Instructions
DataTrak
For providing cycle count and material usage information for E-10 sprayers. For
professional use only.
Accessory Kit 25M269 and 25P193
Important Safety Instructions
Read all warnings and instructions in this manual
and in the spray package manual. Save all
instructions.
®
Kits
3A4385B
EN

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DataTrak 3A4385B and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Graco DataTrak 3A4385B

Summary of Contents for Graco DataTrak 3A4385B

  • Page 1 Instructions ® DataTrak Kits 3A4385B For providing cycle count and material usage information for E-10 sprayers. For professional use only. Accessory Kit 25M269 and 25P193 Important Safety Instructions Read all warnings and instructions in this manual and in the spray package manual. Save all instructions.

  • Page 2: Table Of Contents

    Graco Standard Warranty ....12 Graco Information ......12...

  • Page 3: Warnings

    Warnings Warnings The following warnings are for the setup, use, grounding, maintenance, and repair of this equipment. The exclamation point symbol alerts you to a general warning and the hazard symbols refer to procedure-specific risks. When these symbols appear in the body of this manual or on warning labels, refer back to these Warnings. Product-specific hazard symbols and warnings not covered in this section may appear throughout the body of this manual where applicable.

  • Page 4: Installation

    Installation Installation 4. With cover removed, place magnet (A) on the crank shaft. Prepare to Install 1. See E-10 or E-10hp manual and follow the instructions in the Before Beginning Repair section, including the Pressure Relief Procedure. 2. Disconnect all line power to the sprayer. Install the Kit 1.

  • Page 5: Check Datatrak Operation

    Installation 10. Reassemble module and slide DataTrak (D) into the mounting bracket (C). Check DataTrak Operation 1. Cycle the sprayer in slow recirculation mode. 2. Cycle the sprayer in fast recirculation mode for at least 10 cycles to ensure no errors. NOTE: The DataTrak pump icon should move when the pump rotates.

  • Page 6: Datatrak Controls And Indicators

    DataTrak Controls and Indicators DataTrak Controls and Indicators Reset Key (Resets faults. Press and hold for E-10 Type (user settable) 3 seconds to clear the batch totalizer.) Push Flow Rate Units (user settable to gpm [US], to toggle between flow rate and cycle rate. gpm [Imperial], oz/min [US], oz/min [Impe- Cycle/Flow Rate rial], l/min, or cc/min)

  • Page 7: Datatrak Operation

    DataTrak Operation DataTrak Operation The display (AE) will turn off after 1 minute to save 2. While in Prime/Flush mode, the batch totalizer (BT) battery life. Press any key to wake up the display. will not count. The grand totalizer (GT) continues to count.

  • Page 8: Datatrak Diagnostic Codes

    DataTrak Diagnostic Codes DataTrak Diagnostic Codes When the monitor detects a problem, the LED will flash To acknowledge the diagnosis and return to normal and a diagnostic code will appear on the display. operating screen, press once to wake up the display, and once more to clear the diagnostic code screen.

  • Page 9: Repair

    • Energizer alkaline #522 3. Replace with a new fuse. • Varta alkaline #4922 NOTE: Use only a Graco-approved replacement fuse. Order Part 24V216. Replace Battery 1. Remove DataTrak module (D) from bracket. See . 7. . 8. DataTrak Battery and Fuse Location .

  • Page 10: Parts

    Parts Parts Ref. Part Description Qty. MODULE, DataTrak, cycle counter KIT, cover, cycle counter, E-10 BRACKET, wall mount, DataTrak 119875 MAGNET, disc, 0.38 diameter, 0.100 thick 3A4385B...

  • Page 11: California Proposition 65

    California Proposition 65 California Proposition 65 CALIFORNIA RESIDENTS WARNING: Cancer and reproductive harm – www.P65warnings.ca.gov. 3A4385B...

  • Page 12: Graco Standard Warranty

    With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
