Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. Surge protection device recommended This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric shock, lighting strikes, etc.
1. Introduction The 4x4 HDBaseT Matrix supports the transmission of video (up to 4K2K@ 60Hz, 18Gbps, HDCP 2.2) and multi-channel digital audio from 4 HDMI sources to 3 HDBaseT-Lite outputs and 1 independent HDMI 2.0 output. It supports audio de-embedding from any one of 4 outputs (configurable). Any source can be selected it via on-panel button, IR remote control, RS-232, LAN or Web GUI.
4. Specifications Technical HDMI Compliance HDMI 2.0b HDCP Compliance HDCP 2.2 and HDCP 1.4 Video Bandwidth Up to 18Gbps Up to 4K2K@50/60Hz(YUV4:4:4), 4K2K@30Hz, Video Resolution 1080P@120Hz and 1080P 3D@60Hz Color Space RGB, YCbCr 4:4:4, YCbCr 4:2:2 Color Depth 10-bit, 12-bit LPCM2/5.1/7.1CH, Dolby Digital, DTS 5.1, Dolby HDMI Audio Formats Digital+, Dolby TrueHD, DTS-HD Master Audio,...
Operating Temperature 0°C ~ 40°C / 32°F ~ 104°F Storage Temperature -20°C ~ 60°C / -4°F ~ 140°F Relative Humidity 20~90% RH (non-condensing) 5. Operation Controls and Functions 5.1 Front panel " Name Number Function description When device is in standby mode, the LED light in red. LED is blanking when device is working normally.
Page 6
Digital audio de-embedding output. OPTICAL AUDIO OUTPUT Analog L/R audio de-embedding output. If the front IR sensor of unit is obstructed or the unit is installed in a closed area out of infrared line IR EXT of sight, the IR receiver included can be inserted into the IR EXT port at the rear to extend the IR sensor range and enable local of the matrix.
4K2K60_420,HD Audio 7.1 4K2K60_444,Stereo Audio 2.0 4K2K60_444,Dolby/DTS 5.1 4K2K60_444,HD Audio 7.1 6 HDBaseT Receiver Panel 3 3 4 4 Number Name Function description This LED illuminates when the device is POWER connected with power supply. Plug the 24V DC power supply into the unit. DC 24V (If the device connect to the matrix, the receiver doesn't need local power supply due to POC from the matrix.)
¸ Illuminate: The Transmitter and Receiver are in good connection status. ¸ Flashing: The Transmitter and Receiver are Connection Signal Indicator Lamp in poor connection status. ¸ Dark: The Transmitter and Receiver are not connected. ¸ Illuminate: The HDMI signal with HDCP. Data Signal ¸...
Page 9
IR control is devided into two kind of control ways as below. Insert the 3.5mm IR receiver cable into IR INPUT ports at the rear of the matrix. At the same time, insert the 3.5mm IR blaster cable into IR OUTPUT ports at the rear of the matrix.
IR Pin Definition IR Receiver and Blaster pin’s definition as below: IR RECEIVER IR BLASTER 8. Remote control ① Press this button to open the power of the matrix or set it as a standby status. Output A ② Press these keys to select the output A, output B, output C or output D for output corresponding 1, 2, 3 or 4 input source.
9. Web GUI User Guide The Matrix can be controlled via Web GUI through LAN port. You must know current Matrix IP address. The static IP address is 192.168.1.100. You can connect PC Web GUI through dynamic IP adress. In this unit, you can get the IP address via PC Controller.
Page 12
General page 8/12 ① Display currently the Matrix input and output port status. The “yes” have connected input or output source and “no” represent not connection. ② Power switch. The Matrix will work when open this switch, otherwise, the Matrix will standby. ③...
Page 13
EDID page ① Set EDID mode to input source, then click “Set” button. ② Copy EDID from HDMI output port to input source, then click “Set” button. ③ Open EDID file to input source, then click “Set” button. ④ Click “Refresh” button to refresh currently EDID mode. It will diaplay currently input source EDID mode status.
Page 14
◆ In DHCP close status: HDCP switch: If the DHCP switch has been closed, user can set IP, Subnet and Gate address. In this moment, click the “Save Change” button to save current status information. (Attention: If user have set the IP address, click the “Save Change”...
