3. If the sensor was mistakenly registered in a wrong zone, click on its
"Properties" button. The settings window will appear permitting to select a new
zone for the sensor (Picture 5). You can also open the detector properties menu
by clicking the corresponding button opposite the detector in the general list of
the "Radio devices" tree.
Picture 5. The sensor's properties' menu makes it possible to register the sensor
When an additional wire sensor is connected to the external digital input of the
wireless sensor, in the properties activate the checkbox "Additional input"
(Picture 5). If a sensor (for example, a LeaksProtect) is designed for working 24
h, activate in the checkbox properties "24 h active". 24 h sensors and normal
sensors should not be placed in the same zone! If necessary, adjust the sensor's
sensitivity.
4. When the sensors are successfully registered in the security system, click the
button "Write" (Picture 4) to save sensors' con guration data in the ocBridge
Plus receiver's memory. When ocBridge Plus connected to the PC, click the
button "Read" (Picture 4) to read the pre-saved sensors' con guration from the
ocBridge Plus memory.
Make sure that installation location of sensor, has a stable radio contact with the
ocBridge Plus receiver! A maximum distance of 2000 m (6552 ft) between the sensor
Picture 4. Device registration window
in the zone
