nd the information on the current software version;
download the help le.
Picture. 10. "Help" menu
4. On page "Radio zones" (Picture 11) it is possible to create required the
detection zones areas required and to add there sensors and devices (consult
Sensors' handling) and also to set the additional parameters of sensors',
devices' and zones functioning (consults Managing the central unit).
Picture 11. Radio zones
5. The buttons "Write" and "Read" are used for saving data in ocBridge memory
and for reading current con guration settings (Sensors' handling).
6. "Events memory" page stores information about alarming events (Picture 12),
service events (Picture 13) and statistics tables (Picture 14). It is possible to
renew information in data logs or to clear them with "Log reset" button. The logs
contains up to 50 alarming events and 50 service events. With the button "Save
in le", it is possible to save the events logs in xml format which can be opened
with Excel.
