A/GPG 13.4 SEER2 "M" SERIES WITH R-32
RECOGNIZE THIS SYMBOL AS
A SAFETY PRECAUTION.
These installation instructions cover the outdoor installa-
tion of self contained package air conditioners and heating
units. See the Specification Sheets applicable to your
model for information regarding accessories.
*NOTE: Please contact your distributor or our website
for the applicable Specification Sheets referred to in this
manual.
Do not bypass safety devices.
IOG-3033A
07/2024
INSTALLATION & OPERATING
INSTRUCTIONS for
SINGLE PACKAGE GAS-ELECTRIC
HEATING & COOLING UNIT
Affix this manual and Users Information Manual adjacent to the unit.
WARNING
19001 Kermier Rd., Waller, TX 77484
www.goodmanmfg.com • www.amana-hac.com
© 2022-2024 Daikin Comfort Technologies Manufacturing, L.P.
is a registered trademark of Maytag Corporation or its related companies and is used
under license. All rights reserved.
This Forced Air Central Unit Design Complies With
Requirements Embodied In The American National
Standard / National Standard of Canada Shown Below.
ANSI Z21.47•CSA-2.3 Central Furnaces.
ONLY PERSONNEL THAT HAVE BEEN TRAINED TO INSTALL,
ADJUST, SERVICE, MAINTENANCE OR REPAIR
(HEREINAFTER, "SERVICE") THE EQUIPMENT SPECIFIED IN
THIS MANUAL SHOULD SERVICE THE EQUIPMENT.
THIS EQUIPMENT IS NOT INTENDED FOR USE BY
PERSONS (INCLUDING CHILDREN) WITH REDUCED
PHYSICAL, SENSORY OR MENTAL CAPABILITIES, OR LACK
OF EXPERIENCE AND KNOWLEDGE, UNLESS THEY HAVE
BEEN GIVEN SUPERVISION OR INSTRUCTION CONCERNING
USE OF THE APPLIANCE BY A PERSON RESPONSIBLE FOR
THEIR SAFETY.
CHILDREN SHOULD BE SUPERVISED TO ENSURE THAT
THEY DO NOT PLAY WITH THE EQUIPMENT.
THE MANUFACTURER WILL NOT BE RESPONSIBLE FOR
ANY INJURY OR PROPERTY DAMAGE ARISING FROM
IMPROPER SUPERVISION, SERVICE OR SERVICE
PROCEDURES. IF YOU SERVICE THIS UNIT, YOU ASSUME
RESPONSIBILITY FOR ANY INJURY OR PROPERTY
DAMAGE WHICH MAY RESULT. IN ADDITION, IN
JURISDICTIONS THAT REQUIRE ONE OR MORE LICENSES
TO SERVICE THE EQUIPMENT SPECIFIED IN THIS
MANUAL, ONLY LICENSED PERSONNEL SHOULD SERVICE
THE EQUIPMENT. IMPROPER SUPERVISION, INSTALLATION,
ADJUSTMENT, SERVICING, MAINTENANCE OR REPAIR OF
THE EQUIPMENT SPECIFIED IN THIS MANUAL, OR
ATTEMPTING TO INSTALL, ADJUST, SERVICE OR REPAIR
THE EQUIPMENT SPECIFIED IN THIS MANUAL WITHOUT
PROPER SUPERVISION OR TRAINING MAY RESULT IN
PRODUCT DAMAGE, PROPERTY DAMAGE, PERSONAL
INJURY OR DEATH.
WARNING
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Amana A/GPG 13.4 SEER2 M Series
Summary of Contents for Amana A/GPG 13.4 SEER2 M Series
- Page 1 PROPER SUPERVISION OR TRAINING MAY RESULT IN PRODUCT DAMAGE, PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. 19001 Kermier Rd., Waller, TX 77484 www.goodmanmfg.com • www.amana-hac.com © 2022-2024 Daikin Comfort Technologies Manufacturing, L.P. IOG-3033A is a registered trademark of Maytag Corporation or its related companies and is used 07/2024 under license.
-
Page 2: Table Of Contents
TABLE OF CONTENTS REPLACEMENT PARTS ..........2 Cabinet Finish Maintenance ........28 Ordering Parts ............2 Clean Outside Coil (Qualified Servicer Only) ...28 SAFETY INSTRUCTIONS ..........2 Condenser, Evaporator, and Induced To the Installer ............2 Draft Motors ............28 GENERAL INFORMATION ..........6 Flame Sensor (Qualified Servicer Only) .....28 Qualification of workers .........6 Flue Passages (Qualified Servicer Only) ....28 Transportation Damage ...........6... -
Page 3: What To Do If You Smell Gas
WARNING WARNING Should overheating occur or the gas supply fail to shut If the information in these instructions is not followed off, turn off the manual gas shutoff valve external to the exactly, a fire or explosions may result causing property furnace before turning off the electrical supply. - Page 4 WARNING WARNING AUXILIARY DEVICES WHICH MAY BE A POTENTIAL IGNITION DO NOT USE MEANS TO ACCELERATE THE DEFROSTING SOURCE SHALL NOT BE INSTALLED IN THE DUCT WORK. PROCESS OR TO CLEAN, OTHER THAN THOSE RECOM- EXAMPLES OF SUCH POTENTIAL IGNITION SOURCES ARE MENDED BY THE MANUFACTURER.
-
Page 5: Fire Or Explosion Hazard
WARNING WARNING HERMETIC COMPRESSOR ELECTRICAL TERMINAL VENT- CARBON MONOXIDE POISONING HAZARD ING CAN BE DANGEROUS. IN CERTAIN CIRCUMSTANCES, THE TERMINAL MAY BE EXPELLED, VENTING THE REFRIG- Failure to follow instructions could result in severe ERANT VAPOR AND COMPRESSOR OIL CONTAINED WITHIN personal injury or death due to carbon-monoxide poisoning, THE COMPRESSOR HOUSING AND SYSTEM. -
Page 6: General Information
In the event of dam- www.goodmanmfg.com for Goodman® brand products or age, the receiver should: www.amana-hac.com for Amana® brand products. Within 1. Make notation on delivery receipt of any visible dam- either website, please select the residential or commercial age to shipment or container. -
Page 7: Accessory Installation
THE FOLLOWING INSTRUCTIONS ARE MANDATORY FOR A2L SYSTEMS AND SUPERSEDE OTHER INSTRUCTIONS WARNING ONLY BRAZING TECHNIQUES AND APPROVED MECHANICAL JOINTS SHOULD BE USED TO CONNECT REFRIGERANT TUBING CONNECTIONS. NON-APPROVED MECHANICAL CONNECTORS AND OTHER METHODS ARE NOT PERMITTED IN THIS SYSTEM CONTAINING A2L REFRIGERANT. APPROVED MECHANICAL JOINTS WILL BE DETAILED IN THE PRODUCT'S SPECIFICATION SHEETS. - Page 8 ALTITUDE ADJUSTMENT FACTOR TO CALCULATE MINIMUM ROOM AREA The Indoor equipment mitigation requirements are calculated at sea level. For higher altitudes adjust the minimum room area specified o n or near the Serial Plate by the corresponding altitude adjustment factor shown below.
-
Page 9: All Installations
The following leak detection methods are deemed acceptable • To avoid possible corrosion of the heat exchanger, for all refrigerant systems. do not locate the unit in an area where the outdoor air (i.e. combustion air for the unit) will be frequently Electronic leak detectors may be used to detect refrigerant contaminated by compounds containing chlorine or leaks but, in the case of FLAMMABLE REFRIGERANTS, the... -
Page 10: Rooftop Installations Only
Outside Slab Installation Rooftop Installations Only: NOTE: To ensure proper condensate drainage, unit must be installed in a level position. • To avoid possible property damage or personal injury, the roof must have sufficient structural strength to carry the weight of the unit(s) and snow or water loads as required by local codes. -
Page 11: Gas Piping
Unit should be lifted by the 4 holes located at the base frame corners. Lifting cables should be attached to the WARNING unit with shackles. While rigging unit, center of gravity will cause the condenser end (heavier) to be lower than supply To avoid property damage, personal injury or death when air end. -
Page 12: Piping
Piping be coated to protect against external corrosion when IMPORTANT NOTE: To avoid possible unsatisfactory in contact with masonry, plaster or insulation or are operation or equipment damage due to under firing subject to repeated wettings by liquids (water - not of equipment, do not undersize the natural/propane rain water, detergents or sewage) gas piping from the meter/tank to the unit. -
Page 13: Propane Gas Installations
See below for typical propane gas piping. PROPANE GAS INSTALLATIONS 5 to 15 PSIG First Stage (20 PSIG Max.) Regulator Continuous WARNING 11" W.C. To avoid property damage, personal injury or death due to fire or explosion caused by a propane gas leak, install a gas 200 PSIG Second Stage Maximum... -
Page 14: Electrical Wiring
ELECTRICAL WIRING Thermostat Location Thermostat Mount the thermostat approximately five feet above the Two-Stage Heating with floor, in an area that has an inside, vibration-free wall and Two-Stage Cooling has good air circulation. Movement of air must not be obstructed by furniture, door, draperies, etc. -
Page 15: Unit Voltage
DO NOT use gas piping, or conduit as an electrical ground. Low voltage wiring from the unit control panel to the ther- mostat requires coded cable. See below for ground level and rooftop wiring. NOTE: The unit transformer is factory connected for 240V operation. -
Page 16: Down Discharge Applications
If desired, supply and return duct connections to the unit may be made with flexible connections to reduce possible unit operating sound transmission. Filters CAUTION To prevent property damage due to fire and loss equipment efficiency or equipment damage due to dust and lint build up on internal parts, never operate unit without an air filter installed in the return air system. -
Page 17: Condensate Drain
NORMAL SEQUENCES OF OPERATION Heating HOOD This unit is equipped with an ignition control that automat- ically lights the main burner. DO NOT attempt to light the main burners by any other method. Single-Stage Models: LOWER FLUE NOTE: Ignition control begins timing the HEAT HOOD SCREEN FAN OFF delay. -
Page 18: Fan Only
Two-Stage Models: If the thermostat call is for low stage cooling, the com- WARNING pressor and outdoor fan are energized at low stage. If the thermostat call is for high stage cooling, the compressor To avoid property damage, personal injury or death due to and outdoor fan are energized at high stage. -
Page 19: Gas Supply Pressure Measurement
7. Wait five minutes to clear out any gas. 8. Smell for gas, including near the ground. This is im- WARNING portant because some types of gas are heavier than air. If you have waited five minutes and you do smell HIGH VOLTAGE gas, immediately follow the warnings on page 3 of this Disconnect all power before servicing or... -
Page 20: Gas Manifold Pressure Measurement And Adjustment
6. Turn On power and close thermostat “R” and “W” con- Gas Manifold Pressure Measurement tacts, or “R” and “W1” + “W2” for two-stage models, to and Adjustment provide a call for heat. CAUTION 7. Using a leak detection solution or soap suds, check for leaks at the inlet and outlet pressure taps To prevent unreliable operation or equipment damage, the (White-Rodgers valve). -
Page 21: Gas Btu Input Check
10. Turn OFF all electrical power and gas supply to the system. 11. Remove the manometer hose from the outlet pressure tap. 12. Replace outlet pressure tap: White-Rodgers 36J22 or 36G54 valve: Turn outlet pressure test screw in to seal pressure port (clock- wise, 7 in-lb minimum). -
Page 22: External Static Pressure Check
Total External Static Checking Temperature Rise 2. Measure the static pressure of the supply duct (Posi- tive Measure). 1. All registers must be open; all duct dampers must be 3. Add the two readings together. in their final (fully or partially open) position and the unit operated for 15 minutes before taking readings. -
Page 23: Unit Shutdown
Two Stage Models: Unit Shutdown 1. Set the thermostat to lowest setting. HEATING COOLING 2. Turn off the electrical power supply to the unit. Speed Lead Speed Lead Definition Definition 3. Remove the heat exchanger door on the side of the Color Color unit by removing screws. -
Page 24: Checking Subcooling
RDS Operation Superheat Adjustment NOTE: Superheat adjustments should not be made The mitigation system is controlled by a refrigerant sen- until indoor ambient conditions have stabilized. sor(s), which is secured to a designated location(s) for This could take up to 24 hours depending on in- active monitoring. -
Page 25: Troubleshooting
NOTE: Do NOT adjust the charge based on suction The recovery equipment shall be in good working order with a set of instructions concerning the equipment that pressure unless there is a gross undercharge. is at hand and shall be suitable for the recovery of the 4. -
Page 26: Abnormal Operation - Heating
Abnormal Operation - Heating • Check flame sensor A drop in flame signal can be caused by nearly invisible Internal Control Failure coating on the sensor. Remove the sensor and carefully If the integrated ignition control in this unit encounters an clean with steel wool. -
Page 27: Abnormal Operation - Cooling
Auxiliary/Secondary Limit High Pressure Switch/Low Pressure Switch A dirty filter, excessive duct static, insufficient air flow, a (5-Ton Models ONLY) faulty limit, or a failed circulator blower can cause this limit Some models include a high pressure cutout switch and/ to open. -
Page 28: Maintenance
Servicing Measures for the Refrigerant Detection sys- Clean Outside Coil (Qualified Servicer Only) The coil with the outside air flowing over it should be in- tem: spected annually and cleaned as frequently as necessary Before servicing, identify the mode of operation of the to keep the finned areas free of lint, hair and debris. -
Page 29: Main Burner Flame (Qualified Servicer Only)
Main Burner Flame (Qualified Servicer Only) 3. Remove the burners. Flames should be stable, soft and blue (dust may cause or- 4. Use a bottle brush to clean burner insert and inside of ange tips but must not be yellow). The flames must extend the burners. -
Page 30: General Information
General Information 1. Refer to the description in Functional Parts List when ordering any of the listed functional parts. Be sure to provide the unit model and serial numbers with the order. 2. Although only functional parts are shown, all sheet met- al parts, doors, etc. -
Page 31: Blower Performance Data
BLOWER PERFORMANCE DATA A/GPGM32404031 - Rise Range: 25° - 55° T5 HIGH STATIC T4 COOLING T1 HEATING SPEED T2 HEATING SPEED T3 HEATING SPEED COOLING E.S.P. SPEED SPEED WATTS RISE WATTS RISE WATTS RISE WATTS WATTS 1,050 1,020 1,119 1,010 1,110 1,083 1,052... - Page 32 BLOWER PERFORMANCE DATA A/GPGM33604031** - Rise Range: 25° - 55° T5 HIGH STATIC T4 COOLING E.S.P. T1 HEATING SPEED T2 HEATING SPEED T3 HEATING SPEED COOLING SPEED SPEED WATTS RISE WATTS RISE WATTS RISE WATTS WATTS 1,115 1,265 1,448 1,440 1,075 1,230 1,403...
- Page 33 BLOWER PERFORMANCE DATA A/GPGM34806031 - Rise Range: 30° - 60° T5 HIGH STATIC T4 COOLING T1 HEATING SPEED T2 HEATING SPEED T3 HEATING SPEED COOLING E.S.P. SPEED SPEED WATTS RISE WATTS RISE WATTS RISE WATTS WATTS 1,055 1,380 1,415 1,851 1,780 1,000 1,320...
- Page 34 BLOWER PERFORMANCE DATA A/GPGM36008031 - Rise Range: 30° - 60° T5 HIGH STATIC T1 LOW STAGE HEATING T2 HIGH STAGE HEATING T3 LOW STAGE T4 HIGH STAGE COOLING E.S.P. SPEED SPEED COOLING SPEED COOLING SPEED SPEED WATTS RISE WATTS RISE WATTS WATTS WATTS...
-
Page 35: Ignition Control Diagnostic Indicator Chart
IGNITION CONTROL DIAGNOSTIC INDICATOR CHART (SINGLE STAGE MODELS ONLY) Red Light Signal Refer to Abnormal Heating or Cooling Operation Sections of this Manual Internal Control Failure 1 Flash External Lockout 2 Flashes Pressure Switch Stuck Open 3 Flashes Pressure Switch Stuck Closed 4 Flashes Thermal Protection Device Open 5 Flashes... - Page 36 IGNITION CONTROL DIAGNOSTIC INDICATOR CHART (TWO-STAGE MODELS ONLY) Red Light Signal Refer to Abnormal Heating or Cooling Operation Sections of this Manual Internal Control Failure 1 Flash External Lockout 2 Flashes Pressure Switch Stuck Open 3 Flashes Pressure Switch Stuck Closed 4 Flashes Thermal Protection Device Open 5 Flashes...
-
Page 37: Appendix
APPENDIX UNIT DIMENSIONS Unit Dimensions (Inches) Model Height Chassis Size A/GPGM324***31** 34 1/2 Medium A/GPGM330***31** 34 1/2 Medium A/GPGM336***31** 34 1/2 Medium A/GPGM342***31** 34 1/2 Medium A/GPGM348***31** 42 1/2 Large A/GPGM360***31** 43 1/2 Large POWER WIRE ENTRANCE 1.375 4.125 2.125 RETURN 4.75 CONDENSATE DRAIN CONNECTION... -
Page 38: High Voltage
A/GPGM3 [24/30/36] ***31 WIRING DIAGRAM HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. BREAK FOR TWO STAGE COMPRESSOR UNUSED HEAT COOL ECON... - Page 39 A/GPGM3[42/48]***31 WIRING DIAGRAM HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. BREAK FOR TWO STAGE COMPRESSOR UNUSED HEAT COOL ECON MOUNT SCREW...
- Page 40 A/GPGM360***31 WIRING DIAGRAM HIGH VOLTAGE! DISCONNECT ALL POWER BEFORE SERVICING OR INSTALLING THIS UNIT. MULTIPLE POWER SOURCES MAY BE PRESENT. FAILURE TO DO SO MAY CAUSE PROPERTY DAMAGE, PERSONAL INJURY OR DEATH. Wiring is subject to change. Always refer to the wiring diagram on the unit for the most up-to-date wiring.
- Page 41 PACKAGE UNITS - DUAL FUEL & GAS HOMEOWNER’S ROUTINE MAINTENANCE RECOMMENDATIONS We strongly recommend a bi-annual maintenance checkup be performed by a qualified service agency before the heating and cooling seasons begin. Compressor WARNING The compressor motor is hermetically sealed and does not require additional oiling.
- Page 42 Before Calling Your Servicer • Check the thermostat to confirm that it is properly set. blocked by objects (rugs, curtains or furniture). • Check the disconnect switch near the unit to confirm • Check for obstructions on the unit. Confirm that it has that it is closed.
-
Page 43: Start-Up Checklist
START-UP CHECKLIST Residen�al Package - (Indoor Sec�on) Model Number Serial Number ELECTRICAL Line Voltage (Measure L1 and L2 Voltage) L1 - L2 Secondary Voltage (Measure Transformer Output Voltage) R - C Blower Amps Heat Strip 1 - Amps Heat Strip 2 - Amps BLOWER EXTERNAL STATIC PRESSURE Return Air Sta�c Pressure IN. -
Page 44: Customer Feedback
Please fill out the feedback form on one of the following links: Goodman Brand Products: (http://www.goodmanmfg.com/about/contact-us). ® Amana Brand Products: (http://www.amana-hac.com/about-us/contact-us). ® You can also scan the QR code on the right for the product brand you purchased to be directed to the feedback page. GOODMAN BRAND ®...
