The Charge LED flashes red when charging and flashes green when fully charged. The Charge LED is visible when the
printer's lid is open or closed. A complete charge takes approximately 7-9 hours. For more information on the Charge
PrintPAD MC65 LEDs and Indicators on page 6
LEDs, see
Note: To obtain full battery capacity, a new battery must cycle through two to three charges. To restart a charge,
unplug the power cord. Wait 30 seconds, then replug the power cord.
The MC65 Handheld Computer will charge while power is plugged into the DC power port.
Caution: Do not plug DC power into the internal and external power ports at the same time.
Do not plug the DC power supply into the printer if the printer is being charged by means of external charge
contacts.
Determining Battery Condition
You can determine the relative battery condition by printing a self-test. For more information, see
on page 5
. On the printout, "Battery Volt" varies between 6.8 and 8.4 volts.
Caution: There is a risk of explosion if the battery is replaced by an incorrect type. Dispose of used batteries
according to the instructions.
The operating temperature of this portable printer is 50° C. However, the operating temperature when used with
Datamax-O'Neil power supply for charging the portable printer is limited to 40° C. Charge the printer in a suitable
location that meets this temperature requirement.
(For US/Canada) Use only the Datamax-O'Neil part number 220240-100 power supply with this product.
Installing the Driver
Note: Before using a MC65 and the printer, it is necessary that the appropriate USB driver is installed. Refer to the
USB Installation Guide for more information.
1. Go to datamax-oneil and click
2. Install the driver onto the handheld computer.
Using a Handheld Computer (HHC)
1. Insert the handheld into the cavity by sliding it in from the top.
2. Press down until the handheld is fully latched and seated (Figure 5).
Compatible Handheld Computers
Note: The PrintPad MC65/67 series is intended for use with the UL Listed Accessory Handheld Computer Askey
Computer Corp MC65 series or the UL Listed Accessory Handheld Computer Askey Computer Corp MC67 series.
.
Support
to obtain the appropriate driver for the PrintPAD MC65.
3
PrintPAD MC65 USER'S GUIDE
