- Page 1 Scion Tech SC04.MX22 User Manual 18Gbps 2 x 2 HDMI Matrix Switch with Audio Extraction SC04.MX22 User Manual Version 1.0 www.scion-tech.co.uk sales@scion-tech.co.uk Tel: +44 (0) 1635 862484...
-
Page 2: Table Of Contents
Scion Tech SC04.MX22 User Manual Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc. -
Page 3: Introduction
User Manual 1. Introduction The SC04.MX22 matrix switches 2 x HDMI inputs to 2 x HDMI outputs in a true matrix environment, any input to any output simultainiously and supports 18Gbps video bandwidth with resolutions up to 4K/60Hz 4:4:4, HDR10+ and Dolby Vision™. -
Page 4: Specifications
Scion Tech SC04.MX22 User Manual 4. Specifications Connectivity HDMI Input: 2 x HDMI Type A, 19-Pin Female HDMI Output: 2 x HDMI Type A, 19-Pin Female Analogue Audio: 1 x 3.5mm Jack Socket Digital Audio: 1 x Optical Jack Power: 1 x 2.1mm DC Jack... -
Page 5: Front Panel Description
Scion Tech SC04.MX22 User Manual 5. Front Panel Description IR Sensor EDID AUTO OUT A OUT B COPY Number Name Function / Description Power LED Indicator Power LED The LED illuminates Red when the product is on or in standby... -
Page 6: Ir Remote
Scion Tech SC04.MX22 User Manual 7. IR Remote Output A Output B HDMI Matrix Button Function / Description Power ON and Standby Output A Selects input 1 or 2 to output A. Select circularly input 1 or 2 to output A Output B Selects input 1 or 2 to output B. -
Page 7: Application Drawing
Scion Tech SC04.MX22 User Manual 9. Application Drawing Speakers Audio Amplifier INPUT OUTPUT AUDIO OUT DC 5V OPTICAL Blu-Ray Player Blu-Ray Player Display Display Page 6 www.scion-tech.co.uk sales@scion-tech.co.uk Tel: +44 (0) 1635 862484... -
Page 8: 10 . Maintenance And Warranty
Scion Tech SC04.MX22 User Manual 10. Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices. Servicing Damage requiring service: This product should be serviced by a qualified service engineer if: ●... - Page 9 Scion Tech SC04.MX22 User Manual Limited warranty limits and exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages...
