AJAX ocBridge Plus User Manual page 4

Green light is permanent, red light does not
blink
Green — blinks once per second (before, the
green light was permanent), and the red —
blinks during 30 seconds
The red blinks momentarily
The green — blinks for 10 minutes and the red is
permanent;
no red light
No green and red light
Permanent red light
Permanent green light, the red light is blinking
very fast
Green light blinks momentarily
Red/green- blinks momentarily
2. All devices that you want to connect to the ocBridge Plus must be registered
with a help of «Ajax ocBridge Plus con gurator». In order to register the
sensors, it is necessary to create radio zones in the con gurator in case of it had
not been done before. To do this select the "Radio zone" and click «Add zone»
button (Picture 3).
ocBridge Plus is in con guration mode. In
con guration, there are Pages "Radio zones" or
«Events memory» are opened. During this
period, the sensors do not receive the
responses to the alarm signals and statuses
New radio set unit detection mode is on
A moment when the ocBridge Plus receiver
register a new device
Searching for all devices after the previously
saved PC con guration is downloaded,
system is armed;
system is disarmed
The receiver is in in the operating mode, the
system is disarmed
The receiver is in operating mode, the system is
armed
Radio signal is tested in order to connected
sensor or other device
New detectors' polling period started, 36
seconds by default
Failure is detected
