DAYTEK A02840200 Instruction Manual page 4

ASSEMBLY (CONTINUED)
2. Attach arms to frame
STEP 1. Take 1 arm assembly and
slot into position as shown below.
SPRING BUTTON
3. Thread the clothesline cord.
STEP 1. Thread the cord on both sides of the
clothesline as shown below. Start at the inner most
hole and work your way through to the outside hole
and through the line tensioner.
LINE END 1
LINE START 2
STEP 2. The arm will lock into place
and be held by the spring button.
STEP 2. Once fully threaded pull the cord
reasonably tight to ensure there are no
loose sections.
Important: Tension lines with light hand pull
TOP VIEW
4
STEP 3. Repeat this process for the
other arm.
LINE START 1
LINE END 2
