Honeywell SEARCHLINE EXCEL PLUS Technical Manual page 77

Modbus Holding Register
Address
First Last Qty
40062 40074 13
40075 40081 7
40082 40083 2
40084 40084 1
40085 40085 1
40086 40088 3
40089 40090 2
40091 40092 2
40093 40094 2
40095 40096 2
40097 40098 2
40099 40102 4
40103 40104 2
40105 40106 2
40107 40108 2
40109 40110 2
40111 40112 2
40113 40114 2
40115 40115 1
40116 40122 7
40123 40123 1
40124 40142 19
40143 40144 2
40145 40145 1
40146 40154 9
40155 40155 1
40156 40156 1
40157 40157 1
40158 40158 1
40159 40159 1
Note 2 - Events response format
2 registers Date/Time
1 register Event category; 1=alarm; 2=fault; 3=warning; 5=informational
2 registers Event type
2 registers Argument 1
2 registers Argument 2
Register Parameter Description
Type
r Reserved
r Serial number
r Reserved
r Detector version
r Detector version
r Voltage monitor
r mA - A1 level
r mA - A2 level
r mA - A3 level
r mA - A4 level
r Reserved
r Reserved
r Reserved
r Reserved
r Alarm threshold
r Alarm threshold
r Reserved
r Timestamp of last bump test
r Proof test interval
r Reserved
r Relay congfiguration
r Reserved
r Timestamp
r Reserved
r Event block - read
w Event command
w Modbus responder address
w Baudrate
w Parity
w Stop bits
Searchline Excel™ Plus / Searchline Excel™ Edge – Technical Manual
Chapter 10 Communications
Additional Description
------
------
------
Hw
Sw
[10] = reserved, [11] = reserved, [12] =
+3V3_AFE
Alarm1/Pre-alarm
Alarm2/Alarm
Test signal 2
Overrange
------
------
------
------
Alarm1 set point
Alarm2 set point
------
------
------
------
Default state of relay1,
Default state of relay2,
Default state of relay3,
Relay1 latch on/off,
Relay2 latch on/off,
Relay3 latch on/off
------
Current RTC timestamp in UTC
------
Event data - one record in event history
Event command - request
------
1 - 9600, 2 - 19200, 0 - 76800 (this
baud rate is only to support fp2 s/w)
Note: Modbus will work only with
baudrates 9600 and 19200
0 - Even; 1 - Odd; 2 - None
0 = 1 Stop bit; 1 = 2 Stop bits
77
Notes
Note 16
Note 17
Note 6
Note 2
Note 10
