Summary of Contents for VersaLogic Falcon VL-EPU-2610
- Page 1 Reference Manual DOC. REV. 9/4/2013 Falcon (VL-EPU-2610) Intel Atom E6x0T-based Embedded Processing Unit with SATA, Ethernet, USB, Serial, Video, HD Audio, Mini PCIe Socket, and microSD...
- Page 2 Copyright © 2013 VersaLogic Corp. All rights reserved. Notice: Although every effort has been made to ensure this document is error-free, VersaLogic makes no representations or warranties with respect to this product and specifically disclaims any implied warranties of merchantability or fitness for any particular purpose.
-
Page 3: Versatech Knowledgebase
Product Revision Notes – Commercial release. Revision 1.00 Technical Support The Falcon support page, at http://www.versalogic.com/private/falconsupport.asp, contains additional information and resources for this product including: Reference Manual (PDF format) Datasheets and manufacturers’ links for chips used in this product ... -
Page 4: Table Of Contents
Contents VersaTech KnowledgeBase ....................iii Introduction ........................1 Description .......................... 1 Features and Construction ..................1 Technical Specifications ..................... 2 Block Diagram ........................3 RoHS Compliance ......................5 About RoHS ......................5 Warnings ..........................5 Electrostatic Discharge ..................5 Handling Care ......................6 Thermal Considerations ...................... - Page 5 Contents System RAM ........................22 Clearing Non-Volatile RAM (NVRAM) ................23 Default BIOS Settings ...................... 23 Default BIOS Setup Values ................. 23 Real-Time Clock (RTC) ....................23 Watchdog Timer ....................... 23 Console Redirection ......................24 Interfaces and Connectors ..................25 User I/O Connector ......................
-
Page 6: Introduction
One LVDS interface The Falcon is compatible with popular operating systems including Windows 7/XP/WES7/XPe, Linux, VxWorks, and QNX (see the VersaLogic OS Compatibility Chart). Falcon EPUs are subjected to 100% functional testing and are backed by a limited two-year warranty. Careful parts sourcing and US-based technical support ensure the highest possible quality, reliability, service, and product longevity for this exceptional EPU. -
Page 7: Technical Specifications
Introduction Technical Specifications Specifications are typical at +25°C with +12V supply unless otherwise noted. Board Size: SATA Interface: Heat plate models: 55 x 84 x 22 mm (2.17 x 3.31 x One SATA II port, 3 Gb/s 0.87”) Flash Storage: Heatsink models: 55 x 84 x 38.5 mm (2.17 x 3.31 x Two microSD sockets, each up to 32 GB 1.51”) -
Page 8: Block Diagram
Introduction Block Diagram SPI Boot Flash Intel 16 Mbit Atom Processor Up to 2 GB Max SPI I / F DDR2-800 LVDS DDR2 LVDS DDR2 8 Components 800 MT/s Memory Down Display Port (SDVO) DDI (SDVO) HD Audio (ITP) SMBus SMBus PCIe 1.0 x1 (3) PCIe 1.0 x1 (4) - Page 9 Introduction VL-CBR-5013/5014 RS-232/422/485 Transceivers Screw Terminals Conn. COM2/3 +8-17V Main +3.0V Battery Dual USB 2.0 USB 2.0 (4) USB Magnetics +8-17V Input Dual USB 2.0 480 Mbps Power RS-232/422/485 Transceivers Dual DB-9 2-wire COM Power Supplies COM1/2 Intel HDA Analog Audio Intel HD Audio Audio Line In/Out Line In/Out...
-
Page 10: Rohs Compliance
(PBDE) flame retardants, in certain electrical and electronic products sold in the European Union (EU) beginning July 1, 2006. VersaLogic Corp. is committed to supporting customers with high-quality products and services meeting the European Union’s RoHS directive. -
Page 11: Handling Care
BIOS and PLD code updates. Falcon (VL-EPU-2610) Support Page The VersaTech KnowledgeBase contains a wealth of technical information about VersaLogic products, along with product advisories. Click the link below to see all KnowledgeBase articles related to the Falcon. -
Page 12: Versatech Knowledgebase
Introduction VersaTech KnowledgeBase If you have further questions, contact VersaLogic Technical Support at (503) 747-2261. VersaLogic support engineers are also available via e-mail at Support@VersaLogic.com. EPAIR ERVICE If your product requires service, you must obtain a Returned Material Authorization (RMA) number by calling (503) 747-2261. -
Page 13: Configuration And Setup
Before you begin, unpack the Falcon and accessories. Verify that you received all the items you ordered. Inspect the system visually for any damage that may have occurred in shipping. Contact Support@VersaLogic.com immediately if any items are damaged or missing. - Page 14 Configuration and Setup USB Keyboard and USB Mouse VL-CBR-5014B or VL-CBR-5013B VL-CBR-5014A or VL-CBR-5013A USB CD- Power Supply ROM Drive VL-CBR- 0807 OS Installation CD-ROM VL-CBR-0401 FALCON SATA Hard Drive VL-CBR- Baseboard 0701/0702 CPU Module LVDS VL-CBR-2015 or VL-CBR-2016 Figure 3. Typical Development Configuration 1.
-
Page 15: Operating System Installation
The standard PC architecture used on the Falcon makes the installation and use of most of the standard x86-based operating systems very simple. The operating systems listed on the VersaLogic OS Compatibility Chart use the standard installation procedures provided by the maker of the OS. -
Page 16: Physical Details
Physical Details Dimensions and Mounting ALCON IMENSIONS The Falcon complies with the COM Express mini form factor standard. Dimensions are given below to help with pre-production planning and layout. Figure 4. Falcon Dimensions and Mounting Holes (Not to scale. All dimensions in millimeters.) VL-EPU-2610 Reference Manual... -
Page 17: Vl-Cbr-5013/5014 Paddleboard Dimensions
Physical Details VL-CBR-5013/5014 P ADDLEBOARD IMENSIONS 5.50 5.10 1.57 1.17 1.95 1.24 0.065 Figure 5. VL-CBR-5013/5014 Dimensions (Not to scale. All dimensions in inches.) VL-EPU-2610 Reference Manual... -
Page 18: Vl-Hdw-405 Mounting Plate Dimensions
Physical Details VL-HDW-405 M OUNTING LATE IMENSIONS 84.00 80.00 74.00 4 mm non-threaded 69.00 countersunk, x4 2.5 mm non-threaded countersunk (back), Falcon Outline 15.00 10.00 4.00 0.00 Figure 6. Mounting Plate Dimensions (Not to scale. All dimensions in millimeters.) VL-EPU-2610 Reference Manual... -
Page 19: Hardware Assembly
Physical Details ARDWARE SSEMBLY There are two basic assembly methods: heat plate down (in relation to the enclosure) or heatsink up. An optional mounting plate, VL-HDW-405, can be used with either method. These assembly methods are shown below. (See Appendix A – Mounting Options for mounting configuration details.) Heat Plate Down Use this assembly method if your Falcon is equipped with a heat plate only (no heatsink). - Page 20 Physical Details FALCON CPU Module Heatsink Baseboard Heat Plate Mounting Plate Figure 8. Hardware Assembly with Heatsink Up The recommended method is to attach the baseboard to the mounting plate (VL-HDW-405) and attach the mounting plate to the enclosure. VL-EPU-2610 Reference Manual...
-
Page 21: External Connectors
Physical Details External Connectors – CPU M ALCON ONNECTOR OCATIONS ODULE microSD CPU board pin-1 X/Y coordinates measured from MTH3 Figure 9. Connector Locations (CPU Module) VL-EPU-2610 Reference Manual... -
Page 22: Falcon Connector Locations - Baseboard
Physical Details – B ALCON ONNECTOR OCATIONS ASEBOARD Baseboard pin-1 X/Y coordinates measured from MTH1 Input Power LVDS J12 Pin 1 Mini PCIe / Non-latching mSATA Socket J12 or J8 User I/O microSD User GPIO J8 Pin 1 Latching SATA Ethernet Figure 10. -
Page 23: Falcon Connector Functions And Interface Cables
Physical Details ALCON ONNECTOR UNCTIONS AND NTERFACE ABLES Table 1 provides information about the function, mating connectors, and transition cables for Falcon connectors. Page numbers indicate where a detailed pinout or further information is available. (BB = baseboard, CPU = CPU board.) Table 1: Connector Functions and Interface Cables Pin 1 Location Mating... -
Page 24: Vl-Cbr-5013/5014 Connector Locations
Physical Details VL-CBR-5013/5014 C ONNECTOR OCATIONS Speaker Paddleboard Adapter Ext. Pushbutton COM3 Controls COM1 (Top) USB3 (Top) USB1 (Top) Audio Power Reset COM4 COM2 (Bottom) USB4 USB2 In (Top) (Bottom) (Bottom) Out (Bottom) mSATA activity (Top) Power LED COM1 (Bottom) COM2 Figure 11. -
Page 25: Jumper Blocks
Physical Details Jumper Blocks UMPERS HIPPED ONFIGURATION RS-485 Termination Serial Port Mode W_Disable# VL-EPU-2610 Reference Manual... -
Page 26: Jumper Summary
Physical Details UMPER UMMARY Table 3: Falcon Jumper Summary Jumper Description Block Shipped V1[1-2] Wireless Disable In – Wireless radio operation disabled on Mini PCIe card Out – Wireless radio operation enabled V2[1-2] COM1 Mode In – RS-232 Out – RS-422/485 V2[3-4] COM2 Mode In –... -
Page 27: System Features
RS-232 lines at high speed can increase power demand. The VersaLogic VL-PS-ATX12-300A is a 1U size ATX power supply designed for use with the Falcon. Use the VL-CBR-0807 adapter cable to attach the power supply to the J1 connector. -
Page 28: Clearing Non-Volatile Ram (Nvram)
System Features Clearing Non-Volatile RAM (NVRAM) Jumper block V2[9-10] and connector J3[2-4] are used to clear NVRAM. When clearing the NVRAM: 1. Power off the Falcon. 2. Place jumpers on V2[9-10] and connector J3[2-4]. 3. Power on the Falcon, and remove power after the Boot menu appears. 4. -
Page 29: Console Redirection
System Features Console Redirection The Falcon can be configured for remote access by redirecting the console to a serial communications port. BIOS Setup and some operating systems such as DOS can use this console for user interaction. Console redirection settings are configured in the BIOS Setup. Console redirection is enabled by default. -
Page 30: Interfaces And Connectors
Interfaces and Connectors User I/O Connector The 50-pin user I/O connector (J12 or J8) incorporates the COM ports, four USB ports, programmable LED, power LED, push-button reset, power button, audio line in/out, and speaker interfaces. The table below illustrates the function of each pin. The pinout for this interface is different for non-latching and latching connectors. -
Page 31: Ethernet Interface
Interfaces and Connectors Ethernet Interface The Falcon features an on-board Micrel KSZ9021/31RNI PHY and EG20T embedded Ethernet controller. The controller provides a standard IEEE 802.3 Ethernet interface for 1000Base-T, 100Base-TX, and 10Base-T applications. An RJ-45 connector is located at location J6. Drivers are readily available to support a variety of operating systems. -
Page 32: Sata Interface
An Intel Wi-Fi Link 5300 Mini PCIe card (VL-WD10-CBN) is available from VersaLogic. A Wi-Fi antenna (VL-CBR-ANT01) and a 12" Wi-Fi card to bulkhead RP-SMA transition cable (VL-CBR-0201) are also available. For more information, contact Sales@VersaLogic.com. - Page 33 Interfaces and Connectors Table 9: Mini PCIe / mSATA Pinout Mini PCIe Signal Mini PCIe mSATA mSATA Name Function Signal Name Function WAKE# Wake Reserved Not connected 3.3VAUX 3.3V auxiliary source +3.3V 3.3V source Not connected Reserved Not connected Ground Ground Not connected Reserved...
-
Page 34: W_Disable# Signal
Some Mini PCIe cards use this signal as a second Mini PCIe card wireless disable input. On the Falcon, this signal is available for use for mSATA versus Mini PCIe card detection. There is an option on the VersaLogic Features BIOS setup screen for setting the mSATA detection method. ISABLE IGNAL The W_DISABLE# is for use with optional wireless Ethernet Mini PCIe cards. -
Page 35: Microsd Sockets
Interfaces and Connectors microSD Sockets The Falcon provides two microSD sockets, one on the CPU board (J2) and one on the baseboard (J10). The VL-F41 series of microSD cards provide solid-state storage of 2 GB, 4 GB, or 8 GB. The microSD sockets will accommodate cards with up to 32 GB of storage capacity. -
Page 36: Serial Port Connectors
Interfaces and Connectors ERIAL ONNECTORS The pinouts of the DB9M connectors apply to the serial connectors on the VersaLogic breakout board VL-CBR-5013/5014. These connectors use IEC 61000-4-2-rated TVS components to help protect against ESD damage. Table 10: COM1 Pinout – VL-CBR-5013/5014 Connector J2... -
Page 37: Video
The Falcon has one LVDS connector at location J4. BIOS setup provides several options for standard LVDS flat panel types. If these options do not match the requirements of the panel you are using, contact Support@VersaLogic.com for a custom video BIOS. -
Page 38: Vga Output
Interfaces and Connectors Table 13: LVDS Flat Panel Display Pinout Signal Name Function Ground Not Connected LVDSA3 Diff. Data 3 (+) LVDSA3# Diff. Data 3 (-) Ground LVDSCLK0 Differential Clock (+) LVDSCLK0# Differential Clock (-) Ground LVDSA2 Diff. Data 2 (+) LVDSA2# Diff. - Page 39 Interfaces and Connectors = Pin 1 LVDS Figure 12. VL-CBR-2014 LVDS to VGA Adapter Card VL-EPU-2610 Reference Manual...
-
Page 40: Audio
Interfaces and Connectors Audio The audio interface on the Falcon is implemented using an Integrated Device Technology, Inc. 92HD87B1X5 audio codec. This interface is Intel High Definition Audio (HDA) compatible. Drivers are available for most Windows-based and Linux operating systems. To obtain the most current versions, consult the Falcon Product Support Page. -
Page 41: Power Button
Interfaces and Connectors Power Button Connector J8 includes an input for a power button. A momentary short to ground or assertion of J8 pin 41 will cause a power button ACPI event. The button event can be configured in Windows to enter an S3 power state (Sleep, Standby, or Suspend-to-RAM), an S4 power state (Hibernate or Suspend-to-Disk), or an S5 power state (Shutdown or Soft-Off). -
Page 42: Leds
Interfaces and Connectors LEDs SATA A CTIVITY Connector J8 includes an output signal for an mSATA activity LED, which corresponds to the top LED at position D1 on the VL-CBR-5013/5014 breakout board. OWER The power LED on the VL-CBR-5013/5014 indicates that the paddle board is being powered by the 5V supply (though it does not indicate that all S0 power supplies are good). -
Page 43: Appendix A - Mounting Options
Appendix A – Mounting Options Falcon Mounting Configurations The following illustrations show the mounting options for the Falcon. Figure 13. Bolt-through Heat Plate VL-EPU-2610 Reference Manual... - Page 44 Special Registers Figure 14. Bolt-through Heatsink VL-EPU-2610 Reference Manual...
-
Page 45: Mounting Plate Configurations
Special Registers Mounting Plate Configurations The following illustrations show options for installing the Falcon with the VL-HDW-405 mounting plate. Figure 15. Mounting Plate Option 1 VL-EPU-2610 Reference Manual... - Page 46 Special Registers Figure 16. Mounting Plate Option 2 VL-EPU-2610 Reference Manual...
