- Page 1 Scion Tech SC36.MX44 User Manual 4 x 3+1 HDMI (HDBaseT) Matrix 18G, 4K/60Hz 4:4:4, HDR SC36.MX44 User Manual Version 1.1a www.scion-tech.co.uk sales@scion-tech.co.uk Tel: +44 (0) 1635 862484...
- Page 2 Scion Tech SC36.MX44 User Manual Thank you for purchasing this product For optimum performance and safety, please read these instructions carefully before connecting, operating or adjusting this product. Please keep this manual for future reference. The manual is only for operational purposes, please contact a local dealer for maintenance assistance. The functions described in this version were updated in July 2019.
- Page 3 Scion Tech SC36.MX44 User Manual Safety Precautions ● Unpack the equipment carefully and save the packaging for possible future use. ● Follow basic safety precautions to reduce the risk of fire, electric shock and personal injury. ● Do not dismantle the housing or modify the enclosure as this may result in electric shock or personal injury.
-
Page 4: Table Of Contents
Scion Tech SC36.MX44 User Manual CONTENTS Introduction------------------------------------------------------------------------------------ Key Features-------------------------------------------------------------- Package Contents------------------------------------------------------- Specifications---------------------------------------------------------------------------------- Front Panel Description---------------------------------------------------------------------- Rear Panel Description----------------------------------------------------------------------- Receiver Front & Rear Panel Description------------------------------------------------- Application Drawing------------------------------------------------------------------------- Front Panel Button Controls----------------------------------------------------------------- 7.1 Input Selection----------------------------------------------------------- EDID Settings------------------------------------------------------------ IR Remote Control---------------------------------------------------------------------------- GUI Control (TCP/IP Interface)------------------------------------------------------------... -
Page 5: Introduction
User Manual 1. Introduction The SC36.MX44 matrix is packed with many features and delivers stunning Ultra HD video up to 70m over CAT5e/6 cable. Each HDMI source and accompanied IR signal can be routed to any display simultaneously. Outputs include 3 x RJ45 HDBaseT for CAT5e/6 and 1 x local HDMI with extracted analogue and digital audio outputs. -
Page 6: Specifications
Scion Tech SC36.MX44 User Manual 2.0 Specifications MATRIX Connections HDMI Input: 4 x HDMI Type A, 19-Pin Female HDBaseT Output: 3 x RJ45 Data socket HDMI Output: 1 x HDMI Type A, 19-Pin Female Digital Audio Output: 1 x Toslink Optical Analogue L/R Audio Output: 1 x 5-Pin Phoenix Terminal Infra-Red Input: 3 x 3.5mm Jack Socket... - Page 7 Scion Tech SC36.MX44 User Manual 2.1 Specifications RECEIVER Connections CAT5e/6/7 (HDBaseT) Input: 1 x RJ45 Data Socket HDMI Output: HDMI Type A, 19-Pin Female Infra-Red Input: 1 x 3.5mm Jack Socket Infra-Red Output: 1 x 3.5mm Jack Socket Power: 1 x DC Jack (not required when used with matrix)
-
Page 8: Front Panel Description
Scion Tech SC36.MX44 User Manual 3. Front Panel Description OUTPUT 1 OUTPUT 2 OUTPUT 3 OUTPUT 4 PRESET RECALL HOLD TO STORE Number Name Function / Description Firmware Micro-USB port for upgrading internal firmware. Power LED Illuminates Red when powered ON. -
Page 9: Receiver Front & Rear Panel Description
Scion Tech SC36.MX44 User Manual 5. Receiver Front & Rear Panel Description HDCP Link Power DC 24V HDBaseT IN HDMI Out IR In IR Out Number Name Function / Description HDMI Out Type-A female HDMI connector for display connection. IR In 3.5mm Jack socket for IR sender cable. -
Page 10: Application Drawing
Scion Tech SC36.MX44 User Manual 6. Application Drawing Ceiling Speakers Speakers IR In IR Matrix Control Multi Room Audio INPUTS IR IN OUTPUTS CONTROL TCP/IP RS232 EDID HDBT 1 HDBT 2 HDBT 3 HDMI 1 SPDIF IR OUT 4 x HDMI Signal Inputs... -
Page 11: Front Panel Button Controls
Scion Tech SC36.MX44 User Manual 7. Front Panel Button Control 7.1 Input selection The matrix can be controlled using the buttons on the front panel. Repeatedly press the the output button to cycle through the various inputs for the corresponding output. The blue LED’s will cycle when the button is pressed and settle on the chosen input. -
Page 12: Ir Remote Control
Scion Tech SC36.MX44 User Manual 8. IR Remote Control Connect the IR receiver cable to the IR EYE port of the matrix and conveniently place the eye in clear sight of the IR remote control. 1. Enter and Exit Standby mode. -
Page 13: Gui Control (Tcp/Ip Interface)
Scion Tech SC36.MX44 User Manual 9. GUI Control The matrix can be controlled using the TCP/IP interface. The default settings are: IP Address: 192.168.0.178 Subnet Mask: 255.255.255.0 Type the IP address in to your web browser to enter the log-in page and enter the user name and password. -
Page 14: Audio Settings
Scion Tech SC36.MX44 User Manual 9.2 Audio Settings Switching Audio Configuration RS232 Access Interface Network Analogue Audio Digital Audio Confirm Cancel Use the radio buttons to switch on/off the analogue and digital outputs. 9.3 Configuration - PoC (Power over Cable) -
Page 15: Edid Copy
Scion Tech SC36.MX44 User Manual 9.4 EDID Copy Switching Audio Configuration RS232 Access Interface Network EDID Copy EDID Setting Input Output HDMI 1 HDBT 1 HDMI 2 HDBT 2 HDMI 3 HDBT 3 HDMI 4 HDMI 4 Confirm Cancel Operation: 1. -
Page 16: Rs232 Settings And Control
Scion Tech SC36.MX44 User Manual 9.6 RS232 Control Switching Audio Configuration RS232 Access Interface Network ASCII Baud Rate 9600 Command Ending NULL xxxxx Command Send 1. Baud Rate: Supports: 2400, 4800, 9600, 19200, 38400, 57600, 115200 2. Command Ending: NULL, CR, LF or CR+LF can be chosen 3. -
Page 17: Interface Settings
Scion Tech SC36.MX44 User Manual 9.8 Interface Settings Switching Audio Configuration RS232 Access Interface Network Title Bar Label: Button Labels: Input Output Input 1 HDBT 1 Input 2 HDBT 2 Input 3 HDBT 3 Input 4 HDMI 4 Confirm Cancel ●... -
Page 18: Maintenance And Warranty
Scion Tech SC36.MX44 User Manual 10. Maintenance Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices. Servicing Damage requiring service: This product should be serviced by a qualified service engineer if: ●... - Page 19 Scion Tech SC36.MX44 User Manual Limited warranty limits and exclusions This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER...
