DAYTEK A02840200 Instruction Manual page 5

ASSEMBLY (CONTINUED)
LINE TENSIONER
4. Secure the cord.
Secure the cord into the line
LINE END 1
tensioner as shown in the
diagram and trim excess
leaving approximately 100mm
LINE START 2
(10cm/4 inches).
Note: The cord will stretch after
initial use. We suggest re-tensioning
the cord after several uses.
Caution: Do not over tension the
cord as you could distort the frame
and put unnecessary strain on the
joint. Refer to diagrams below.
YOUR DAYTEK A-FRAME CLOTHESLINE IS NOW READY FOR USE.
Important: Tension lines with light hand pull
STEP 1. Thread line through tensioner. STEP 2. Pull line tight.
TOP VIEW
STEP 3. Loop line around
tensioner knob 2-3 times.
TOP VIEW
5
LINE START 1
LINE END 2
STEP 4. Lock line into clip and trim
excess leaving approximately 10cm
(4 inches).
TOP VIEW
LINE TENSIONER
