Robot Coupe R5 Plus Manual page 6

3) Engage the blade on
the motor shaft and lo-
wer it right to the bottom
of the bowl.
Make sure that it is cor-
rectly positioned, by rota-
ting it in the bowl.
4 ) Place the lid on the
bowl and rotate to the
right until it clicks.
The device is now ready
for use. The green light
sho uld ther efo r e b e
illuminated.
TECHN ICAL
SPECIFICATION S
• DESCRIPTION AN D ADVAN T AGES
- 5 .5 -litre stainless steel bow l for models R5 Plus
and R5 V.V.
- 6 .5 -litre stainless steel bow l for models R6 and
R6 V.V.
- A patented blade, an exclusive RO BO T-CO UPE
feature, gives per fect result for small or large
quantities.
- N ew blade profile for optimum cutting quality.
- Pulse contro l for better cutting precision.
- Automatic bowl locking.
- Extremely simple unlocking of bowl by means of a
trigger fitted in the handle.
- Lid designed to allow the addition of liquid or ingre-
dients during processing.
- Models R5 Plus and R5 V.V. are equipped with a
straight blade knife supplied as standard equip-
ment and can be provided with an optional serra-
ted blade for grinding and kneading tasks.
- Models R6 and R6 V.V. are supplied with an all-
sta inless steel stra ight bla de knife that is fully
removable and can be fitted with serrated blades.
- Flat motor base for easier fitting and cleaning of at-
tachments.
- Models R5 Plus and R6 (three-phase) are provided
with two speeds 1500 and 3000 Rpm.
- Model R5 Plus (single-phase) is provided with one
speed of 1.500 Rpm.
- Models R5 V.V. and R6 V.V. are equipped with a
speed variation which varies between 3 0 0 and
3.000 Rpm to ensure more flexible use and give a
wide range of tasks.
- Machines in compliance with strictest hygiene and
safety standards .
• PACKAGIN G
The packaging for these models has been specially
designed to prevent damage occurring in transit.
Details of the contents are clearly marked on the
packaging:
- type of device;
- voltage;
- attachments (if any);
- serial number;
Dimensions (in mm):
Heigh 580 Lenght 500 W idth 400.
• W EIGHT
net weight
R5 Plus 24 kg
R5 V.V. 25 kg
R6 25 kg
R6 V.V. 26 kg
• DIMEN SION S (in mm)
R5 Plus R5 V.V.
A 480 480 520
B 350 350 350
C 280 280 280
265 265 265
D
• W ORKIN G HEIGHT
We recommend that you position the food processor on
a stable worktop so that the upper edge of the large feed
hopper is at a height of between 1.20 m and 1.30 m.
• N OISE LEVEL
The equivalent continuous sound level when the food
processor i s operati ng on no-load i s less than
70 db (A).
The cutter will enable your to perform all your cutting
tasks in minimum time; we recommend therefore, that
you keep a close eye on the mixture in order to ob-
tain the desired results.
gross weight
26 kg
27 kg
27 kg
28 kg
R6 R6 V.V.
520
350
280
265
EXAMPLES
