2-3. Principal components

• CPU
• RAM
• Printer
• Display
• Power transformer
• Keyboard
• Drawer
2-4. Option
• Wet cover
Name
Number of control bit
Internal RAM
Internal ROM
Main system clock
Sub system clock
Name
Capacity
Name
Capacity
Name
Print method
Print digit
Printing speed
MCBF
Paper width
Paper diameter
Paper thickness
Ink ribbon
Ribbon life
Name
Number of digit
Name
Input system
200CR
PCR-360/PCR-365
240CR
PCR-460
Name
— 2 —
µPD78054GC-213-3B9 (200CR etc.)
µPD78054GC-214-3B9 (240CR etc.)
8
1024 B
32 KB
5.00 MHz
32.768 KHz
LC3564S70/85/10
8 KB
CXK58257AP-70/10L
32 KB (PCR-460 only)
M-405R
Print wheel selective system
12 digits ( Numeric : 10 digits
Symbol : 2 digits)
Approx. 3 lines/sec.
1,000,000 lines
W 57.5 ± 0.5 mm
80 mm or less
0.06 ~ 0.085 mm
RAP-01
50,000 lines
LED (HDSP-5621-G or HDSP-5621-H)
8 digits (LED x 4 pcs.)
TE-240-E4D (US, Canada)
TE-240-E3U (Except US, Canada)
2 keys roll over / 6 keys buffer memory
DL-1320 for U.S.
DL-2762 for Canada, other countries.
DL-1320 for US
DL-1832 for Europe, other countries.
DL-2762 for Europe, UK, Germany other
countries.
WT-73
