn signal. WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The ignition must be in the ACC or RUN position to operate the windshield wiper.
Page 74 Controls and features Moisture sensitive wipers (if equipped) When the windshield wiper control is set to INT and the intermittent position is AUTO, moisture sensitive front wipers automatically activate when moisture accumulates on the windshield. When the ignition is turned to Off and then back to Run and the wiper setting has remained in AUTO position, the wipers may cycle one time.
Page 75: Steering Wheel Controls
Controls and features During easy exit (if activated through the Message Center) operation, the column will move to the full in and up position. When the key is inserted into the ignition switch, the column will return to the previous setting.
Page 76 Controls and features In AM, FM1, or FM2 mode: Press to select preset stations within the selected radio band. In Tape mode: Press to select the next selection on the tape. In CD mode: Press to select the next selection on the CD. In any mode: Press VOL + or −...
Page 77: Speed Control
Press the PHONE/MUTE control to mute the playing media. Press again to return to the playing media. If your vehicle is equipped with a factory installed cellular phone, refer to the Phone/Mute Mode section of the Controls and Features chapter. SPEED CONTROL To turn speed control on Press ON.
Page 78 Controls and features Do not shift the gearshift lever into N (Neutral) with the speed control on. To turn speed control off Press OFF or Turn off the vehicle ignition. Once speed control is switched off, the previously programmed set speed will be erased.
Page 79 If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed. This is normal. Speed control cannot reduce the vehicle speed if it increases above the set speed on a downhill. If your vehicle speed is faster than the set speed while driving on a downhill, you may want to shift to the next lower gear or apply the brakes to reduce your vehicle speed.
Page 80 Controls and features To set a lower set speed Press and hold SET −. Release the control when the desired speed is reached or Press and release SET − to operate the Tap-Down function. Each press will decrease the set speed by 1.6 km/h (1 mph) or Depress CANCEL or the brake pedal.
Page 81 To disengage speed control Press CANCEL, depress the brake pedal, or depress the clutch pedal (if equipped). Disengaging the speed control will not erase the previously programmed set speed. Controls and features RESUME CANCEL...
Page 82 Controls and features Pressing OFF will erase the previously programmed set speed. To return to a previously set speed Press RESUME. For RESUME to operate, the vehicle speed must be faster than 48 km/h (30 mph). Indicator light This light comes on when the vehicle speed control is engaged and actively controlling vehicle speed.
Page 83: Moonroof (If Equipped)
MOON ROOF (IF EQUIPPED) To open the moon roof: Push up on the control to raise the moon roof to the vent position (when the glass panel is closed). Push the front portion of the control rearward to open the moon roof.
Page 84: Automatic Dimming Inside Rear View Mirror
Controls and features With the ignition key in the OFF, ACC or RUN position, the reading lamp on the dome lamp can be turned on by pressing the control. AUTOMATIC DIMMING INSIDE REAR VIEW MIRROR Your vehicle is equipped with an inside rear view mirror which has an auto-dimming function.
Page 85 Controls and features degrees between adjacent zones and will become noticeable as the vehicle crosses multiple zones. A correct zone setting will eliminate this error. Refer to Compass zone adjustment. Compass zone adjustment 1. Determine which compass zone you are in by referring to the zone map.
Page 86: Illuminated Visor Mirror
Controls and features 1. Start the vehicle. 2. Press and hold the COMP side of the control for approximately six seconds until “C” appears in the mirror display. 3. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles or on your everyday routine until the display reads a direction.
Page 87 Controls and features U.S. federal safety standards. For more information on this matter, call toll-free: 1–800–355–3515 or on the Internet at HomeLink.jci.com. Programming Do not program the HomeLink Universal Transceiver with the vehicle parked in the garage. 1. Prepare for programming the HomeLink Universal Transceiver by erasing the three factory default codes by holding down the two...
Page 88 Controls and features Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting after two seconds which may not be long enough to program the HomeLink Universal Transceiver. To program your hand-held transmitters: continue to hold the button on the HomeLink Universal Transceiver.
Page 89 Controls and features After completing the “Programming” functions, follow these steps to train a garage door opener with the rolling code feature: 1. Locate the training button on the garage door motor head unit. Refer to the garage door opener manual or call 1–800–355–3515 or on the Internet at HomeLink.jci.com.
Page 90: Power Windows
Controls and features 2. When the indicator light begins to flash slowly (after 20 seconds), position the hand-held transmitter 5–14 cm (2 to 5 inches) away from the HomeLink surface. 3. Press and hold the hand-held transmitter button. 4. The HomeLink indicator light will flash, first slowly and then rapidly. When the indicator light begins to flash rapidly, release both buttons.
Page 91: Power Door Locks
Controls and features Express down To make the driver window open fully without holding the window control, press the top portion of the AUTO driver window control completely down to the second detent. Press or pull the control to stop window operation. Window lock The window lock feature allows only the driver to operate the rear power...
Page 92: Center Console
Controls and features While the key is in the ignition, the vehicle can be locked by manually pressing the lock control, operating the remote entry transmitter, or operating the drivers door lock with the key. Central locking/Two step unlocking When unlocking the driver door with the key, turn it once toward the front of the vehicle to unlock that door only.
Page 93: Remote Entry System
POSITIVE RETENTION FLOOR MAT Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal. To remove the floor mat, reverse the installation procedure.
Page 94 Controls and features is in the RUN position and the gear shift is in P (Park). The personal alarm feature, however, will not operate when the ignition is in the RUN position. If there is any potential remote keyless entry problem with your vehicle, ensure ALL key fobs (remote entry transmitters) are brought to the dealership, to aid in troubleshooting.
Page 95 Controls and features Locking the doors Press this control to lock all the doors and arm the perimeter anti-theft system (also enables the ignition tamper security system). To confirm all the doors, hood and trunk are closed, the turn signal lamps will display one short flash.
Page 96 Controls and features Activating the personal alarm Press this control to turn on the personal alarm. Press the control a second time to turn off the personal alarm. The personal alarm will also turn off if the remote transmitter unlock control is pressed, or if the ignition switch is turned to the RUN position, or after 30 seconds of...
Page 97 To replace the battery: 1. Twist a thin coin between the two halves of the transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE TRANSMITTER APART. 2. Place the positive (+) side of new battery in the same orientation. Refer to the diagram inside the transmitter unit.
Page 98 Controls and features Relock The autolock feature repeats when: any door, except the drivers, is opened then closed while the engine is running and you put the vehicle in motion. Deactivating/activating the autolock/relock feature The autolock/relock feature can be turned off or on through the vehicle message center (if equipped).
Page 99: Perimeter Alarm System
2. Within 5 five seconds, press one control on the remote transmitter which you would like to deactivate and then press the SET control on the driver’s door panel. 3. Repeat this procedure for another remote transmitter if desired. PERIMETER ALARM SYSTEM The perimeter anti-theft system will help protect your vehicle doors, hood and trunk from unauthorized entry.
Page 100 Controls and features SECURILOCK PASSIVE ANTI-THEFT SYSTEM SecuriLock passive anti-theft system is an engine immobilization system. This system prevents the engine from being started unless a coded key programmed to your vehicle is used. The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems.
Page 101 Spare coded keys can be purchased from your dealership. Your dealership can program your key or you can “do it yourself”, refer to Programming spare keys. The SecuriLock passive anti-theft system is not compatible with non-Ford (aftermarket) remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection.
Page 102 Controls and features key type for your particular vehicle make and model year. If a key Application Matrix is not available, call 1–800–ROTUNDA (1–800–768–8632) (press 2) to order a Key Application Matrix. If an unprogrammed key is used in the ignition it will cause a “NO START”...
Page 103: Interior Luggage Compartment Release
Controls and features 6. To program additional new unprogrammed key(s), repeat this procedure from step 1. If successful, the new coded key(s) will start the vehicle’s engine and the theft indicator will illuminate for three seconds and then go out. If not successful, the new coded key(s) will not start the vehicle’s engine and the theft indicator will flash on and off.
Page 104 Controls and features Keep vehicle doors and luggage compartment locked and keep keys out of a child’s reach. Unsupervised children could lock themselves in an open trunk and risk injury. Children should be taught not to play in vehicles. On hot days, the temperature in the trunk or vehicle interior can rise very quickly.
Page 105: Seating And Safety Restraints
Seating and safety restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 106 Seating and safety restraints The head restraints can be moved in four directions and use the same release control as the two-way head restraints: up and down forward or backward Adjusting the power seats The power seat controls are located on the outboard side of the seat. Never adjust the driver’s seat or seatback when the vehicle is moving.
Page 107 Move the control up or down to move the seat up and down. 8 way 6 way Move front/rear of control up/down to tilt seat cushion. 8 way Heated seats (if equipped) To operate the heated seats: Push control to activate. Push again to deactivate.
Page 108 Seating and safety restraints Using the power lumbar support (if equipped) The power lumbar control is located on the outboard side of the seat. Press one side of the control to adjust firmness. Press the other side of the control to adjust softness.
Page 109: 2Nd Seat/Split-Folding Rear Seat
Memory seats/steering column/mirrors (if equipped) This system allows automatic positioning of the driver seat, outside rearview mirrors, and power adjusted tilt/telescope steering column to two programmable positions. The memory seat control is located on the driver door. To program position one, move the driver seat to the desired position using the seat controls.
Page 110 Seating and safety restraints Fold the seatback(s) down. When raising the seatback(s), make sure you hear the seat latch into place. Make sure that the safety belt for the rear center passenger is properly routed over the rear seatback. SAFETY RESTRAINTS Safety restraints precautions Always drive and ride with your seatback upright and the lap belt snug and low across the hips.
Page 111 It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 112 Seating and safety restraints Combination lap and shoulder belts Front seat belts Rear seat belts...
Page 113 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch. Make sure the tongue is securely fastened in the buckle. 2. To unfasten, push the release button and remove the tongue from the buckle.
Page 114 Seating and safety restraints BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the seat belt assembly “automatic locking retractor” feature or any other seat belt function is not operating properly when checked according to the procedures in Workshop Manual. Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions.
Page 115 Grasp the shoulder portion and pull downward until the entire belt is extracted. Allow the belt to retract. As the belt retracts, you will hear a clicking sound. This indicates the safety belt is now in the automatic locking mode. In this mode, the shoulder belt is automatically pre-locked.
Page 116 Seating and safety restraints Failure to replace the Belt and Retractor assembly could increase the risk of injury in collisions. Safety belt pretensioner Your vehicle is equipped with safety belt pretensioners at the driver and front passenger seating positions. The safety belt pretensioner is a device which removes excess webbing from the safety belt system.
Page 117 Front safety belt height adjustment Your vehicle has safety belt height adjustments for the driver and front passenger. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder. To lower the shoulder belt height, push the button and slide the height adjuster down.
Page 118 Seating and safety restraints Belt minder The Belt Minder feature is a supplemental warning to the safety belt warning function. This feature provides additional reminders to the driver that the driver’s safety belt is unbuckled by intermittently sounding a chime and illuminating the safety belt warning lamp in the instrument cluster.
Page 119 Reasons given... “Seat belts don’t work” “Traffic is light” “Belts wrinkle my clothes” “The people I’m with don’t wear belts” “I have an air bag” Air bags offer greater protection when used with “I’d rather be thrown clear” Do not sit on top of a buckled safety belt to avoid the Belt Minder chime.
Page 120 Seating and safety restraints the ignition switch is in the OFF position all vehicle doors are closed the driver’s safety belt is unbuckled the parklamps/headlamps are in OFF position (If vehicle is equipped with Autolamps, this will not affect the procedure.) To reduce the risk of injury, do not deactivate/activate the Belt Minder feature while driving the vehicle.
Page 121 Safety belt extension assembly If the safety belt assembly is too short for you, even when fully extended, 20 cm (8 inches) can be added to the safety belt assembly by adding a safety belt extension assembly (part number 611C22). Safety belt extension assemblies can be obtained from your dealer at no cost.
Page 122: Air Bag Supplemental Restraint System (Srs)
Seating and safety restraints AIR BAG SUPPLEMENTAL RESTRAINT SYSTEM (SRS) BRAKE Your vehicle is equipped with a crash sensing and diagnostic module which records information about the air bag and sensor systems. In the event of a collision this module may save information related to the collision including information about the air bag system and impact severity.
Page 123 Do not attempt to service, repair, or modify the Air Bag Supplemental Restraint System or its fuses. See your Ford or Lincoln Mercury dealer. Modifications to the front end of the vehicle, including frame, bumper, front end body structure and tow hooks may effect the performance of the air bag sensors increasing the risk of injury.
Page 124 Seating and safety restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 125 The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the air bag.
Page 126 Seating and safety restraints one or more impact and safing sensors. a readiness light and tone. and the electrical wiring which connects the components. The diagnostic module monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors), the system wiring, the air bag system readiness light, the air bag back up power, the air bag ignitors and safety belt pretensioners.
Page 127 Do not attempt to service, repair, or modify the air bag Supplemental Restraint System, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
Page 128 Seating and safety restraints occupied. The air bag was designed to inflate between the door panel and occupant to further enhance the protection provided occupants in side impact collisions. The air bag SRS is designed to activate when the vehicle sustains lateral deceleration sufficient to cause the sensors to close an electrical circuit that initiates air bag inflation.
Page 129: Safety Restraints For Children
The readiness light will not illuminate immediately after ignition is turned to the RUN position. A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and light are repaired. If any of these things happen, even intermittently, have the SRS serviced at your dealership or by a qualified technician immediately.
Page 130: Safety Seats For Children
Seating and safety restraints Children and safety belts If the child is the proper size, restrain the child in a safety seat. Children who are too large for child safety seats (as specified by your child safety seat manufacturer) should always wear safety belts. Follow all the important safety restraint and air bag precautions that apply to adult passengers in your vehicle.
Page 131 Child and infant or child safety seats Use a safety seat that is recommended for the size and weight of the child. Carefully follow all of the manufacturer’s instructions with the safety seat you put in your vehicle. If you do not install and use the safety seat properly, the child may be injured in a sudden stop or collision.
Page 132 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 133 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 134 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 135 The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor. 1.
Page 136 Seating and safety restraints 5. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 6. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat.
Page 137 LATCH lower anchors and LATCH-compatible attachments. Two plastic LATCH guides may be obtained at no charge from any Ford or Lincoln Mercury dealer. They snap onto the latch lower anchor in the vehicle to help attach a child seat with rigid latch attachments.
Page 138 Seating and safety restraints If you install a child seat with rigid LATCH attachments, do not tighten the tether strap enough to lift the child seat off the seat when the child is seated in it. Keep the tether strap just snug without raising the front of the child seat.
Page 139: Preparing To Start Your Vehicle
PREPARING TO START YOUR VEHICLE Engine starting is controlled by the powertrain control system. This system meets all Canadian Interference-Causing Equipment standard requirements regulating the impulse electrical field strength of radio noise. When starting a fuel-injected engine, avoid pressing the accelerator before or during starting.
Page 140 Starting 2. Make sure the headlamps and vehicle accessories are off. If starting a vehicle with an automatic transmission: Make sure the parking brake is set. Make sure the gearshift is in P (Park). If starting a vehicle with a manual transmission: Make sure the parking brake is set.
Page 141: Starting The Engine
Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. If the driver’s safety belt is fastened, the STARTING THE ENGINE Whenever you start your vehicle, release the key as soon as the engine starts.
Page 142 Starting Using the engine block heater (if equipped) An engine block heater warms the engine coolant, which improves starting, warms up the engine faster and allows the heater-defroster system to respond quickly. Use of an engine block heater is strongly recommended if you live in a region where temperatures reach -23°C (-10°F) or below.
Page 143 Starting Important ventilating information If the engine is idling while the vehicle is stopped in an open area for long periods of time, open the windows at least 2.5 cm (one inch). Adjust the heating or air conditioning (if equipped) to bring in fresh air. Improve vehicle ventilation by keeping all air inlet vents clear of snow, leaves and other debris.
Page 144: Driving
Driving BRAKES Your service brakes are self-adjusting. Refer to the scheduled maintenance guide for scheduled maintenance. Occasional brake noise is normal and often does not indicate a performance concern with the vehicle’s brake system. In normal operation, automotive brake systems may emit occasional or intermittent squeal or groan noises when the brakes are applied.
Page 145 illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock brake system is disabled and normal braking is still effective unless the brake warning light also remains illuminated with parking brake released.
Page 146 Driving The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency. Since the parking brake applies only the rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected.
Page 147: Traction Control
wheels out of alignment loose or worn suspension components Speed sensitive steering The steering in your vehicle is speed sensitive. At high speeds, steering assist will decrease to improve steering feel. At lower speeds, maneuverability will be increased. If the amount of effort required to steer your vehicle changes while driving at a constant vehicle speed, have the power steering system checked by your dealer or a qualified service technician.
Page 148 Driving If you should become stuck in snow or on a very slippery road surface, try switching the Traction Control system off. This may allow excess wheel spin to “dig” the vehicle out or enable a successful “rocking” maneuver. If the Traction Control cycled excessively, the brake portion of the system will shut down to prevent the rear brakes from...
Page 149 Driving conditions which may activate AdvanceTrac Taking a turn too fast Evasively maneuvering to avoid an accident, pedestrian or obstacle Hitting a patch of ice Changing lanes on a snow-rutted road Entering a snow-free road from a snow-covered side street Entering a paved road from a gravel road Hitting a curb while turning Driving on slick surfaces...
Page 150: Automatic Transmission Operation (If Equipped)
Driving During AdvanceTrac A rumble or grinding sound much like ABS or Traction Control A slight deceleration or a reduction in the acceleration of the vehicle The AdvanceTrac indicator light will flash If your foot is on the brake pedal, you will feel a vibration in the pedal much like ABS.
Page 151 If you cannot move the gearshift lever out of P (Park) with ignition in the RUN position and the brake pedal depressed: 1. Apply the parking brake, turn ignition key to LOCK, then remove the key. 2. Insert the key and turn it to OFF. Apply the brake pedal and shift to N (Neutral).
Page 152 Driving considered normal and will not affect function durability of the transmission. Once the vehicle is at operating temperature it may take several shifts at the same operating condition for the transmission to properly adapt. Over time the adaptive learning process will fully update transmission operation.
Page 153 Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 154 Driving Drive 5 (Overdrive) The normal driving position for the best fuel economy. Transmission operates in gears One through Five. Drive 4 (Drive) Transmission operates in gears One through Four. Drive 4 (Drive) provides engine braking in 4th gear and is useful when: driving with a heavy load.
Page 155 Driving 3 (Third) Transmission operates in third gear only. Selecting 3 (Third) provides engine braking. Upshifts can be made by shifting to 4 (Drive) or 5 (Overdrive). Selecting 3 (Third) at higher speeds causes the transmission to shift to a lower gear, and will shift to 3 (Third) after vehicle decelerates to the proper speed.
Page 156 Driving 1 (First) Use 1 (Low) to provide maximum engine braking on steep downgrades. Upshifts can be made by shifting to 2 (Second), 3 (Third), 4 (Drive) or 5 (Overdrive). Selecting 1 (Low) at higher speeds causes the transmission to shift to a lower gear, and will shift to 1 (Low) after vehicle decelerates to the proper speed.
Page 157 Driving Understanding gearshift positions The Select Shift Transmission (SST) Shifter allows the driver to select between the transmission’s automatic shift mode or the manually selected shift mode. Automatic shift mode When in the automatic shift mode (D5 position), the 5–speed automatic transmission operates like a typical automatic transmission.
Page 158 Driving + and - position operation These positions allow the driver to manually select the appropriate upshift (+) or downshift (-) and gear range. Can only be entered from the D5 (Overdrive) shift position. Gear ranges 1–5 provide the same function and ratio as found in the D5 or D4 automatic mode positions.
Page 159 speed for the next lower gear, the transmission will allow another downshift to occur if selected by the driver. Recommended Shift Speeds Upshift according to the following charts: Recommended upshifts when accelerating 1 - 2 2 - 3 3 - 4 4 - 5 Recommended upshifts when cruising 1 - 2...
Page 160: Manual Transmission Operation (If Equipped)
Driving MANUAL TRANSMISSION OPERATION (IF EQUIPPED) Using the clutch Vehicles equipped with a manual transmission have a starter interlock that prevents cranking the engine unless the clutch pedal is fully depressed. When starting a vehicle with a manual transmission, you must: 1.
Page 161 Do not drive with your foot resting on the clutch pedal and do not use the clutch to hold your vehicle at a standstill while waiting on a hill. These actions will greatly reduce clutch life. Recommended shift speeds Upshift according to the following chart: Recommended upshifts when accelerating 1 - 2 2 - 3...
Page 162 Driving 2. Set parking brake. 3. Shift into 1 (First). 4. Turn the ignition key to position 1 (LOCK). Do not park your vehicle in Neutral, it may move unexpectedly and injure someone. Use 1 (First) gear and set the parking brake fully.
Page 163: Driving Through Water
Removing key from ignition Turn the ignition key to position 1 (LOCK). Remove the ignition key. DRIVING THROUGH WATER Do not drive quickly through standing water, especially if the depth is unknown. Traction or brake capability may be limited and if the ignition system gets wet, your engine may stall.
Page 164 Driving GVWR (Gross Vehicle Weight Rating): Maximum total weight of the base vehicle, passengers, optional equipment and cargo. The GVWR is specific to each vehicle and is listed on the Safety Certification Label on the driver’s door pillar. GAWR (Gross Axle Weight Rating): Carrying capacity for each axle system.
Page 165: Trailer Towing
to the front of your vehicle, (potentially including weight added to the cab), the weight added should not exceed the front axle reserve capacity (FARC). Additional frontal weight may be added to the front axle reserve capacity provided you limit your payload in other ways (i.e. restrict the number of passengers or amount of cargo carried).
Page 166 Driving Maximum GCWR - kg Engine 3.0L 3.9L 3.0L with Sport Package 3.9L with Sport Package Do not exceed the maximum loads listed on the Certification label. For load specification terms found on the label, refer to Vehicle loading in this chapter.
Page 167 Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications. The trailer brakes must meet local and Federal regulations. Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system.
Page 168 Driving Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your scheduled maintenance guide for more information. Trailer towing tips Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination.
Page 169: Luggage Rack (If Equipped)
LUGGAGE RACK (IF EQUIPPED) The luggage rack is dealer installed only. See your local Lincoln Mercury dealership. The maximum load is 75 kg (165 lb) on the luggage rack structure. The vehicle’s roof panel is not designed to carry a load.
Page 170: Roadside Emergencies
In the United States, this card is found in the Owner Guide portfolio in the glove compartment in Ford vehicles and is mailed to you if you own a Mercury or Lincoln. In Canada, the card is found in the Roadside Assistance book in the glove compartment.
Page 171: Hazard Flasher
In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, you may purchase additional coverage beyond the basic coverage period by consulting the Ford Roadside Assistance Club brochure or by calling 1–877–294–CLUB (1–877–294–2582).
Page 172: Fuses And Relays
Roadside emergencies The fuel pump shut-off switch is located in the driver’s foot well, behind the kick panel. The reset button (RED) for the fuel pump shut-off switch is accessible through an opening in the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1.
Page 173 Always replace a fuse with one that has the specified amperage rating. Using a fuse with a higher amperage rating can cause severe wire damage and could start a fire. Standard fuse amperage rating and color Fuse Mini Rating Fuses Grey Violet Pink...
Page 174 Roadside emergencies RELAY 1 The fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating OWNER'S MANUAL Passenger Compartment Fuse Panel Description Starter Relay Coil Radio ABS/TCS/AdvanceTrac Cluster, PCM Relay, Fuel Pump Relay, REM, Transit Relay T/A Switch, O/D Cancel Switch, Autolamp Sensor, Heated Seat Modules OBD II DDM, DSM, Anti-theft LED, Security Horn,...
Page 175 Fuse/Relay Fuse Amp Location Rating — — Roadside emergencies Passenger Compartment Fuse Panel Description Right Front Low Beam Left Front Turn, Left Front Repeater, Left Front Sidemarker, Left Front Park Lamps Left Front High Beam Not Used Cluster RCM, DATC Not Used (Spare) E/C Mirror, Heated Seat Controls, RSM (Rain Sensor Module)
Page 176 Roadside emergencies Front power distribution box The front power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 177: Fuel Injectors
The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating 10A* — 15A* 15A* 20A* 15A* — — — — 15A* 10A* Roadside emergencies 9 10 11 12 RELAY 01 RELAY 02 RELAY RELAY 04 RELAY 05 RELAY 06 RELAY RELAY RELAY...
Page 178 Roadside emergencies Fuse/Relay Fuse Amp Location Rating 30A** 30A** — 30A** 20A** 40A** — 30A** 30A** 30A** — — Relay 01 — Relay 02 — Relay 03 — Relay 04 — Relay 05 — Relay 06 — Relay 07 — Relay 08 —...
Page 179 Rear power distribution box The rear power distribution box is located in the luggage compartment under the spare tire well cover. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses.
Page 180 Roadside emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Location Rating 15A* 10A* 10A* 10A* 10A* 10A* 20A* 15A* — 20A* 15A* 20A* 20A** 20A** 20A** 20A** 30A** 30A** 40A** 20A** 30A** 20A** 30A** Power Distribution Box Description Decklid Release Solenoid Right Rear Turn Lamp Left Rear Stop Lamp...
Page 181: Changing The Tires
Fuse/Relay Fuse Amp Location Rating 20A** 20A** 30A** Relay 001 — Relay 002 — Relay 003 — Relay 004 — Relay 005 — Relay 006 — Relay 007 — Diode 01 — Diode 02 — *Mini fuses **Maxi fuses CHANGING THE TIRES If you get a flat tire while driving, do not apply the brake heavily.
Page 182 Roadside emergencies use tire chains drive through an automatic car wash, because of the vehicle’s reduced ground clearance try to repair the temporary spare tire or remove it from its wheel drive for long distances when the temporary-use spare is on operate the vehicle with more than one temporary-use spare tire improperly inflate the temporary-use spare use the wheel for any other type of vehicle...
Page 183 Roadside emergencies 3. Lift the trunk cargo cover and remove the spare tire, jack and lug wrench. 4. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground. 5. Put the jack in the jack notch next to the tire you are changing.
Page 184 (not the dealer) to get a replacement key. If the lug wrench/lug nut key assembly is lost, see your nearest Ford or Lincoln/Mercury dealer who has access to the master set of keys. Do not use an impact wrench with the anti-theft key.
Page 185: Jump Starting Your Vehicle
To remove the anti-theft lug nut: 1. Insert the key over the locking lug nut. Make sure you hold the key square to the lug nut. If you hold the key at an angle, you could damage the key and the lug nut. 2.
Page 186 Roadside emergencies adaptive learning process will fully update transmission operation to its optimum shift feel. 1. Use only a 12–volt supply to start your vehicle. 2. Do not disconnect the battery of your disabled vehicle as this could damage the vehicle’s electrical system. Keep the battery vent hose attached at all times.
Page 187 Roadside emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 188 Roadside emergencies 4. Make the final connection of the negative (-) cable to the spare tire tie-down stud. (Your vehicle may be equipped with a plastic cap on top of the tire tie-down stud. This cap must be removed prior to attaching the cable to the stud.) Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 189 Roadside emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the spare tire tie-down stud. 2. Remove the jumper cable on the negative (-) connection of the booster vehicle’s battery.
Page 190 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 191: Wrecker Towing
Roadside emergencies WRECKER TOWING If you need to have your vehicle towed, contact a professional towing service or, if you are a member, your roadside assistance center. It is recommended that your vehicle be towed with a wheel lift or flatbed equipment.
Page 192: Maintenance And Care
Maintenance and care SERVICE RECOMMENDATIONS To help you service your vehicle: We highlight do-it-yourself items in the engine compartment for easy location. We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 193: Opening The Hood
3. Turn off the engine and remove the key. 4. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on Automatic transmission: 1. Set the parking brake and ensure the gearshift is securely latched in P (Park).
Page 194: Identifying Components In The Engine Compartment
Maintenance and care IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 3.0L DOHC V6 engine 1. Engine oil filler cap 2. Engine oil dipstick 3. Brake (and clutch, if equipped) fluid reservoir 4. Engine coolant reservoir 5. Power steering fluid reservoir 6. Air filter assembly 7.
Page 195: Engine Oil
Maintenance and care 3.9L–4V V8 engine 1. Engine oil filler cap 2. Engine oil dipstick 3. Brake fluid reservoir 4. Engine coolant reservoir 5. Power steering fluid reservoir 6. Air filter assembly 7. Windshield washer fluid reservoir 8. Power distribution box 9.
Page 196 Maintenance and care 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P (Park) (automatic transmission) or 1 (First) (manual transmission). 4.
Page 197 Maintenance and care Adding engine oil 1. Check the engine oil. For instructions, refer to Checking the engine oil in this chapter. 2. If the engine oil level is not within the normal range, add only certified engine oil of the recommended viscosity. Remove the engine oil filler cap and use a funnel to pour the engine oil into the opening.
Page 198 Maintenance and care Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used tha does not meet Ford material and design specifications, start-up engine noises of knock may be experienced. It is recommended you use the appropriate Motorcraft oil filter (or another brand meeting Ford specifications) for your engine application.
Page 199 BRAKE FLUID Checking and adding brake fluid Brake fluid should be checked and refilled as needed. Refer to the scheduled maintenance guide for the service interval schedules. 1. Clean the reservoir cap before removal to prevent dirt or water from entering the reservoir. 2.
Page 200: Clutch Fluid (If Equipped)
Maintenance and care CLUTCH FLUID (IF EQUIPPED) The clutch master cylinder and brake master cylinder are part of the same system; both are refillable through the brake master cylinder with brake fluid. For more information on brake fluid maintenance, refer to Brake fluid in this chapter.
Page 201: Engine Coolant
only if they provide cold weather protection without damaging the vehicle’s paint finish, wiper blades or washer system. Do not put washer fluid in the engine coolant reservoir. Washer fluid placed in the cooling system may harm engine and cooling system components.
Page 202 Maintenance and care When the engine is cold, check the level of the engine coolant in the reservoir. The engine coolant should be at the “cold fill level” as listed on the engine coolant reservoir. Refer to the scheduled maintenance guide for service interval schedules.
Page 203 Adding engine coolant Use only Ford Premium Engine Coolant (green in color) or a premium engine coolant that meets Ford specification ESE-M97B44–A. DO NOT USE Ford Extended Life Engine Coolant F6AZ-19544-AA (orange in color). DO NOT USE a DEX-COOL engine coolant or an equivalent engine coolant that meets Ford specification WSS-M97B44-D.
Page 204 Maintenance and care Engine coolant concentrations above 60% or below 40% will decrease the freeze protection characteristics of the engine coolant and may cause engine damage. Plain water may be added in an emergency, but you must replace it with a 50/50 mixture of engine coolant and distilled water as soon as possible.
Page 205 Always dispose of used automotive fluids in a responsible manner. Follow your community’s regulations and standards for recycling and disposing of automotive fluids. Coolant refill capacity To find out how much fluid your vehicle’s cooling system can hold, refer to Refill capacities in the Capacities and specifications chapter. Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter.
Page 206 Maintenance and care Vehicles driven year-round in non-extreme climates should use a 50/50 mixture of engine coolant and distilled water for optimum cooling system and engine protection. What you should know about fail-safe cooling If the engine coolant supply is depleted, this feature allows the vehicle to be driven temporarily before incremental component damage is incurred.
Page 207 1. Pull off the road as soon as safely possible and turn off the engine. 2. Arrange for the vehicle to be taken to a service facility. 3. If this is not possible, wait a short period for the engine to cool. 4.
Page 208: Power Steering Fluid
Maintenance and care POWER STEERING FLUID Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only MERCON ATF. 1. Start the engine and let it run until it reaches normal operating temperature (the engine coolant temperature gauge indicator will be near the center of the normal area between H and C).
Page 209 Maintenance and care the Lubricant specifications section in the Capacities and specifications chapter. Use of a non-approved automatic transmission fluid may cause internal transmission component damage and void the warranty. Checking and adding manual transmission fluid (if equipped) 1. Clean the filler plug. 2.
Page 210 Maintenance and care BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which is located in the luggage compartment, next to the spare tire. Your battery is designed to purge any battery gases to the outside of the vehicle by means of a vent hose. This vent hose MUST be attached at all times.
Page 211 Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 212: Air Filter Maintenance
Maintenance and care If you do not allow the engine to relearn its idle trim, the idle quality of your vehicle may be adversely affected until the idle trim is eventually relearned. When the battery is disconnected or a new battery installed, the transmission must relearn its adaptive strategy.
Page 213 Maintenance and care Changing the air filter element 1. Loosen the hose clamp on the outlet tube at the air filter housing. 2. Release the two clamps that secure the cover to the air filter housing and place the cover aside.
Page 214: Cabin Air Filter
Maintenance and care 3. Remove the air filter element from the air filter housing. 4. Wipe the air filter housing and cover clean to remove any dirt or debris and to ensure good sealing. 5. Install a new air filter element. Be careful not to crimp the filter element edges between the air filter housing and cover.
Page 215 The particulate air filtration system is designed to reduce the concentration of airborne particles such as dust, spores and pollen in the air being supplied to the interior of the vehicle. The particulate filtration system gives the following benefits to customers: Improves the customer’s driving comfort by reducing particle concentration Improves the interior compartment cleanliness...
Page 216 Maintenance and care 2. Remove the five pushpins that retain the passenger side portion of the cowl screen. To release the pins, depress the center “button” of the pins using a key or similar object. Note also that the cowl screen is retained to the rubber hood hinge cover with Velcro.
Page 217 Maintenance and care 5. Insert the new cabin air filter into the cabin air filter housing until the clips are secure. 6. Install the cowl cover. 7. Insert the five pushpins that retain the passenger side portion of the cowl screen. Push up the center “button” of the pins, to insert the pins. Refasten the velcro at the rubber hood hinge cover.
Page 218: Windshield Wiper Blades
Maintenance and care WINDSHIELD WIPER BLADES Check the wiper blades at least twice a year or when they seem less effective. Substances such as tree sap and some hot wax treatments used by commercial car washes reduce the effectiveness of wiper blades. In cold weather conditions, the wiper blades need to be thawed before operating in order to prevent premature wear to the wiper blades.
Page 219: Information About Uniform Tire Quality Grading
Maintenance and care 2. Firmly press the release tab to unlock wiper blade from wiper arm. 3. Pull the wiper blade down toward the windshield to remove it from the arm. 4. Attach the new wiper to the wiper arm and reposition the clip until it locks.
Page 220 Maintenance and care Treadwear 200 Traction AA Temperature A These Tire Quality Grades are determined by standards that the United States Department of Transportation has set. Tire Quality Grades apply to new pneumatic tires for use on passenger cars. They do not apply to deep tread, winter-type snow tires, space-saver or temporary use spare tires, tires with nominal rim diameters of 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2).
Page 221 sudden tire failure. The grade C corresponds to a level of performance which all passenger car tires must meet under the Federal Motor Vehicle Safety Standard No. 109. Grades B and A represent higher levels of performance on the laboratory test wheel than the minimum required by law.
Page 222 Maintenance and care Tire rotation Because your vehicle’s tires perform different jobs, they often wear differently. To make sure your tires wear evenly and last longer, rotate them as indicated in the scheduled maintenance guide. If you notice that the tires wear unevenly, have them checked. Four tire rotation Five tire rotation (with full-size spare tire)
Page 223 Unidirectional tire rotation For vehicles equipped with original equipment unidirectional tires and full-size spare, your vehicle can be driven with the unidirectional full-size spare, rotating counter to the directional arrow on the tire sidewall. Your unidirectional full-size spare tire is rotated for wear balance. Best performance may be achieved by remounting the tire to the wheel, if necessary, to permit tire rotation...
Page 224: Snow Tires And Chains
Maintenance and care Failure to follow these precautions may adversely affect the handling of the vehicle and make it easier for the driver to lose control and roll over. Tires that are larger or smaller than your vehicle’s original tires may also affect the accuracy of your speedometer.
Page 225: What You Should Know About Automotive Fuels
WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank. The pressure in an overfilled tank may cause leakage and lead to fuel spray and fire. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 226 Maintenance and care Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. Avoid getting fuel liquid in your eyes.
Page 227 Fuel Filler Cap Your fuel tank filler cap has an indexed design with a 1/8 turn on/off feature. When fueling your vehicle: 1. Turn the engine off. 2. Carefully turn the filler cap counterclockwise 1/8 of a turn until it stops.
Page 228 Maintenance and care Repairs to correct the effects of using a fuel for which your vehicle was not designed may not be covered by your warranty. Octane recommendations Your vehicle is designed to use “Premium” unleaded gasoline with an (R+M)/2 octane rating of 91 or higher for optimum performance.
Page 229: Essentials Of Good Fuel Economy
Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: You may need to cycle the ignition from OFF to ON several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
Page 230 Maintenance and care amount of fuel in a full tank and a tank when the fuel gauge indicates empty. Empty reserve is the small amount of fuel remaining in the fuel tank after the fuel gauge indicates empty. The amount of usable fuel in the empty reserve varies and should not be relied upon to increase driving range.
Page 231 Keep a record for at least one month and record the type of driving (city or highway). This will provide an accurate estimate of the vehicle’s fuel economy under current driving conditions. Additionally, keeping records during summer and winter will show how temperature impacts fuel economy.
Page 232: Emission Control System
Maintenance and care Use recommended engine oil. Refer to Lubricant Specifications. Perform all regularly scheduled maintenance items. Follow the recommended maintenance schedule and owner maintenance checks found in your vehicle scheduled maintenance guide. Conditions Heavily loading a vehicle or towing a trailer may reduce fuel economy at any speed.
Page 233 Use only the specified fuel listed. Avoid running out of fuel. Do not turn off the ignition while your vehicle is moving, especially at high speeds. Have the items listed in your scheduled maintenance guide performed according to the specified schedule. The scheduled maintenance items listed in the scheduled maintenance guide are essential to the life and performance of your vehicle and to its emissions system.
Page 234 Maintenance and care Readiness for Inspection/Maintenance (I/M) testing In some localities, it may be a legal requirement to pass an I/M test of the on-board diagnostics system. If your “Check Engine/Service Engine Soon” light is on, refer to the description in the Warning Lights and Chimes section of the Instrumentation chapter.
Page 235 Replacing headlamp bulbs To remove the high or low beam headlamp bulb: 1. Make sure headlamp switch is in OFF position. 2. Lift the hood, push and release four tabs and remove the protective cover from the headlamps. 3. Disconnect the electrical connector from the bulb by pulling rearward.
Page 236 Maintenance and care 1. Disconnect the electrical connector from the foglamp bulb. 2. Rotate the foglamp bulb counterclockwise and remove from the foglamp (the rear side of the foglamp is shown). 3. Install the foglamp bulb in foglamp by rotating clockwise. 4.
Page 237: Aiming The Headlamps
Function Headlamp low beam Headlamp high beam Park and turn lamp (front) Side marker lamp (front) Foglamp Tail lamp, brakelamp, side lamp Rear turn lamp Backup lamp Tail/body side Tail/deck (trunk) lid License plate lamp High-mount brakelamp Front door courtesy lamp Map lamp (with moon roof) Dome lamp (rear) Map lamp (front)
Page 238 Maintenance and care If the vehicle has been in an accident, the vehicle’s front structure should be properly aligned before aiming the headlamps. Horizontal aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, remove the protective cover, then locate the horizontal indicator and the adjusting screw.
Page 239: Cleaning And Caring For Your Vehicle
Maintenance and care Vertical aim adjustment 1. Park the vehicle on a level surface. 2. With the hood open, remove protective cover, then locate the bubble level and the vertical adjustment screw. 3. The numbers shown on the vial indicate the directional change (up or down) of the vertical aim.
Page 240 Maintenance and care During winter months, it is especially important to wash the vehicle on a regular basis. Large quantities of dirt and road salt are difficult to remove and also cause damage to the vehicle. Any gasoline spilled on the vehicle or deposits such as bird droppings should be washed and sponged off as soon as possible.
Page 241 Maintenance and care Remove particles such as bird droppings, tree sap, insect remains, tar spots, road salt and industrial fallout immediately. Cleaning the wheels Wash with the same detergent as the body of your vehicle. Do not use acid-based or alcohol-based wheel cleaners, steel wool, fuel or strong detergents.
Page 242 Maintenance and care Ford Dealer. Do not use abrasive cleansers on glass as they may cause scratches. The windshield or rear window is clean if beads do not form when you rinse it with water. The windshield, rear window and wiper blades should be cleaned on a regular basis, and blades or rubber elements replaced when worn.
Page 243 Cover the highlighted areas to prevent water damage when cleaning the engine. Never wash or rinse the engine while it is running; water in the running engine may cause internal damage. Cleaning the instrument panel Clean with a damp cloth, then dry with a dry cloth. Avoid cleaner or polish that increases the gloss of the upper portion of the instrument panel.
Page 244 Maintenance and care Cleaning seats equipped with side air bags Remove dust and loose dirt with a whisk broom or a vacuum cleaner. Remove fresh spots immediately. Follow the directions that come with the cleaner. Do not saturate the seat cover with upholstery cleaner. Do not use chemical solvents or strong detergents when cleaning the seat mounted side air bag.
Page 245 Maintenance and care Cleaning the interior fabric Remove dust and loose dirt with a whisk broom or a vacuum cleaner. Remove fresh spots immediately. Do not use household or glass cleaners. These agents can stain and discolor the fabric. Use a mild soap and water solution if necessary.
Page 246: Capacities And Specifications
Capacities and specifications MOTORCRAFT PART NUMBERS Component Air filter element Fuel filter Battery (standard) Battery (optional) Oil filter PCV valve Spark plugs* * Refer to Vehicle Emissions Control Information (VECI) decal for spark plug information. REFILL CAPACITIES Fluid Ford Part Name Brake fluid and High Performance clutch fluid (if...
Page 247 Fluid Ford Part Name Rear axle Motorcraft SAE 75W-140 High Performance Synthetic Rear Axle Lubricant Fuel tank Transmission Motorcraft fluid MERCON V ATF Motorcraft MERCON ATF Windshield Ultra-Clear washer fluid Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. Refer to Lubricant Specifications in this chapter.
Page 248: Lubricant Specifications
Capacities and specifications LUBRICANT SPECIFICATIONS Item Ford part name Brake fluid and High clutch fluid (if Performance equipped) DOT 3 Motor Vehicle Brake Fluid Door Silicone weatherstrips Lubricant Door latch, hood Multi-Purpose latch, auxiliary Grease hood latch, door hinges, striker plates, seat tracks and fuel filler door hinge...
Page 249: Engine Data
Item Ford part name Rear Axle Motorcraft SAE Lubricant 75W-140 High Performance Synthetic Rear Axle Lubricant Automatic Motorcraft transmission MERCON V fluid Manual Motorcraft transmission MERCON ATF fluid Windshield Ultra-clear washer fluid Windshield Washer Concentrate Use only brake fluids certified to meet Ford specifications. DOT 3 fluid is recommended.
Page 250: Vehicle Dimensions
Capacities and specifications VEHICLE DIMENSIONS Vehicle dimensions (1) Overall length (2) Overall width (3) Overall height (4) Wheelbase (5) Track - Front (5) Track - Rear mm (in) 4 925 mm (193.9 in) 1 859 mm (73.2 in) 1 426 mm (56.1 in) 2 909 mm (114.5 in) 1 537 mm (60.5 in) 1 544 mm (60.8 in)
Page 251: Certification Label
IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification Label be affixed to a vehicle and prescribe where the Certification Label may be located. The Certification Label is located on the driver’s side A-pillar. Vehicle identification number The vehicle identification number is attached to a metal tag and is...
Page 252: Customer Assistance
Bumper to Bumper Warranty expires You may purchase Ford ESP from any participating Ford and Lincoln Mercury and Ford of Canada dealer. There are several plans available in various time, distance and deductible combinations which can be tailored to fit your own driving needs.
Page 253 Customer assistance If you have questions or concerns, or are unsatisfied with the service you are receiving, follow these steps: 1. Contact your Sales Representative or Service Advisor at your selling/servicing dealership. 2. If your inquiry or concern remains unresolved, contact the Sales Manager or Service Manager at the dealership.
Page 254 Customer assistance If you own a Lincoln vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 255: The Dispute Settlement Board (U.s. Only)
What kinds of cases does the Board review? Unresolved warranty repair concerns or vehicle performance as designed concerns on Ford and Lincoln Mercury cars and Ford and Lincoln Mercury light trucks which are within the terms of any applicable written...
Page 256 Ford or Lincoln Mercury dealership representative Consumer candidates for Board membership are recruited and trained by an independent consulting firm. The dealership Board member is chosen from Ford and Lincoln Mercury dealership management, recognized for their business leadership qualities. What the Board needs...
Page 257 a brief summary of the action taken by the dealer(s) and Ford Motor Company the names (if known) of all the people you contacted at the dealership(s) a description of the action you expect to resolve your concern You will receive a letter of explanation if your application does not qualify for Board review.
Page 258: Getting Assistance Outside The U.s. And Canada
Customer assistance You may also contact the North American Customer Relationship Center at 1-800-392-3673 (Ford), TDD for the hearing impaired: 1-800-232-5952 or by writing to the Center at the following address: Ford Motor Company Customer Relationship Center 16800 Executive Plaza Drive P.O.
Page 259 Customer assistance The use of leaded fuel in your vehicle without proper conversion may damage the effectiveness of your emission control system and may cause engine knocking or serious engine damage. Ford Motor Company/Ford of Canada is not responsible for any damage caused by use of improper fuel.
Page 260 FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of Ford accessories are available for your vehicle through your local authorized Lincoln Mercury dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 261 Travel equipment Removable luggage rack Removable luggage rack adapters Protection and appearance equipment Air bag anti-theft locks Car cover Carpet floor mats Emergency kit First aid kit Front end covers (mini) HomeLink Molded splash guards Molded vinyl floor mats Moon roof air deflector Park pilot/reverse park aid Rear spoiler Wood/Leather steering wheel...
Page 262: Ordering Additional Owner's Literature
Customer assistance cause the engine to stumble or stall or cause the transmission to be damaged or operate improperly. In addition, such systems may be damaged or their performance may be affected by operating your vehicle. (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) Ford cannot assume responsibility for any adverse effects or damage...
Page 263: In California (U.s. Only)
Customer assistance IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer or its representative is unable to repair a motor vehicle to conform to the vehicle’s applicable express warranty after a reasonable number of attempts, the manufacturer shall be required to either replace the vehicle with one substantially identical or repurchase the vehicle and reimburse the buyer in an amount equal to the actual price paid or payable by the consumer (less a reasonable allowance for consumer...
Page 264: Reporting Safety Defects
Reporting safety defects REPORTING SAFETY DEFECTS (U.S. ONLY) If you believe that your vehicle has a defect that could cause a crash, or could cause injury or death, you should immediately inform the National Highway Traffic Safety Administration (NHTSA) in addition to notifying Ford Motor Company.
Page 265: Index
Accessory delay ...91 AdvanceTrac ...148 Air bag supplemental restraint system ...122, 126 and child safety seats ...124 description ...122, 126 disposal ...129 driver air bag ...124, 127 indicator light ...11, 126, 128 operation ...124, 127 passenger air bag ...124, 127 side air bag ...126 Air cleaner filter ...212–213, 246 Air conditioning ...31...
Page 266 Index engine compartment ...242 exterior ...240 exterior lamps ...241 instrument cluster lens ...243 instrument panel ...243 interior ...244–245 mirrors ...241 plastic parts ...241 safety belts ...244 washing ...239 waxing ...240 wheels ...241 windows ...244 wiper blades ...241 woodtone trim ...244 Climate control (see Air conditioning or Heating) ...31 Clock ...50, 66...
Page 267 Engine ...249–250 check engine/ service engine soon light ...8 cleaning ...242 coolant ...201 fail-safe coolant ...206 idle speed control ...210 lubrication specifications ...248–249 refill capacities ...246 service points ...194–195 starting after a collision ...171 Engine block heater ...142 Engine fan ...207 Engine oil ...195 checking and adding ...195 dipstick ...195...
Page 268 Index Hazard flashers ...171 Head restraints ...105 Headlamps ...27 aiming ...237–239 autolamp system ...29 bulb specifications ...236 daytime running lights ...27 flash to pass ...28 high beam ...10 replacing bulbs ...235 turning on and off ...27 warning chime ...14 Heating ...31 HomeLink universal transceiver (see Garage door opener) ...86–89...
Page 269 high beam ...10, 12 low coolant ...8 low fuel ...11 low washer fluid ...12 oil pressure ...11 safety belt ...11 speed control ...82 steering column lock ...12 transmission PRNDL indicator ...13 turn signal indicator ...10 Load limits ...163 GAWR ...163 GVWR ...163 trailer towing ...163 Locks...
Page 270 Index Safety belts (see Safety restraints) ...14, 110, 112–115, 117 Safety defects, reporting ...264 Safety restraints ...110, 112–117 belt minder ...118 cleaning the safety belts ...121, 244 extension assembly ...121 for adults ...112–115 for children ...129–130 warning light and chime ...11, 14, 117 Safety seats for children ..130–131 Seat belts (see Safety restraints) ...110...
Page 271 Vehicle dimensions ...250 Vehicle Identification Number (VIN) ...251 Vehicle loading ...163 Ventilating your vehicle ...143 Warning chimes ...14 Warning lights (see Lights) ...8 Water, Driving through ...163 Windows power ...90 Windshield washer fluid and wipers checking and cleaning ...218 operation ...73 replacing wiper blades ...218 Wrecker towing ...191 Index...
Page 272: Filling Station Information
Filling station information Item Required fuel Fuel tank capacity Engine oil capacity-3.0L V6 engine (includes filter change) Engine oil capacity-3.9L V8 engine (includes filter change) Tire size and pressure Hood release Coolant capacity-3.0L V6 engine Coolant capacity-3.9L V8 engine Power steering fluid capacity Engine cooling fan fluid capacity Manual transmission fluid...

This manual is also suitable for:

Ls 2001

Lincoln 2001 LS Owner's Manual

Quick Links

Need help?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lincoln 2001 LS

Summary of Contents for Lincoln 2001 LS

This manual is also suitable for:

Table of Contents
