Note 8 - Definition of U8_OPRST_OPERATING_STATE
Value Precedence
0 n/a
1 8
2 7
3 6
4 1
5 2
6 3
7 5
8 4
9 to 255 n/a
Note 9 - Definition of wRelayState
Bit Meaning
0 Relay1
1 Relay2
2 Relay3
3-7 for future expansion
Note 10 - Definition of wCommands
Command
no operation
end Inhibit
start Inhibit
reset alarms and faults
get newest record
get oldest record
get next newer event
get next older event
for XNX future expansion
Note 13 - Meaning of iFaultWarnNumber
Value Interpretation
0 No fault or warning exists
1 to 999 No fault exists. The warning number is reported
1000 to 1999 A fault exists. Fault number plus 900 is reported
Meaning
reserved
normal monitoring
warm-up/start-up
inhibit
alarm
not used
not used
warning
fault
for future expansion
Value of wCommand (MSB byte, LSB byte)
NA
NA
NA
NA
Group, 0x18
Group, 0x19
Group, 0x1A
Group, 0x1B
all others
Group definition:
Group value can be set from 0 to 2
Group 0 – internal and security events (and
all other uncategorised events)
Group 1 – alarm and proof test events
Group 2 – service events
