Standard Features
• Heavy-duty stainless-steel heat exchanger
• Energy-efficient compressor
• All-aluminum evaporator coil
• Aluminum tube/aluminum fin coil
• Multi-speed ECM blower motor
• Flowrater expansion device on 2- to 4-ton units;
TXV expansion device on 5-ton units
• Redundant gas valve with easy
conversion to propane
• Power-assisted combustion
• Direct spark ignition system includes a microprocessor-based control for the entire ignition
sequence, all blower operation, and all safety circuits complete with self-diagnostics
• All models comply with California Low NOx standards
• AHRI Certified; ETL Listed
SS-APG14M
Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas.
Cooling Capacity: 23,000 - 57,500 BTU/h
Heating Capacity: 40,000 - 120,000 BTU/h
Cabinet Features
• High-quality UV-resistant powder-paint finish
• Horizontal or downflow application
• Compressor sound blanket
• Convenient access panels
• One roof curb fits all units
• Fully insulated cabinet
• Bottom, 2" high base rails for easier handling
• When properly anchored, meets 2010 Florida
Building Code unit integrity requirements for hur-
ricane-type winds (Anchor bracket kits available.)
* Complete warranty details available from your local dealer or at www.amana-
hac.com. To receive the Lifetime Heat Exchanger Limited Warranty (good
for as long as you own your home) plus the 10-Year Parts Limited Warranty,
online registration must be completed within 60 days of installation. Online
registration is not required in California or Québec.
www.amana-hac.com
APG14M
Packaged Gas/Electric
14 SEER / 81% AFUE
Contents
Nomenclature ........................................ 2
Accessories ............................................ 2
Product Specifications ........................... 3
Expanded Cooling Data ......................... 7
Airflow Data ......................................... 24
Dimensions .......................................... 29
Wiring Diagrams ................................. 30
7/15
Supersedes 11/14

Advertisement

loading
Need help?

Need help?

Do you have a question about the APG14M and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Amana APG14M

  • Page 1: Table Of Contents

    60 days of installation. Online registration is not required in California or Québec. SS-APG14M www.amana-hac.com 7/15 Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P., Houston, Texas. Supersedes 11/14...
  • Page 2: Nomenclature

    Nomenclature   8,   9 ,   1 0 Brand Electrical Amana®   B rand 208-­‐230/1/60 208-­‐230/3/60 Product   C ategory Packaged   U nit Refrigerant   4         R -­‐410A Unit   T ype Gas/Electric Heat  ...
  • Page 3: Product Specifications

    ¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes. ² Must use time-delay fuses or HACR-type circuit breakers of the same size as noted. Note: Always check the S&R plate for electrical data on the unit being installed. SS-APG14M www.amana-hac.com...
  • Page 4 ¹ Wire size should be determined in accordance with National Electrical Codes. Extensive wire runs will require larger wire sizes. ² Must use time-delay fuses or HACR-type circuit breakers of the same size as noted. Note: Always check the S&R plate for electrical data on the unit being installed. www.amana-hac.com SS-APG14M...
  • Page 5 ² Must use time-delay fuses or HACR-type circuit breakers of the same size as noted. Notes • Always check the S&R plate for electrical data on the unit being installed. • Test data was use to calculate the MOP and MCA. SS-APG14M www.amana-hac.com...
  • Page 6 Expanded Cooling Data — APG1424***M41** www.amana-hac.com SS-APG14M...
  • Page 7: Expanded Cooling Data

    Expanded Cooling Data — APG1424***M41** (cont.) SS-APG14M www.amana-hac.com...
  • Page 8 Expanded Cooling Data — APG1430***M41** www.amana-hac.com SS-APG14M...
  • Page 9 Expanded Cooling Data — APG1430***M41** (cont.) SS-APG14M www.amana-hac.com...
  • Page 10 Expanded Cooling Data — APG1436***M41** www.amana-hac.com SS-APG14M...
  • Page 11 Expanded Cooling Data — APG1436***M41** (cont.) SS-APG14M www.amana-hac.com...
  • Page 12 Expanded Cooling Data — APG1442***M41** www.amana-hac.com SS-APG14M...
  • Page 13 Expanded Cooling Data — APG1442***M41** (cont.) SS-APG14M www.amana-hac.com...
  • Page 14 Expanded Cooling Data — APG1448***M41** www.amana-hac.com SS-APG14M...
  • Page 15 Expanded Cooling Data — APG1448***M41** (cont.) SS-APG14M www.amana-hac.com...
  • Page 16 Expanded Cooling Data — APG1460***41A* — Low Stage www.amana-hac.com SS-APG14M...
  • Page 17 Expanded Cooling Data — APG1460***41A* — Low Stage (cont.) SS-APG14M www.amana-hac.com...
  • Page 18 Expanded Cooling Data — APG1460***41A* — High Stage www.amana-hac.com SS-APG14M...
  • Page 19 Expanded Cooling Data — APG1460***41A* — High Stage (cont.) SS-APG14M www.amana-hac.com...
  • Page 20 Expanded Cooling Data — APG1461***41A* — Low Stage www.amana-hac.com SS-APG14M...
  • Page 21 Expanded Cooling Data — APG1461***41A* — Low Stage (cont.) SS-APG14M www.amana-hac.com...
  • Page 22 Expanded Cooling Data — APG1461***41A* — High Stage www.amana-hac.com SS-APG14M...
  • Page 23 Expanded Cooling Data — APG1461***41A* — High Stage (cont.) SS-APG14M www.amana-hac.com...
  • Page 24: Airflow Data

    APG1430060M41** - Rise Range: 30° - 60° T1 Heating Speed T2 Heating Speed T3 Heating Speed T4 Cooling Speed T5 Cooling Speed E.s.p. Watts Rise Watts Rise Watts Rise Watts Watts 1,035 1,035 1,225 1,185 1,150 1,115 1,085 1,045 1,000 www.amana-hac.com SS-APG14M...
  • Page 25 E.s.p. Watts Rise Watts Rise Watts Rise Watts Watts 1,185 1,335 1,335 1,630 1,140 1,300 1,305 1,595 1,100 1,265 1,265 1,555 1,060 1,215 1,225 1,520 1,020 1,170 1,190 1,485 1,135 1,135 1,450 1,085 1,095 1,410 1,025 1,040 1,370 SS-APG14M www.amana-hac.com...
  • Page 26 Watts Rise Watts Watts 1,055 1,380 1,570 1,570 1,780 1,000 1,320 1,520 1,520 1,740 1,270 1,480 1,480 1,695 1,220 1,425 1,425 1,640 1,160 1,380 1,380 1,595 1,115 1,335 1,335 1,550 1,060 1,285 1,285 1,505 1,000 1,235 1,235 1,465 www.amana-hac.com SS-APG14M...
  • Page 27 1,745 1,340 1780 1,940 1,300 1,705 1,270 1745 1,910 1,255 1,660 1,235 1700 1,880 1,205 1,620 1,175 1655 1,825 1,165 1,580 1,135 1610 1,790 1,110 1,535 1,085 1560 1,735 1,055 1,485 1,040 1520 1,700 1,010 1,435 1475 1,660 SS-APG14M www.amana-hac.com...
  • Page 28 1,745 1,340 1780 1,940 1,300 1,705 1,270 1745 1,910 1,255 1,660 1,235 1700 1,880 1,205 1,620 1,175 1655 1,825 1,165 1,580 1,135 1610 1,790 1,110 1,535 1,085 1560 1,735 1,055 1,485 1,040 1520 1,700 1,010 1,435 1475 1,660 www.amana-hac.com SS-APG14M...
  • Page 29: Dimensions

    Large 40” 18” 14” COMBUSTION AIR INTAKE APG1461***M41** Large 40” 18” 14” BLOWER ACCESS PANEL Dimensions Model W" D" H" APG1424***M41** 34¾ APG1430***M41** 34¾ APG1436***M41** 34¾ 5 3/4 APG1442***M41** 34¾ APG1448***M41** 42¾ APG1460***M41** 42¾ APG1461***M41** 42¾ SUPPLY RETURN SS-APG14M www.amana-hac.com...
  • Page 30: Wiring Diagrams

    Wiring Diagram — APG1424-42M41 BREAK FOR TWO STAGE COMPRESSOR UNUSED HEAT COOL ECON MOUNT SCREW REQUIRED SPEED-UP www.amana-hac.com SS-APG14M...
  • Page 31 Wiring Diagram — APG1448M41 BREAK FOR TWO STAGE COMPRESSOR UNUSED HEAT COOL ECON MOUNT SCREW REQUIRED SPEED-UP SS-APG14M www.amana-hac.com...
  • Page 32 Wiring Diagram — APG1460-61M41 Amana® is a trademark of Maytag Corporation or its related companies and used under license to Goodman Company, L.P. All rights reserved. Our continuing commitment to quality products may mean a change in specifications without notice. © 2015 Goodman Company, L.P. • Houston, Texas • Printed in the USA.
