- Page 1 Scion Tech SC04.MX88 User Manual 18Gbps 8 x 8 HDMI Matrix Switch with ARC and Downscaler SC04.MX88 User Manual Version 1.0 www.scion-tech.co.uk sales@scion-tech.co.uk Tel: +44 (0) 1635 862484...
-
Page 2: Table Of Contents
Scion Tech SC04.MX88 User Manual Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
User Manual 1.0 Introduction The SC04.MX88 matrix switches 8 x HDMI inputs to 8 x HDMI outputs in a true matrix environment, any input to any output simultainiously and supports 18Gbps bandwidth with resolutions up to 4K/60Hz 4:4:4, HDR10+ and Dolby Vision™. -
Page 4: Specifications
Scion Tech SC04.MX88 User Manual 4.0 Specifications Connectivity HDMI Input: 8 x HDMI Type A, 19-Pin Female HDMI Output: 8 x HDMI Type A, 19-Pin Female Digital Audio Output: 8 x Coaxial RCA Phono Socket Analogue Audio Output: 8 x 3.5mm Stereo Jack Socket RS232: 1 x 9-Way “D”... -
Page 5: Front Panel Description
Scion Tech SC04.MX88 User Manual 5.0 Front Panel Description MENU POWER SCION Input → 18Gbps 8 x 8 HDMI Matrix Output → ENTER DOWN LOCK www.scion-tech.co.uk Number Name Function / Description Displays the matrix switching status, input / output, EDID, Baud rate and LED Screen IP address. -
Page 6: Rear Panel Description
Scion Tech SC04.MX88 User Manual 6.0 Rear Panel Description IR EXT L/R Audio Outputs Coax Audio Outputs TCP/IP RS232 DC 12V IN 1 IN 2 IN 3 IN 4 IN 5 IN 6 IN 7 IN 8 OUT 1 OUT 2... -
Page 7: Ir Remote
Scion Tech SC04.MX88 User Manual 7.0 IR Remote Input Output HDMI Matrix 1. Power / Standby: Press to power on the matrix or to set in standby. 2. Inputs: Select input source and use arrow buttons to toggle through last and next input. -
Page 8: Preparing Your Pc's Ip Address
Scion Tech SC04.MX88 User Manual 8.0 Preparing your PC for TCP/IP control To access the Web interface enter the matrix IP address in to your web browser address bar. The default IP address is 192.168.1.100 Note: If the IP address is unknown, use the RS232 interface command in section (r ip addr!) to discover the current IP settings or reset the matrix to it’s factory default settings. -
Page 9: Web Gui
Scion Tech Scion Tech SC04.MX44+ SC04.MX88 User Manual User Manual 9.0 Web GUI Enter the matrix IP address in to your computers Web Browser. When the matrix GUI opens enter the login and Password. Administrator Login User Login Username: Admin... -
Page 10: Video
Scion Tech SC04.MX88 User Manual 9.2. Video This section allows you to create “presets” to memorise commonly used crosspoint settings. 1. Select your input and output preference. 2. Click “Save” 3. The preset will activate when the “Set” button is pressed. -
Page 11: Edid Settings
Scion Tech SC04.MX88 User Manual 9.4. EDID Settings The following EDID option are available. 1080p, Stereo Audio 2.0 1080p, Dolby/DTS 5.1 1080p, HD Audio 7.1 1080i, Stereo Audio 2.0 1080i, Dolby/DTS 5.1 1080i, HD Audio 7.1 3D, Stereo Audio 2.0 3D, Dolby/DTS 5.1... -
Page 12: Outputs / Resolution Scaling / Arc
Scion Tech SC04.MX88 User Manual 9.5. Outputs This section provides information about the signal status of the outputs and allows editing of output names. 4 x 4 HDMI Matrix Admin Log Out Standby Output Settings Status Outputs Name Type Cable... -
Page 13: Network Settings
Scion Tech SC04.MX88 User Manual 9.7. Network Settings The network settings page allows the configuration of the network settings. 4 x 4 HDMI Matrix Admin Log Out Standby IP Settings Status Mode Static DHCP Video 192.168.1.100 192.168.1.1 IP Address: Gateway: Input 255.255.255.0... -
Page 14: Application Drawing
Scion Tech SC04.MX88 User Manual 10. Application Drawing Audio Amplifier Speakers Control RS232 / TCP/IP Coax Audio Outputs IR EXT L/R Audio Outputs TCP/IP RS232 DC 12V IN 1 IN 2 IN 3 IN 4 IN 5 IN 6 IN 7... -
Page 15: Maintenance And Warranty
Scion Tech SC04.MX88 User Manual 19. Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices. Servicing Damage requiring service: This product should be serviced by a qualified service engineer if: ●... - Page 16 Scion Tech SC04.MX88 User Manual Limited warranty limits and exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages...
