Page 1: Users Manual
® 63/66/68 Infrared Thermometers Users Manual PN 2149032 September 2004 Rev. 3, 6/09 © 2004-2009 Fluke Corporation. All rights reserved. Printed in China. Specifications are subject to change without notice. All product names are trademarks of their respective companies. - Page 2 LIMITED WARRANTY AND LIMITATION OF LIABILITY This Fluke product will be free from defects in material and workmanship for two years from the date of purchase. This warranty does not cover fuses, disposable batteries, or damage from accident, neglect, misuse, alteration, con- tamination, or abnormal conditions of operation or handling.
-
Page 3: Table Of Contents
Table of Contents Title Page Introduction............1 Contacting Fluke ..........1 Safety Information ..........2 Symbols and Safety Markings......3 Features ............5 Display ............. 7 Display (63)............ 8 Display (66/68)..........8 Buttons (66/68)..........9 How the Thermometers Work......9 Operating the Thermometer ...... - Page 4 63/66/68 Infrared Thermometers Using a Contact Temperature Probe (PRB) (66/68) ............18 HOLD ............19 Storing Data (66/68) ........19 Recalling Data (66/68) ........19 LOG Clear Function........19 Maintenance ............ 20 Changing the Battery........20 Cleaning the Lens.......... 20 Cleaning the Housing ........
-
Page 5: Introduction
63/66/68 Introduction The Fluke Models 63, 66, and 68 Infrared Thermometers (“the thermometers”) are for non-contact temperature measurement. These thermometers determine an object’s surface temperature by measuring the amount of infrared energy radiated by the object’s surface. See Figure 2. -
Page 6: Safety Information
63/66/68 Infrared Thermometers Safety Information Warning A Warning identifies conditions and actions that pose hazards to the user. To avoid electrical shock or personal injury, follow these guidelines: * Do not point laser directly at eye or indirectly off reflective surfaces. Before using the thermometer inspect the case. -
Page 7: Symbols And Safety Markings
Risk of danger. Important information. See Manual. Hazardous voltage. Precedes warning Warning. Laser. Conforms to requirements of European Union and European Free Trade Association (EFTA) Celsius Fahrenheit Battery Do not dispose of this product as unsorted municipal waste. Go to Fluke’s website for recycling information. - Page 8 63/66/68 Infrared Thermometers MADE IN CHINA 9V NEDA 1604 MFG DATE: Dec 29, 2004 SERIAL #: 2421540101-0070 LASER / LIGHT ˚C ˚F 66/68 MADE IN CHINA 9V NEDA 1604 MFG DATE: Dec 29, 2004 SERIAL #: 2423260201-0030 LOCK ˚C ˚F OFF ON ame0010.eps Figure 1.
-
Page 9: Features
63/66/68 Features Features The thermometers include: Single-spot laser sighting MAX temperature display Backlit display Durable, ergonomic construction Tripod mount Hard case and wrist strap MAX, MIN, DIF, AVG temperature displays (66/68) Adjustable emissivity (66/68) High and low alarm (66/68) Data logging (66/68) Trigger Lock (66/68) Contact probe jack (66/68) -
Page 10: Display (63)
63/66/68 Infrared Thermometers Laser Display (66/68 shown) 63: Backlight On/Off Battery Door 66/68: Trigger Release Button Lock On/Off Trigger Battery Cover ame007.eps Figure 2. Infrared Thermometer... -
Page 11: Display
63/66/68 Display Display ame001.eps Backlight “On” symbol (63/66/68) C/ F symbol (Celsius/Fahrenheit) (63/66/68) High alarm and low alarm symbol (66/68) Maximum temperature display (63) Temperature values for the MAX, MIN, DIF, AVG, HAL, LAL, PRB (66/68) Icon for MAX (63/66/68) Icon for MIN, DIF, AVG, HAL, LAL, PRB (66/68) LOG icon shows log mode for data storage (66/68) Live temperature value (63/66/68) -
Page 12: Display (66/68)
63/66/68 Infrared Thermometers Display (63) In the SCAN mode, the backlit reading displays both the live temperature (G) and maximum temperature (D) in Celsius or Fahrenheit (B). The thermometer holds the last reading for 7 seconds after the trigger is released and “HOLD” appears (H). Display (66/68) In SCAN mode, both the live temperature (G) and the selected mode function (D,E) are displayed in Celsius or Fahrenheit (B). -
Page 13: Buttons (66/68)
63/66/68 Buttons (66/68) Buttons (66/68) Sets high and low alarm Up and down Cycles through the function loop Laser/Backlight on/off button (pull trigger and press button to activate laser/backlight) LOG button (for storing data) How the Thermometers Work Infrared thermometers measure the surface temperature of an opaque object. -
Page 14: Operating The Thermometer
63/66/68 Infrared Thermometers Reflected energy Emitted Transmitted energy Energy Target ame002.eps Figure 3. How the Thermometer Works Operating the Thermometer Temperature Measurement To measure temperature, point the unit at an object and pull the trigger. Be sure to consider distance-to-spot size ratio and field of view. -
Page 15: Distance And Spot Size
63/66/68 Operating the Thermometer ame003.eps Figure 4. Locating a Hot or Cold Spot Distance and Spot Size As the distance (D) from the object being measured increases, the spot size (S) of the area measured by the unit becomes larger. The relationship between distance and spot size for each unit is shown in Figure 5. - Page 16 63/66/68 Infrared Thermometers 132 mm @ 1500 mm D:S=12:1 75 mm @ 900 mm 38 mm @ 300 mm 5.3 " @ 3 " @ 60 " 36 " 1.5 " @ 12 " 62 mm @ 1500 mm D:S=30:1 30 mm @ 900 mm 24 mm @...
-
Page 17: Field Of View
63/66/68 Operating the Thermometer Field of View Make sure that the target is larger than the unit’s spot size. The smaller the target, the closer you should be to it. See Figure 6. ame004.eps Figure 6. Field of View Emissivity Emissivity describes the energy-emitting characteristics of materials. - Page 18 63/66/68 Infrared Thermometers reach the same temperature as the surface beneath it. Measure the temperature of the tape or painted surface. The 66/68 thermometers allow you to adjust the unit’s emissivity for the type of surface being measured. Refer to Table 2. Table 2.
-
Page 19: Switching C And F
63/66/68 Operating the Thermometer Table 2. Surface Emissivity (cont.) Measured Surface Emissivity Measured Surface Emissivity Steel Clay 0.95 Cold-Rolled 0.7-0.9 Concrete 0.95 Ground Sheet 0.4-0.6 Cloth 0.95 Polished Sheet Glass Zinc Plate 0.85 Oxidized Gravel 0.95 NON-METALS Gypsum 0.8-0.95 Asbestos 0.95 0.98 Asphalt... -
Page 20: Trigger Lock (66/68)
63/66/68 Infrared Thermometers Trigger Lock (66/68) To lock the unit on for continuous measurement, slide the bottom switch down. See Figure 2. If the trigger is pulled while the unit is locked on, the laser and backlight will turn on if they have been activated. -
Page 21: Selecting A Function (66/68)
63/66/68 Operating the Thermometer ame006.eps Figure 7. Function Cycle Selecting a Function (66/68) To select the MAX, MIN, DIF, or AVG mode, pull the trigger. While holding the trigger, press until the appropriate icon appears in the lower left corner of the display. Each time is pressed, the thermometer advances through the function cycle. -
Page 22: Setting The High Alarm, Low Alarm, And Emissivity (66/68)
63/66/68 Infrared Thermometers Setting the High Alarm, Low Alarm, and Emissivity (66/68) To set values for the High Alarm (HAL), Low Alarm (LAL), and Emissivity, pull the trigger or press to activate the display. Press until the appropriate icon appears in the lower left of the display. -
Page 23: Hold
63/66/68 Operating the Thermometer HOLD The unit’s display will remain activated for seven seconds after the trigger is released, unless the unit is locked on (lock on 66/68 only). HOLD appears in the upper left of the display. During HOLD or after the unit shuts off, recall stored values by pressing without pulling the trigger (66/68). -
Page 24: Maintenance
63/66/68 Infrared Thermometers mode. It can be used when the thermometer has any number of log locations stored. Note Only use the LOG Clear function if you want to clear all the LOG location data that is stored in the unit’s memory. To use LOG Clear, while in LOG mode, pull the trigger then press until the unit reaches LOG location “0”. -
Page 25: Troubleshooting
40 C (104 F) Possible damage by Contact your distributor Accessories Optional accessories for the thermometers are: Contact probe (RTD) (66/68) - Fluke PN 2148313 Nylon Soft Carrying Case – Fluke PN 2152040 NIST/DKD certification... -
Page 26: Ce Certification
63/66/68 Infrared Thermometers CE Certification The thermometers conform to the following standards: EN61326-1 EMC EN61010-1 EN60825-1 Safety Certification testing was conducted using a frequency range of 80- 1000 MHz with the instrument in three orientations. Notes 63: Between 165 MHz and 880 MHz ( 5%) at 3 V/m, the instrument may not meet its stated accuracy. - Page 27 63/66/68 Specifications Distance to Spot Ratio 12:1 30:1 50:1 Emissivity (Adjustment for surface measured) Pre-set at 0.95 66/68: Digitally adjustable from 0.10 to 1.0 Response Time 500 mSec Repeatability ±0.5 % of reading or ±1 °C (±2 °F), whichever is greater Spectral Response 8 m to 14 m Laser Sighting...
- Page 28 63/66/68 Infrared Thermometers Optional Contact Probe (66/68) Temperature Range -40 °C to 260 °C (-40 °F to 500 °F) Accuracy (Assumes ambient operating temperature of 23 °C (73 °F) to 25 °C (77 °F)) ±1% of reading or ±1°C (±2°F), whichever is greater Certifications: CE,...
