Dauphin AIKO Operating Instructions

1
2

Backrest Lumbar Adjustment

1
To Adjust: Slide the lumbar support on the back of the
backrest and raise or lower to desired position.
2

Adjustable Arm Height

To Adjust: Push button on seat arm just below the pad while
holding it in, bring to preferred position and let go to lock into place.

Adjustable Arm Width

3
To Adjust: Move lever backward to unlock, then adjust in or out
depending on preference and then move the lever forward to lock
into position.
4
Seat Depth
To Adjust: Push in the button under the right side of the
seat. Move the seat forward or backward to the desired
position and release the button to lock.
USA: 100 Fulton Street Boonton, NJ 07005
3
4
5
6
TEL: 1.800.631.1186 FAX: 1.800.220.3844 EMAIL: info@dauphin.com WEB: www.dauphin.com
Operating Instructions
7
Seat Tilt Adjustment
5
To Adjust: Rotate the rear lever on the back of the seat,
right hand side. Rotate lever up or down.

AutoSync Mechanism

6
.
To Enhance the Backrest Tension: Turn the end
of the lever clockwise. To loosen, turn the end of the lever
counter-clockwise.
Seat Height Adjustment Lever
7
To Adjust: Pull up the right-hand lever to adjust the seat height.
The angle between your lower leg and thigh should be at
least 90° with your feet flat on the floor.
Variable Backrest Limiter
8
To Adjust: Turn the lever under the left side of the seat. Slide
the back away to pull the seat to the desired position.
AIKO
