- Page 1 GTKPRO2 Quick Start Guide GPS TRACKING ADVANCED VEHICLE TELEMATICS gatortracking.com.au...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Table of contents..........2 Information guide..........3 Introduction...........3 Not included.............4 Detailed product overview........4 Knowing your device........5 Setting Up Your Device........6 Wiring diagram..........8 Installation............9 Led indications..........10 Location and orientation considerations..11 Server connection and new account setup..12 Login screen............13 Main screen.............14 Add object............15 Devices............16 Technical specifications........17... -
Page 3: Information Guide
We recommend you download the latest version of the guide, as well as check for more information and instructional videos from our website at Gatortracking.com.au INTRODUCTION The GTKPRO2 vehicle tracking, telematics device is supplied with all the equipment that is necessary for basic tracking operation. The package contains: • GTKPRO2 device •... -
Page 4: Not Included
• Bluetooth remote sensors. (Third party supplied) DETAILED PRODUCT OVERVIEW The GTKPRO2 is a professional real-time tracking device with GNSS and LTE CAT-M1 connectivity and backup battery. This device is pre-configured to Simultaneously use the US based GPS and the Russian based GLONASS global satellite navigation systems. -
Page 5: Knowing Your Device
KNOWING YOUR DEVICE... -
Page 6: Setting Up Your Device
SETTING UP YOUR DEVICE 1. Gently remove bottom cover using plastic pry tool from both sides. Then remove the top cover. 2. Insert the supplied M2M Micro-SIM card. Make sure that Micro-SIM card cut-off corner is pointing forward to the left looking from above. Figure 1 Cover removal Figure 2 SIM card insert NOTE: DO NOT INSERT THE INCLUDED SIM CARD IN ANY OTHER DEVICE OTHER THAN THIS... - Page 7 SETTING UP YOUR DEVICE 3. Connect the battery as shown to device. Position the battery in place where it does not obstruct other components. (Especially the Transceiver modules (large square metal can looking components) Do not insert a 3rd party SIM card in this device. 4.
-
Page 8: Wiring Diagram
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
Page 9: Installation
INSTALLATION When wiring up your device, please pay careful attention to the dual colours of some wires. Connecting power source Be sure to locate your constant power wire after the car computer goes to sleep mode this may happen in 5 to 30 minutes period after turning the car off and removing the key. After installation, measure the voltage at the module again to make sure it has not decreased. -
Page 10: Led Indications
LED INDICATIONS NAVIGATION LED INDICATIONS BEHAVIOUR MEANING Permanently on GNSS signal is not received Blinking every second Normal operation, GNSS is working Off GNSS is turned off Device is not working or Device is in sleep mode Blinking fast constantly Device firmware is being flashed STATUS LED INDICATIONS BEHAVIOUR MEANING... -
Page 11: Location And Orientation Considerations
LOCATION AND ORIENTATION CONSIDERATIONS IMPORTANT NOTE: The Unit must be installed with the Writing side of the module facing up. Failure to do so will result in pure GPS positioning. (It is advised to secure the Module in place AFTER your wiring is complete and you have turned the device on to test that it’s working. -
Page 12: Server Connection And New Account Setup
The Gator Tracking server is for the exclusive use of Gator branded tracking devices. Gator customers are eligible to register an account at anytime for free. However the devices added to the account require a Subscription in order to work beyond 30 days from activation. -
Page 13: Login Screen
LOGIN SCREEN Select “create account", enter the email address you would like to use, make sure you get this correct as a password will be sent directly to it (one-time). Enter your details, press "Register", then wait a second for the success notice, which will ask you to check your email for the password. -
Page 14: Main Screen
MAIN SCREEN You can now add your Gator tracking device to your account by pushing the "Add Object" button in the main view. -
Page 15: Add Object
ADD OBJECT When you select add object this will bring up a box that lets you enter details about the device, confirm that you've configured it, and save it. You will also have the option of adding a subscription for your tracker. -
Page 16: Devices
QvmDIjbsDCB9bNFA or search “Gator tracking” and look for videos with this logo. You can also visit the app store and download the Mobile app. Under “Gator Tracking”... -
Page 17: Technical Specifications
TECHNICAL SPECIFICATIONS GNSS GPS, GLONASS, GALILEO, BEIDOU, QZSS, AGPS (Configured for GPS and GLONASS only) Receiver Tracking: up to 33 satellites Tracking sensitivity -165 dBM Accuracy < 3 m (Accuracy depends on PDOP metrics (satellite qty and spread) Hot start <... - Page 18 TECHNICAL SPECIFICATIONS BLUETOOTH/ CAN 4.0 + LE Supported BT peripherals Temperature and Humidity sensors, Universal BLE sensors support (Requires extra configuration and server admin approval) Supported CAN peripheral Peripheral data to server is not supported under all subscription plans. CAN data plans on request. (Requires extra configuration and server admin approval) INTERFACE (Digital High/Lo) D1 - Ignition detection (High), D2 door open...
- Page 19 TECHNICAL SPECIFICATIONS PHYSICAL SPECIFICATION Dimensions 65 x 56.6 x 20.6 mm (L x W x H) Weight 55 g OPERATING ENVIRONMENT Operating temperature (without battery) -40 °C to +85 °C Storage temperature (without battery) -40 °C to +85 °C Operating humidity 5% to 95% non-condensing Ingress Protection Rating IP41...
-
Page 20: Technical Assistance
TECHNICAL ASSISTANCE If you need assistance setting up or using your Gator product now or in the future, call Gator Support. Australia TEL: 03 – 8587 8898 FAX: 03 – 8587 8866 Mon-Fri 9am – 5pm AEST Copyright © 2017 by TDJ Australia All rights reserved.
