WIDE SPAN
STORAGE RACKS
TOOLS NEEDED
Rubber Mallet
Upright Post x 4 (A)
Board (E) or Wire (F) x 3 (or 6)
B
A
B
PAGE 1 OF 2
Side Support x 6 (B)
Figure 1
PARTS LIST
Front/Back Support x 6 (C)
ASSEMBLY
NOTE: Lean posts against a wall or assemble with
another person.
1. Connect two upright posts (A) by inserting a side
support piece (B) at the bottom and top of the posts.
(See Figure 1)
2. Repeat step one for the other two upright posts (A).
Center Support x 3 - 9 (D)
NOTE: Boards and wire
come as two pieces for 60,
72, and 96" wide racks.
1211 IH-1060
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for U-Line ih-1060
Summary of Contents for U-Line ih-1060
- Page 1 1. Connect two upright posts (A) by inserting a side support piece (B) at the bottom and top of the posts. (See Figure 1) 2. Repeat step one for the other two upright posts (A). Figure 1 PAGE 1 OF 2 1211 IH-1060...
- Page 2 72" W −2 Shelf Supports 96" W −3 Shelf Supports Figure 4 7. Set boards (E) or wire (F) on top of shelf supports, side supports, and front/back supports. (See Figure 5) Figure 5 PAGE 2 OF 2 1211 IH-1060...
