Summary of Contents for Fluke 67 MAX
- Page 1 67 MAX Infrared Thermometer Calibration Manual March 2021 (English) © 2021 Fluke Corporation. All rights reserved. Specifications are subject to change without notice. All product names are trademarks of their respective companies.
- Page 2 Fluke authorized resellers shall extend this warranty on new and unused products to end-user customers only but have no authority to extend a greater or different warranty on behalf of Fluke. Warranty support is available only if product is purchased through a Fluke authorized sales outlet or Buyer has paid the applicable international price.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction......................Contact Fluke ...................... Safety Information ....................Specifications ...................... Maintenance ......................Change the Battery..................Clean the Product..................Calibration ......................Preliminary Requirements ................Required Environmental Conditions for Calibration........Required Equipment..................Procedure ..................... Setup ......................Black Body Source ................ - Page 4 67 MAX Calibration Manual...
-
Page 5: Introduction
Introduction The Fluke 67 MAX IR Thermometer (the Product) is a non-contact, clinical infrared (IR) thermometer that measures the amount of infrared energy radiated by the subject's skin at a reference point to determine a subject's temperature. WWarning Read all safety information before you use the Product. - Page 6 67 MAX Calibration Manual Note • The Product is not FDA Approved or cleared. • The Product is intended for consumer use and is NOT INTENDED for use to collect information for medical diagnosing purposes. • The Product complies with the FDA Enforcement Policy for Clinical Electronic Thermometers During the Coronavirus Disease 2019 (COVID-19) Public Health Emergency.
-
Page 7: Specifications
Date of Manufacture Ô Õ Serial Number Medical Device ¸ ¹ Protected against the ingress of >1 Catalog Number mm diameter solid foreign objects º Ó and dripping water Specifications For Product specifications, refer to the 67 MAX Users Manual. -
Page 8: Maintenance
67 MAX Calibration Manual Maintenance Change the Battery To install or change the AA IEC LR6 battery, open the battery compartment and replace the battery as shown in Figure 1. Battery should be replaced when the low-battery indicator appears. •... -
Page 9: Calibration
Verification of the DUT that tests each function and range for compliance to specifications. After you do this procedure, if the DUT does not meet its specifications, it should be sent to a qualified Fluke Service Center for adjustment. See Contact Fluke. -
Page 10: Required Environmental Conditions For Calibration
67 MAX Calibration Manual Required Environmental Conditions for Calibration Ambient temperature and humidity must be stable during calibration: • Temperature range: 73 °F ±3 °F (23 °C ±3 °C) • Ambient relative humidity: <70 %RH During this process: • Keep the DUT lens housing at a constant temperature. Do not hold the DUT by hand on the lens housing. -
Page 11: Procedure
Ensure the thermometer fits easily into the 4180 measurement well. Setup Fluke highly recommends that a calibration fixture be used. Black Body Source The calibration station consists of black body sources that are measured by a precision thermistor thermometer and a thermometer readout. -
Page 12: Prepare The Black Body Source
67 MAX Calibration Manual Figure 2. Precision Black Body Source System (PBBS) 84.9814 C Prepare the Black Body Source Make sure that the black body is powered on and is allowed to warm up for at least 1 hour. To configure the black body: 1. -
Page 13: Prepare The Reference Thermometer System For Measurement
Infrared Thermometer Calibration 3. On the black body menu: a. Push F1 > TEMP SETUP b. Select IRT ε c. Push ENTER to allow you to edit this field and type in 0.98. d. Push ENTER to save the value. Prepare the Reference Thermometer System for Measurement To prepare the Reference Thermometer System for Measurement: 1. -
Page 14: Calibrate The Dut
3. If the DUT is being held in hand, the technician must hold the DUT at the correct measurement distance while ensuring that the DUT is geometrically centered on the target. Fluke highly recommends that a calibration fixture be used. 4. Simultaneously record the DUT IR temperature readings, ambient temperature, and reference thermometer readings with these instructions. -
Page 15: Analyzing Test Results
Infrared Thermometer Calibration 5. Calculate and record the average of the ambient temperature measurements. Compare the average with the Ambient Temperature Limit listed in Table 3. If the average temperature exceeds this limit, make sure the distance is correct and repeat the test. 6. -
Page 16: User-Replaceable Parts
To order replacement parts, call one of the numbers listed under Contact Fluke. User-replaceable parts are listed in Table 4. Table 4. User-Replaceable Parts Fluke Part Description Number BATTERY,PRIMARY,ZN- 376756 MNO2,1.5V,2.24AH,15A,LR6,ALKALINE,AA,14X50MM,BULK 4103199 FLUKE-62MAX-2014,BATTERY DOOR ASSEMBLY 5224967 FLUKE-67 MAX-8002,LEFT DECAL,3M DROP 5224971 FLUKE-67 MAX-8003,RIGHT DECAL,SAFETY MARKINGS 5224845 FLUKE-67 MAX-8001,REAR DECAL...
