Ross Video Limited

Installation Guide

Volume I

Software Issue: 18

Table of Contents

Advertisement

Table of Contents

Need help?

Need help?

Do you have a question about the Synergy 2 SD and is the answer not in the manual?

Questions and answers

Summary of Contents for Ross Synergy 2 SD

Page 1 Ross Video Limited Installation Guide Volume I Software Issue: 18...
Page 2 The material in this manual is furnished for informational use only. It is subject to change without notice and should not be construed as commitment by Ross Video Limited. Ross Video Limited assumes no responsibility or liability for errors or inaccuracies that may appear in this manual.
Page 3 Important Regulatory and Safety Notices to Service Personnel Before using this product and any associated equipment, refer to the “Important Safety Instructions” listed below to avoid personnel injury and to prevent product damage. Product may require specific equipment, and/or installation procedures to be carried out to satisfy certain regulatory compliance requirements.
Page 4 8) Do not install near heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat. 9) Do not defeat the safety purpose of the polarized or grounding-type plug. A polarized plug has two blades with one wider than the other. A grounding type plug has two blades and a third grounding prong.
Page 5 Notice Changes or modifications to this equipment not expressly approved by Ross Video Limited could void the user’s authority to operate this equipment. CANADA This Class “A” digital apparatus complies with Canadian ICES-003.
Page 6 EUROPE This equipment is in compliance with the essential requirements and other relevant provisions of CE Directive 93/68/EEC. INTERNATIONAL This equipment has been tested to CISPR 22:1997 along with amendments A1:2000 and A2:2002, and found to comply with the limits for a Class A Digital device. Notice This is a Class A product.
Page 7 Software upgrades for switchers may occur from time to time, and are determined by Ross Video. The upgrades are posted on the Ross Video website, and are free of charge for the life of the switcher. This warranty is void if products are subjected to misuse, neglect, accident, improper installation or application, or unauthorized modification.
Page 8 The crossed-out wheeled bin symbol invites you to use these systems. If you need more information on the collection, reuse, and recycling systems, please contact your local or regional waste administration. You can also contact Ross Video for more information on the environmental performances of our products.
Page 9 Company Address Ross Video Limited Ross Video Incorporated 8 John Street P.O. Box 880 Iroquois, Ontario, K0E 1K0 Ogdensburg, New York Canada USA 13669-0880 (+1) 613 • 652 • 4886 General Business Office: (+1) 613 • 652 • 4425 Fax: (+1) 613 •...
Page 11: Table Of Contents
Contents Volume I Introduction A Word of Thanks ........................1-1 About This Guide .........................1-2 Volume I ........................1-2 Volume II .......................1-3 Documentation Conventions ....................1-5 Documentation Terms ......................1-6 Abbreviations ........................1-7 Product Overview ........................1-8 Product Highlights ....................1-8 Standard Features ....................1-9 System Options ....................1-15 A Word about Technical Support ..................1-26 Installation In This Chapter ........................2-1 Static Discharge ........................2-2...
Page 12 System Backup ....................2-33 Software Upgrade ....................2-34 Restoring Disk Registers ..................2-36 Installed Options Menus ....................2-37 Software Options Menu ..................2-37 Panel Boards Menu ..................... 2-38 Frame Boards Menu ................... 2-39 Option Boards Menu ................... 2-39 Installing Serial Numbers ................... 2-40 Installing Software Options ................
Page 13 Help Features ........................5-7 Help Menu ......................5-7 Screen Capture ........................5-9 BNC Configuration and Check In This Chapter ........................6-1 Installation Enable Jumper Setting ..................6-2 BNC Configuration Menu Tree ...................6-3 BNC Configuration ......................6-4 Naming BNC Inputs ....................6-4 Restoring Default BNC Names ................6-6 Setting Up Mnemonics Displays for BNC Names ..........6-7 Setting Up BNC Types ..................6-9 Setting Up Tallies ....................6-11 Setting Up Alphas ....................6-13...
Page 14 Programming Special Functions ..................8-19 Time Clock Functions ..................8-19 Special Functions ....................8-21 Peripheral Interface II Custom Controls ............. 8-37 Copy MLE Custom Controls .................... 8-39 Notes on Using the Copy MLE Function ............8-40 Naming Custom Controls ....................8-42 Customizing Mnemonic Displays —...
Page 15 System Timing ........................9-56 Auto-timing Technical Overview ................9-56 Non-Sync LEDs ....................9-57 Key Timing ......................9-58 Reference Delay Adjustment ................9-58 Peripheral Control Setup ....................9-59 Tally Connections ......................9-60 Aspect Ratio ........................9-61 Completing Setup In This Chapter ........................10-1 Disk Menu Tree .........................10-2 About the Synergy File Storage System ................10-3 Using the Disk Menu ...................10-4 Notes on Using a USB Key .................10-5 Storage Errors ......................10-5...
Page 16 Editor and OverDrive Operation ..................12-18 OverDrive Operation Notes ................12-18 Using OverDrive with a Synergy 2 Switcher ........... 12-18 External DVEs In This Chapter ........................13-1 Supported External DVEs ....................13-2 Primary and Secondary DVEs ..................13-3 Setup Steps ......................13-3 Connection Diagrams ..................
Page 17 Volume II Routers Character Generators VTRs (Betacam) Audio Servers Video Servers (VDCP) Robotic Cameras Monitor Walls Audio Mixers Appendix A. Specifications Appendix B. Diagnostics Appendix C. Hardware Options Appendix D. Frame Modification Appendix E. Switcher Installation Worksheets Appendix F. Custom Device Serial Protocols Glossary of Terms Index Synergy Series Installation Guide (v18)
Page 18 viii • Contents Synergy Series Installation Guide (v18)
Page 19: Introduction
Introduction A Word of Thanks Congratulations on choosing the Ross Synergy SD Series digital video production switchers. You have purchased the power and versatility of a digital Multi-Level Effects (MLE) switcher that is ready to take on all creative challenges in today’s competitive broadcast environment. You will be pleased at how easily your Synergy switcher fits into your overall working environment.
Page 20: About This Guide
About This Guide This guide covers the installation of the following Synergy switchers: • Synergy 2 SD (2 MLE) • Synergy 3 SD (3 MLE) • Synergy 4 SD (4 MLE) The guide takes you through physical installation, system configuration, and the steps required to integrate your switcher with peripheral equipment.
Page 21: Volume Ii
• Chapter 13 — “External DVEs” provides instructions for connecting and setting up a Digital Video Effects system (DVE) with a Synergy switcher. • Glossary — The Glossary provides a reference list of important switching and video terms used throughout this guide. •...
Page 22 Index — An Index is also provided for your reference. If, at any time, you have a question pertaining to the installation of your Ross Synergy switcher, please contact us at the numbers listed in the front of this guide. Our technical staff are always available for consultation, training, or service.
Page 23: Documentation Conventions
Documentation Conventions The following conventions are used throughout this guide: • Rear panel connectors are indicated in bold-faced upper case letters. For example: The AUX 1 connector is ... • Control Panel buttons are indicated in bold-faced upper case letters, using a sans-serif font.
Page 24: Documentation Terms
Documentation Terms The following terms are used throughout this guide: • A “1+0 DVE” has a video connection only going from Synergy to the DVE. Both key and fill signals are connected from the DVE to Synergy. • A “1+1 DVE” has both a video (fill) and a key (alpha) connection going from Synergy to the DVE.
Page 25: Abbreviations
Abbreviations The following abbreviations are used throughout the text: Abbreviation Definition Analog-to-Digital Background Bus BKGD Auxiliary Character Generator Digital-to-Analog Distribution Amplifier Digital Disk Recorder Downstream Keyer Digital Video Effects Digital Video Recorder Identification Multi-level Effects Program Bus Preset Bus PST PATT Preset Pattern Preview Rack Unit...
Page 26: Product Overview
Product Overview Ross Video developed the Synergy SD series for live news, live sports, and live production. Because the switcher is the center of the action, it must be powerful, versatile, yet easy to operate. This operational simplicity frees operators to concentrate on the programming — instead of the equipment.
Page 27: Standard Features
Keyers or worrying about Aux Buses, signal paths, or tallies. • Upgrades from the Web. Software (and some hardware) can be upgraded by downloading files from the Ross Video web site onto a storage device such as a floppy disk or USB key. •...
Page 28 Inputs can be used for video, alpha channel, chroma keying, or switcher reference. Regarding reference, note that any serial digital input can be assigned as the reference. If an analog reference is desired, Ross Video will optionally provide external conversion from (or to) the analog domain.
Page 29 4:4:4 chroma channel interpolation from any of the 4:2:2 inputs. • The Synergy 2 SD (with one MLE plus Program/Preset) is capable of putting up to four different chroma keys on air simultaneously. •...
Page 30 Standard Digital Outputs In addition to the standard 12 untimed Aux Bus outputs, a wide array of program and preview outputs are also provided as standard: Synergy SD Series Digital Outputs Quantity Output Type Synergy 2 Synergy 3 Synergy 4 Main PGM Preview Matrix (no overlay) MLE 1 PGM (BKGD)
Page 31 BKGD CLEAN FEED Basic Clean Feed Modes At point 1 above, the clean feed output is pulled after the MLE’s program/preset bus, but before the two keys are added. At point 2 above, the clean feed output is pulled downstream of the two MLE Keyers — effectively, an additional output.
Page 32 Memory System Each switcher is equipped with a standard 100-event memory for complete switcher snapshots. At the touch of a button, the entire switcher (or simply a portion of the switcher) can be recalled directly from an MLE keypad. You can also associate “attributes” with memory recalls. These could be dynamic “effects dissolves,” auto transitions, or external device commands.
Page 33: System Options
All switcher inputs and outputs are 10-bit SDI, including the system reference. Signal sources of other video formats must be converted to serial digital. Ross Video chose to do this conversion externally to ensure that the very latest conversion technology and most competitive pricing is available to our customers.
Page 34 UMA-8017 Universal SDI Monitoring Amplifier Please visit our website at http://www.rossvideo.com or contact your Ross Video representative to obtain a current Ross Video Product Catalog for detailed information on our complete line of converters. Serial Digital Inputs Additional serial digital inputs are available in sets of eight — up to a maximum of 64 serial digital inputs.
Page 35 remote port must be connected to the switcher and the VTR Remote Control Option must be installed. • The “Safe Title and Safe Area” overlay places a SMPTE standard safe title or safe area indication over the switcher’s main preview output. Safe title is a box that outlines the area within which the vast majority of home TV sets will be able to read text.
Page 36 WARP DVE into an MLE Keyer. The option is available for all MLEs including the DSK. Once installed, the option can also be moved to another MLE if desired. • The Synergy 2 SD can be equipped with up to two Squeeze & Tease options — effectively, combining the power of up to four DVEs. •...
Page 37 In addition to its DVE functionality, either full screen video or key signals can be frozen at the touch of a button — thus putting the power of a frame store into every keyer. If full screen video is frozen, it can be used as a background to the other MLE Keyer.
Page 38 (only) include buttons to access the 12 Aux Bus outputs. The primary difference between the panels is in the number of source and MLE buttons: • Synergy 2 SD — each panel includes 17 source buttons plus SHIFT, and a button for MLE 1. •...
Page 39 • The communications signal is re-buffered at each Aux panel. • Aux panel assignments are performed using the control panel and menu system. Refer to the section “Aux Bus Setup” on page 11–3 for instructions. Note New versions of the Dedicated and Assignable Remote Aux Panels now provide 8 GPI input ports per panel.
Page 40 • VTR Remote Control can be tied into the Custom Control buttons. Any Custom Control button can be attached to functions such as play, stop, rewind, fast forward, frame advance, auto edit and standby off. Still Store Interface This option enables control over still store devices. It allows a user to randomly access any still or clip under control from the Synergy SD switcher.
Page 41 With the option installed, the following functions are available: • Using the VTR Clips menu, you can set up a list of server clips that you want to use on air, name them, preview them, trim each clip’s head and tail and enable (or disable) each clip for use.
Page 42 The DVE SEND button in each MLE’s Transition Group assigns the external DVE (the “primary” DVE) to that particular MLE — and also selects DVE Send as the transition type (as opposed to wipe or dissolve). You can then select the next transition (using the BKGD, KEY 1 and KEY 2 buttons) and press the AUTO TRANS button.
Page 43 • supply 2 failure • cooling fan failure Note that the option includes two redundant power supplies — one for the frame and one for the control panel. Adding redundant power does not increase the amount of rack space required, as the main supply mounts inside the frame, and the control panel supply mounts inside the control panel tub.
Page 44: A Word About Technical Support
A Word about Technical Support At Ross Video, we take pride in the quality of our products, but if problems occur, help is as close as the nearest telephone. Our 24 Hour Hot Line service ensures you have access to technical expertise around the clock.
Page 45: Installation
Installation In This Chapter This chapter provides instructions for installing Synergy 2, 3 and 4 SD switcher hardware. The following topics are discussed: • Static Discharge • Getting Started • Unpacking • Synergy Control Panel Overview • Synergy Frame Overview •...
Page 46: Static Discharge
Static Discharge Throughout this chapter, please heed the following cautionary note: Caution Static discharge can cause serious damage to sensitive semiconductor devices. Avoid handling the switcher circuit boards in high static environments such as carpeted areas and when synthetic fiber clothing is worn.
Page 47: Getting Started
Limited immediately. A Word about Serial Numbers Serial numbers have now been implemented to allow Ross Video to properly track which options have been purchased by each customer. Switchers shipped in August 1999 and later have serial numbers installed (in flash memory) at the factory. Switchers shipped before August 1999 do not have serial numbers installed.
Page 48: Synergy Control Panel Overview
Synergy Control Panel Overview This section provides a hardware overview of the Synergy SD Series Control Panels. The following sections are included: • Synergy Control Panel — Top View • Synergy Control Panel — Rear Connector Panel • Synergy Control Panel — Power Connectors Synergy Control Panel —...
Page 49 Synergy 3 Control Panel The Synergy 3 Control Panel comes standard with three MLEs, and 24 inputs. Synergy 3 Control Panel with USB Removable Media Drive Option Synergy 2 Control Panel The Synergy 2 control panel comes standard with two MLEs and 16 inputs. Synergy 2 Control Panel with USB Removable Media Drive Option Synergy Series Installation Guide (v18) Installation •...
Page 50: Synergy Control Panel - Rear Connector Panel
Important The cable connecting the Synergy Control Panel to the Synergy Frame is not wired as a standard CAT5 ethernet cable. If you need a cable of a specific length, contact your Ross Video Representative for ordering information. • AUX 1, 2 — Two 6-pin shielded Telco connectors are provided for communications between the control panel and remote Aux panels.
Page 51: Synergy Control Panel - Power Connectors
Synergy Control Panel — Power Connectors The following figure illustrates the dual power connectors on the rear of each control panel. Although the layout and labeling is identical, the placement of these two connectors will differ, depending upon the size of your specific Synergy switcher. PRIMARY REDUNDANT POWER...
Page 52: Synergy Frame Overview
Synergy Frame Overview This section provides a hardware overview of the Synergy SD Series Frame. The following sections are included: • Synergy Frame — Front View • Synergy Frame — Rear Connector Panel View Synergy Frame — Front View The following figure illustrates the front of the frame, with the door removed. T10A 250V (PRIMARY)
Page 53 Board layout is identical for all Synergy switchers. 1. Power Controls and Indicators A panel is provided for power supply controls and LED indicators. Note that a cutout in the front door allows these controls to be accessed with the door closed. The PRIMARY POWER switch turns on the primary power supply.
Page 54 • Note that an air filter is mounted on the back of the tray, behind the fans. This filter should be cleaned periodically. Warning When the power supply tray is inserted into the frame, it mates with male power pins that carry live voltage if the frame is plugged in. All power must be disconnected before servicing Caution Do not insert your fingers into the power supply slot when the unit is...
Page 55: Synergy Frame - Rear Connector Panel View
Extender Board in this slot. Synergy Frame — Rear Connector Panel View The following figure illustrates the rear connector panel of the electronics chassis. INPUTS SERIES DIGITAL PRODUCTION SWITCHER ROSS VIDEO LTD. MODEL ISSUE SERIAL# CAUTION: DISCONNECT POWER...
Page 56 Active, MLE 3 Active Synergy 4 Active Active Active Active Active, MLE 4 Active If DAs are required to provide additional outputs for a particular signal, contact Ross Video or your Ross dealer for details. 2–12 • Installation Synergy Series Installation Guide (v18)
Page 57 4. Aux Output Section Ten BNC connectors are provided for the switcher’s first ten standard auxiliary bus outputs. Outputs 11 and 12 are located in the Special Output Section. Each auxiliary output is identified in the label array to the left of the connectors. Aux outputs can be timed or untimed, depending upon the number of Timed Aux Bus options installed.
Page 58 7. DVE 2 Connector One 9-pin, D-Type, RS-422 connector labeled DVE 2 is provided for serial control purposes. Please note: • The port is primarily designed to connect to the second channel of a DVE that requires one serial port per channel. •...
Page 59 The cable connecting the Synergy Control Panel to the Synergy Frame is not wired as a standard CAT5 ethernet cable. If you need a cable of a specific length, contact your Ross Video Representative for ordering information. Synergy Series Installation Guide (v18)
Page 60: Installation At A Glance
Installation at a Glance The following section presents a brief overview of the installation process. The exact steps taken in installing your switcher will depend on the specific options that you have purchased. Caution All cautionary rules regarding static discharge apply. Refer to the section “Static Discharge”...
Page 61: Hardware Installation
4.0" (10.1 cm) 21.25" Cutout - Synergy 2 (54.0 cm) Distance from Cutout to Console Front (Recommended) 2.0" (5.0 cm) 35.5" (90.2 cm) Console Front Synergy 2 SD Control Panel Cutout Dimensions Synergy Series Installation Guide (v18) Installation • 2–17...
Page 62 Console Top Cable Clearance 4.0" (10.1 cm) 23.0" Cutout - Synergy 3 (58.4 cm) Distance from Cutout to Console Front (Recommended) 2.0" (5.0 cm) 50.25" (127.6 cm) Console Front Synergy 3 SD Control Panel Cutout Dimensions Console Top Cable Clearance 4.0"...
Page 63 In addition to the cut-out measurement, ensure that there is sufficient clearance under the desktop for connectors and cables on the rear of the control panel. Approximately four inches (10.1 cm) of clearance should be sufficient for each switcher, as shown in the following diagram.
Page 64 The control panel’s power supply is not intended to be field serviced — it is serviced by replacement only. In case of power supply failures, please contact your dealer or Ross Video. The power supply cover should only be removed by qualified service personnel.
Page 65: Installing Remote Aux Panels
Installing Remote Aux Panels Remote Aux panels are self-contained units that have their own power supply. Each panel controls the switcher’s Aux Buses via a single control cable. Even though an unlimited number of Aux panels can be connected to each of the AUX PANEL connectors, a practical limit of 16 Aux panels should be observed.
Page 66 4. Echo Port One 6-pin RJ-12 Telco connector is provided for daisy-chaining the remote panel to the next remote Aux panel in line. Refer to the section “Remote Aux Panel Cabling” on page 3–3 for connection details. For pinout information, refer to the section “Pinouts” in Appendix A, “Specifications”.
Page 67: Installing The Electronics Frame
Installing the Electronics Frame The electronics frame is designed to be rack mounted. Note the following installation requirements: • Rack Units: 11 RU • Height: 19.5 inches (49.5 cm) • Depth: 19.25 inches (48.9 cm) • Rack: standard 19 inch wide equipment rack Install the frame for maximum stability during operation, and in such a way as to allow adequate ventilation.
Page 68: Installing The Frame Power Supply
The power supply should only be installed by qualified service personnel. In case of a power supply failure, contact your dealer or Ross Video. Carefully unpack the power supply from its box, and retain all packing material for future use, if required.
Page 69 Use the following procedure to install frame power: Caution In some countries, it may be necessary to supply the correct mains supply cord. Use only an approved IEC 320 C-13 type A/C line cord rated for a minimum 10A at 250V and certified for the country of use. For frame redundancy, it is recommended that two independent AC sources be used to feed the power supplies.
Page 70: Jumpers And Switches
Jumpers and Switches This section provides important information about system jumpers and switches. Three sections are included: • Jumper Positions • Control Panel Jumpers and Switches • Frame Jumpers and Switches Caution All product servicing should be carried out by qualified service personnel.
Page 71: Control Panel Jumpers And Switches
Control Panel Jumpers and Switches For all switchers, the following figure illustrates the location of jumpers and switches on the front edge of the Control Panel CPU Board: Control Panel CPU Board Rear Connector Panel JP5 JP6 JP7 JP8 JP9 JP10 JP11 JP12 Control Panel Front RESET Control Panel Jumpers and Switches...
Page 72: Frame Jumpers And Switches
6. JP7, Reserved Jumper JP7 is reserved for future use. Please leave it in the default Down position. 7. JP8, Reserved Jumper JP8 is reserved for future use. Please leave it in the default Down position. 8. JP9, Reserved Jumper JP9 is reserved for future use. Please leave it in the default Down position. 9.
Page 73 2. DIP Switch 2, Power Supply This 8-position DIP switch identifies the power supply(s) in the frame. If a single power supply is used, set SW1 (leftmost) to the Up position. If a redundant (second) power supply is used as well, set SW1 to the Down position. 3.
Page 74: System Reset Notes
Installation Change Confirmation Menu 11. JP11, Software Upgrade Jumper JP11 controls the ability to upgrade software from a storage device: • Up: Software can be upgraded from a storage device. Refer to the section “Software Upgrade” on page 2–34 for instructions. Down: Software cannot be upgraded from a storage device.
Page 75: Power Fail Indicators
Power Fail Indicators Note that two important POWER FAIL indicator LEDs on the Control Panel mirror the condition of the four chassis “Power” LEDs and the panel’s power supply: PANEL: when lit, indicates that there is a fault with the control panel’s primary or •...
Page 76: Software Upgrade
This section provides step-by-step instructions for upgrading the Synergy switcher software from a storage device. You can obtain a copy of the software, or of any previous version, by logging on to the Ross Video website: (http://www.rossvideo.com) Use the following steps to perform a software upgrade from a storage device: •...
Page 77: System Backup
System Backup Important Because the software upgrade process automatically returns the switcher to default values, it is important that you back up all switcher elements to a storage device, such as a floppy disk or USB key, at this point. Use the following procedure to save your setup configurations to a storage device: Navigate to the Disk Menu as follows: •...
Page 78: Software Upgrade
Software Upgrade This section outlines how to initiate the software upgrade using either floppy disks or a USB key. Using Floppy Disks Use the following procedure to initiate the software upgrade from floppy disks: Ensure that you backup your switcher by saving your setups to a floppy disk. Refer to the section “System Backup”...
Page 79 Important After restoring power to the control panel, you may receive the error message, “USB Upgrade Failed”. Contact Ross Video Technical Support for more information on correcting the error. This completes the procedure for upgrading system software. Please continue with the “Restoring Disk Registers”...
Page 80: Restoring Disk Registers
If you receive this error message, you must verify the software versions of your Squeeze & Tease 3D cards and your Synergy control panel. Contact Ross Video Technical Support if you have questions on upgrading your Synergy switcher software version to match your Squeeze & Tease 3D cards.
Page 81: Installed Options Menus
• Storing and Recalling Option Codes Important Serial numbers allow Ross Video to properly track which options have been purchased by each customer. Switchers shipped in August 1999 and later have serial numbers installed (in flash memory) at the factory.
Page 82: Panel Boards Menu
The menu is provided for information only — no action can be taken. • If a serial number appears at the top of the menu, please verify that the list reflects the exact options that you have purchased. If not, please contact Ross Video Technical Support for further information. •...
Page 83: Frame Boards Menu
Frame Boards Menu The Main Area of the Frame Boards Menu provides three columns of information that pertain to the boards installed in the frame: • Column 1 (Board) lists each circuit board by part number and name. • Column 2 (Rev) lists the board’s hardware revision number. •...
Page 84: Installing Serial Numbers
Installed Options – Option Boards Menu Use the center knob to scroll the list. This completes the procedure to view the optional boards you have installed on your Synergy SD Switcher. Notes on Using the Option Boards Menu Please note: •...
Page 85: Installing Software Options
The next time the switcher is powered up, a new Encrypt Code is generated. Call Ross Video Technical Support at the number listed on the menu. When you speak to our Technical Support representative, tell them your name, your facility name, and the Encrypt Code as listed on the menu.
Page 86: Storing Option Codes
• The option(s) that you wish to install. Technical Support keeps an up-to-date record of each switcher’s configuration and option status. You will be given a numeric code for each option. Enter the code on the keypad in the switcher’s Global Memory Area. Operating Make a written note of your serial number and each option code, and store them in a safe place for future reference.
Page 87: Recalling Option Codes
Label the storage device and store it in a safe place. It is recommended that you place the following information on the label: • Synergy SD Switcher Model (2, 3, or 4) • Software Option Codes Backup • Today’s Date •...
Page 88 2–44 • Installation Synergy Series Installation Guide (v18)
Page 89: Preliminary Cabling And Check
Preliminary Cabling and Check In This Chapter This chapter outlines procedures for making basic control panel, frame, reference, and monitor connections. A preliminary functional check procedure is also provided. The following topics are discussed: • Cabling • Control Cable Installation •...
Page 90: Cabling
The following figure illustrates the connections that you will make in this chapter. Synergy Rack Frame INPUTS SERIES DIGITAL PRODUCTION SWITCHER ROSS VIDEO LTD. MODEL ISSUE SERIAL# Synergy Control Panel CAUTION: DISCONNECT POWER...
Page 91: Control Cable Installation
The cable connecting the Synergy Control Panel to the Synergy Frame is not wired as a standard CAT5 ethernet cable. If you need a cable of a specific length, contact your Ross Video Representative for ordering information. Use the following procedure to install the control cable between the Frame and the Control Panel:...
Page 92 If your system includes remote Aux Bus panels, one serial cable is shipped with each panel. There are two types of cable available: • Aux panel cables with standard 10 meter lengths. • Non-standard cables with lengths specified by the customer. For standard length cables, refer to the packing list provided with your switcher;...
Page 93 Remote Aux Panel Cabling — New Version Panels Once you have located the appropriate cables for each remote Aux panel (new version), make the connections according to the following figure: Synergy Control Panel REMOTE TALLY FRAME New Version Remote Aux Panel New Version Remote Aux Panel To connector J5 on the next Aux Panel...
Page 94: Reference Signal Connection
Serial Digital to NTSC Serial Digital to PAL Serial Digital to Analog Component For information on Ross Video’s full line of conversion equipment, contact your sales representative or Ross Video Limited. 3–6 • Preliminary Cabling and Check Synergy Series Installation Guide (v18)
Page 95: Animated Logo Generator (Cdk-111A-M) Cabling
Animated Logo Generator (CDK-111A-M) Cabling This section explains how to connect the Animated Logo Generator (ALG) to your Synergy 2, 3 or 4 SD Switcher. Use the following procedure to connect the ALG to your Synergy SD Series switcher: Using industry standard coaxial cable and BNC connectors, connect a digital reference signal from your facility’s house sync generator to the IN BNC of the CDK-111A-M.
Page 96 Rotary Switch ALG (CDK-111A-M) Card Edge Refer to the section, “Animated Logo Generator Mode”, in the CDK-111A-M Owner’s Guide, for complete instructions on installing, configuring, and operating your CDK-111A-M in ALG mode. 3–8 • Preliminary Cabling and Check Synergy Series Installation Guide (v18)
Page 97: Dsk 3/4 (Cdk-111A-M) Cabling
DSK 3/4 (CDK-111A-M) Cabling This section explains how to connect the DSK 3/4 (CDK-111A-M) to your Synergy 2, 3 or 4 SD Switcher. Refer to the section “DSK 3/4 (CDK-111A-M) Communications Setup” on page 7–19 for full installation and configuration procedures. Use the following procedure to connect your DSK 3/4s: CDK-111A-M CDK-111A-M...
Page 98 On the second DSK, BNC 5 and 6 are the PGM Out and PV Out, respectively. Important Before turning on the power, please ensure that the rotary switch on the front edge of the CDK-111A-M card indicated on the diagram below is turned to position 6.
Page 99: Power Up
• Turn the unit back on and recheck the ALL OK LED. If the LED is still not lit, contact Ross Video Technical Support. On the control panel, ensure that the PANEL LED under the POWER FAIL heading is not lit.
Page 100: Resetting The System
Resetting the System If required, the Synergy SD Switcher can be reset manually from either the control panel or the frame. There are two types of resets: • A Full Reset affects hardware and software simultaneously • A Software Reset affects software only Full Reset This function performs both a hardware and a software reset simultaneously: To reset the frame and all system software, press the red button labeled RESET on the...
Page 101 • To reset MLE 3 (on Synergy 3 and Synergy 4 systems), simultaneously press MLE 3 (in the RECALL column) and MLE 3 (in the STORE column). To reset MLE 4 (on Synergy 4 systems), simultaneously press MLE 4 (in the RECALL •...
Page 102: Preliminary Functional Check
• Fade to black All Ross Video products undergo thorough quality control and testing before shipment. The following preliminary check ensures that no damage has occurred during transit, and that all boards are correctly installed. Once the preliminary check is complete, the remaining installation procedures can be performed.
Page 103 The default display in the Global Memory System Group indicates the following information (for the DSK and the Program/Preset MLE): REG:00 — Memory register 00 is preset Memory0 — Memory register 00 was last recalled M:015 — MLE (4, 3, or 2) transition rate is 15 frames D:008 —...
Page 104: Basic Troubleshooting
If you have the USB Removable Media Drive option installed, you may receive the error message, “USB Upgrade Failed” after restoring power to the control panel. Contact Ross Video Technical Support for more information on correcting this error. For other switcher problems, please contact Ross Video Technical Support.
Page 105: Preliminary Video Installation
Preliminary Video Installation In This Chapter This chapter describes the connections required to provide video and key signals to all areas of the switcher. You will complete input and output worksheets, connect inputs and alpha signals, install all pushbutton inserts, and connect your switcher outputs. The following topics are discussed: •...
Page 106: Input Worksheet
If you elect to use analog color black as your reference (based on your facility’s requirements), you must use an external A-D converter. For information on Ross Video’s full line of conversion equipment, contact your sales representative or Ross Video Limited.
Page 107 For each input (moving from left to right in the worksheet columns): • Fill in the actual source name. For example: VTR 1. • Fill in the Remote port on the Synergy switcher for that input. For example: Remote 1. •...
Page 108 BNC Input Worksheet Actual Remote Device Input Input Tally Alpha Auto Audio Button Source Port Address Name Type Number Type Channel Sample VTR 1 Remote 1 VTR Blue — — — Sample CG Alpha Remote 2 CG Alpha Alpha — S, Off —...
Page 109 BNC Input Worksheet Actual Remote Device Input Input Tally Alpha Auto Audio Button Source Port Address Name Type Number Type Channel Synergy Series Installation Guide (v18) Preliminary Video Installation • 4–5...
Page 110: Connecting And Verifying Inputs
Connecting and Verifying Inputs This section covers the following topics: • Input Connection • Input Verification Input Connection Operating Use cabling techniques in accordance with good engineering practice. Using the data from the worksheet section “BNC Input Worksheet” on page 4–4, connect your reference input, primary inputs, and all alpha inputs to the appropriate connectors on the rear of the frame.
Page 111: Input Verification
Input Verification For verification of your inputs, ensure that a monitor is connected to the PGM – MAIN BNC output. Remember also (at this point in the installation) that default mapping is still in effect. Re-mapping (per your input worksheet) will be performed in the section “BNC Configuration” on page 6–4. During this procedure, you can map any input to any button on a bus row.
Page 112 To view inputs 33 through 64, press SHIFT + buttons 1 through 32, respectively. (Button 35 is mapped to SHIFT on the shifted row). Operating You can also double press the SHIFT button to have the MLE remain in the shifted mode. Double pressing the SHIFT button again releases the MLE from the shifted mode.
Page 113: Pushbutton Inserts
Ross Video would be pleased to consider adding it to the standard film. There are four typical ways of labeling a pushbutton: •...
Page 114: Aux Bus Panel Pushbutton Inserts
Remove the pushbutton from the switch by pulling straight upward on the lens cap. Remove the lens cap from the lens and place the desired input designation under the lens cap. Operating If you have trouble removing a control panel button, use a pair of wide-tipped pliers (1/2 inch) with masking tape wrapped around the ends.
Page 115 Use the following procedure to install an Aux Bus pushbutton insert: Cut out the designation film inserts for the Aux Bus pushbuttons. These can be the same inserts used for the control panel pushbuttons. Operating For best results when cutting out the button inserts, use a sharp X-ACTO ®...
Page 116: Output Connection
If you require more primary outputs than are provided on the rear of the frame, consideration should be given to using a digital distribution amplifier. Contact Ross Video or your Ross Video dealer for details. Complete the auxiliary output worksheet on page 4-12. Or, to avoid marking up this guide, use the worksheet provided in Appendix E, “Switcher Installation Worksheets”...
Page 117 Contact Ross Video or your Ross Video dealer for details. Complete the special output worksheet on page 4-14 . Or, to avoid marking up this guide, use the worksheet provided in Appendix E, “Switcher Installation Worksheets”...
Page 118 If you require more special outputs than are provided on the rear of the frame, consideration should be given to using a digital distribution amplifier. Contact Ross Video or your Ross Video dealer for details. 4–14 • Preliminary Video Installation...
Page 119: Connecting And Verifying Outputs
Connecting and Verifying Outputs This section covers the following topics: • Output Connection • Output Verification Output Connection Using the data from the three previous charts, connect the following outputs to the desired destinations. Use cabling and connecting techniques in accordance with good engineering practice. Primary Outputs Per your Primary Output Worksheet, connect the following primary outputs to the desired external destinations, such as program monitors, preview monitors, transmission, routing switchers, etc.
Page 120: Output Verification
Special Outputs Per your Special Output Worksheet, connect the following special outputs to the desired external destinations, such as monitors, preview monitors, VTRs, and routing switchers. • CLEAN (standard, provides the clean feed output which is software configurable) • PV (standard, provides main output of the preview matrix) •...
Page 121 Auxiliary Output Verification Output to Verify Verification Method AUX 1 In the AUX BUS ASSIGN group, press ASSIGN 1, then switch between inputs on AUX Bus. AUX 2 In the AUX BUS ASSIGN group, press ASSIGN 2, then switch between inputs on AUX Bus.
Page 122 4–18 • Preliminary Video Installation Synergy Series Installation Guide (v18)
Page 123: Using The Menu System
Using the Menu System In This Chapter This chapter introduces the menu system of the Synergy SD Switcher. The following topics are discussed: • About the System Control Display • Menu System Basics • Positioner Icons • Adjusting the Display •...
Page 124: About The System Control Display
About the System Control Display Each Synergy SD Switcher includes a System Control Group in its top panel. GLOBAL MEMORY SYSTEM SYSTEM CONTROL REMOTE INCLUDE HOME INCL EDITOR ATTRIB RECALL STORE CLIP FADE UNDO RATE KEYS MLE 3 LOCK ONLY RATE MENU BANK...
Page 125: Menu System Basics
Menu System Basics The following figure illustrates the System Control Group, which is identical on all Synergy switchers — in both appearance and function. At the center of the group is the System Control Display, a bright LCD screen that provides a variety of clear menus for various system setup and operational functions.
Page 126 3. Label Area Labels on the two bottom rows represent functions that you can activate, or buttons that route you to further sub-menus. These labels change depending upon the selected mode and menu. A menu function is activated by pressing its corresponding Soft Key. Note In this guide, display functions are referred to by their actual label names, and not by the soft key that is pressed (below the display).
Page 127: Positioner Icons
7. Menu Control Buttons To the left of the display, three buttons are provided to assist with navigating the menu system. • HOME — Press HOME to return the display to the top of the menu tree. Main Menu 1-2 will be displayed. •...
Page 128: Adjusting The Display
A) When the left-right Positioner Icon appears, you can use the top knob to adjust the selected function or you can move the Positioner left and right. B) When the up-down Positioner Icon appears, you can use the middle knob to adjust the selected function or you can move the Positioner up and down.
Page 129: Help Features
Help Features Two help features provide convenient on-line assistance as you operate your Synergy switcher: • Help Menu • Pop-up Help Help Menu The Help Menu provides a list of important “hidden” switcher functions that require two-button combinations to access, such as Keyer and MLE copy functions. The More Info Menu provides more extensive information about the requested function.
Page 130 Pop-up Help The Pop-up Help feature is designed to alert the operator when an illegal function is attempted. When the illegal button is pressed, the Pop-up Help Menu appears — providing a brief explanation of why the operation cannot be performed. A sample menu is shown below. Pop-up Help Menu The Pop-up Help Menu disappears when the illegal button is released.
Page 131: Screen Capture
Screen Capture Switcher users can take screen captures of the Synergy SD control panel menus. The switcher saves the screen capture as a 16K bitmap file, which you can then import into other applications on your PC. Use the following procedure to capture a bitmap of the current display screen: Insert a storage device into the Synergy control panel as follows: •...
Page 132 5–10 • Using the Menu System Synergy Series Installation Guide (v18)
Page 133: Bnc Configuration And Check
BNC Configuration and Check In This Chapter This chapter provides instructions for configuring and checking your BNC inputs. As you follow each procedure, you are in effect building a database that is used by the switcher to provide the desired names, sources, Key and fill associations, and overall switcher functionality.
Page 134: Installation Enable Jumper Setting
Installation Enable Jumper Setting Before you begin the configuration process, please ensure that the Installation Enable Jumper (JP10) on the front edge of the Frame CPU Board is in the Down position. This position allows all installation settings to be changed without restriction. Refer to the section “Frame Jumpers and Switches”...
Page 135: Bnc Configuration Menu Tree
BNC Configuration Menu Tree The following figure illustrates the portion of the menu tree that is used to configure your BNC connectors — specifically, the path used to reach the BNC Setup Menu and other associated setup menus. Use this figure for reference during the following procedures. Main Menu 1 Main Menu 2 MORE...
Page 136: Bnc Configuration
BNC Configuration The following procedures will be discussed in this section: • Naming BNC Inputs • Restoring Default BNC Names • Setting Up Mnemonics Displays for BNC Names • Setting Up BNC Types • Setting Up Tallies • Setting Up Alphas •...
Page 137 The bottom BNC number knob selects the input that you want to name. As you scroll through your inputs, the Current Name field tracks each name. Use the following procedure to name your inputs: Note During the procedure, refer to the Input Name column in your Input Worksheet.
Page 138: Restoring Default Bnc Names
To choose a preset name: • Press Preset Names to display the Preset Names Menu. BNC — Preset Names Menu • Use the middle knob to scroll the list of preset names. • Press Select to accept the preset name, or press Cancel to return. •...
Page 139: Setting Up Mnemonics Displays For Bnc Names
Use the following procedure to restore the default BNC name of a BNC connector: Navigate to the BNC Names Menu 1-2 as follows: • Press HOME MORE Setup Installation BNC Names. BNC Names Menu 1-2 Use the BNC Number knob until the desired BNC number is shown. As you rotate the knob, you will notice the Current Name Field changes to show the current name (as stored in switcher memory) of the BNC connector.
Page 140 Use the BNC Names Menu 2-2 to adjust how BNC names will appear in their associated mnemonic displays. • A Standard PS/2 keyboard can be used to perform the same actions as using the System Control buttons and knobs. Refer to the section, “Using The Keyboard” in Chapter 2 “Control Panel Introduction”...
Page 141: Setting Up Bnc Types
The selected mnemonic display changes on the switcher when you exit the Installation Menus. To adjust the mnemonic display style of another BNC name, use the BNC number knob. The selected BNC name/number appears in the mnemonic display area of the menu as you select BNCs from the list.
Page 142 Use the following procedure to set your input types: Navigate to the BNC Menu 1-3 as follows: • Press HOME MORE Setup Installation BNC. Press BNC Type to display the BNC Type Menu. BNC — BNC Type Menu Use the BNC knob to select the BNC input that you want to assign an input type to. Use the Type knob to select the desired input type.
Page 143: Setting Up Tallies
• Alpha — Select this option when an alpha signal (also known as a “key” signal) is connected to the selected BNC. Devices such as DVEs, Character Generators, Graphics (Paint) Systems, and Still Stores typically provide unique alpha signals. Selecting Alpha generates a filtered list on the Alpha Setup Menu. Router —...
Page 144 Press Tally to display the Tally Setup Menu. BNC — Tally Setup Menu Use the Tally knob to select the tally you want to assign. Use the BNC/MLE knob to select the MLE or BNC that you want to assign the selected tally to.
Page 145: Setting Up Alphas
Setting Up Alphas The Alpha Setup Menu allows you to select the specific keying mode for the selected alpha (Key) signal. These mode selections determine how the key is processed electronically, and how it appears visually. Operating During the procedure, refer to the Alpha Type column in your Input Worksheet.
Page 146: Setting Up Auto Keys
levels, giving the key a soft edge. Unshaped Key alphas can also be consider true linear alphas. Key alphas are set as unshaped by default. Shaped — Select Shaped to have the switcher perform an additive Key. With a shaped Key, the Key alpha cuts a hole based on the monochrome value of the alpha.
Page 147: Ultimatte Insider
Ultimatte Insider If you have purchased the Ultimatte Insider option, refer to Appendix C, “Hardware Options” for detailed instructions on installing the board, setting it up using the menu system, and setting up special Ultimatte Auto Select keys. Setting Up Panel Buttons As the last step in the BNC configuration process, the Panel Button Setup Menu allows you to map BNC connectors to physical buttons on the control panel.
Page 148: Shifted Crosspoint Buttons
• PGM/Key SHIFT — Select this option to have the SHIFT button access the unshifted crosspoints on the Key bus of each MLE. Refer to the section “Shifted Crosspoint Buttons” on page 6–16 for more information on using this function. Important The SHIFT and PGM/Key Shift functions are mutually exclusive.
Page 149 Use the following procedure to access a shifted crosspoint: Press and hold the SHIFT button on the crosspoint bus you want to access the shifted crosspoint on. Press the Crosspoint button you want to select. Release both buttons. Both the Crosspoint button and SHIFT buttons will remain lit. Note If you press another Crosspoint button, you will select an unshifted crosspoint and the SHIFT button will not be lit.
Page 150: Bus Hold Function
Aux Bus Setup Menu — Shift Mapping Message Bus Hold Function The Bus Hold function allows you to retain the currently selected video crosspoint on a bus during a memory recall. If the BUS HOLD button is assigned to a crosspoint, each bus BKGD (or PGM), PST, Key 1, and Key 2, on all MLEs, can be held independently.
Page 151: Exiting The Setup Menus
Use the N/S Control knob to select between the following: • Individual — Select this option to disable the N/S LED for the selected BNC input only. • All OFF — Select this option to turn all the N/S Disable setting Off. This will override all the individual N/S Disable settings, and return the BNCs to a N/S Disable OFF mode.
Page 152: Checking Inputs
Checking Inputs At this point in the installation process, ensure that you have performed the following tasks for each BNC input to your Synergy switcher: • Named the input • Set up its BNC type • Set up its tally •...
Page 153: Checking Keys
Checking Keys Once your inputs have been checked, you can now check each auto-key association that you have made. This procedure allows you to verify that each alpha-fill combination is working properly, and generating a proper linear key. Use the following procedure to check your keys: On the PGM Bus, select the re-entry crosspoint for MLE 1.
Page 154 MLE 1 KEY 1 SELF AUTO CHROMA SELECT PATT MATTE FILL MASK BORD SHDW OVER OUTL AUTO BORD TRANS Sample MLE Keyer State Visually check the appearance of the Key on the monitor: • The assigned alpha signal should be properly cutting the hole in the background. •...
Page 155 If the Key alpha and fill sources are correct, but the Key does not appear correct visually, check the following “mode” assignments that you made on the Alpha Setup Menu: BNC — Alpha Setup Menu • If you selected Unshaped and the alpha signal is actually Shaped, you will see black edges around the keyed image.
Page 156 6–24 • BNC Configuration and Check Synergy Series Installation Guide (v18)
Page 157: Basic Communications Setup
Basic Communications Setup In This Chapter This chapter provides instructions for setting up communications parameters with peripheral equipment. The following topics are discussed: • Communications Menu Tree • Remote Port Expander (BSS4) Setup • Custom Device Setup • Peripheral Interface II Protocol Setup •...
Page 158: Communications Menu Tree
Communications Menu Tree The figure below illustrates the portion of the Synergy menu tree that is used for communications set up procedures. Use this figure for reference throughout this chapter. Main Menu 1 Main Menu 2 MORE Custom Preview Clips Aux Bus Logo Setup...
Page 159: Remote Port Expander (Bss4) Setup
Remote Port Expander (BSS4) Setup The RS-422 Four Port Buffered Smart Switch (Model RS422BSS4) connects to one of the Remote Ports on the back of the Synergy control panel to allow you to control up to four serial devices from that one port.
Page 160 Assign the BSS4 to the Expander communications port as follows: • Use the Com Port knob to select the communications port you want to assign the specific BSS4 to. • Use the Device knob to select BSS4. Press Com Settings to display the Communications Settings Menu. Communications —...
Page 161 When you press Confirm, a second screen will be displayed prompting you to program the BSS4 Remote Port Expander. BSS4 — Program BSS4 Screen Note If you press Cancel, a warning message will be displayed and you will have to perform the setup of the BSS4 again. 12.
Page 162: Connecting Equipment To The Remote Port Expander (Bss4)
You will now notice that there are four new remote ports on the Communications Menu 1-2. These ports will be labelled A, B, C and D, corresponding to the Slave Ports on the BSS4, and will start with the number of the remote port that the BSS4 is connected to. Communications —...
Page 163 to the section “Programming the BSS4 for Peripheral Devices” on page 7–7 for more information. Slave Port B Slave Port C Model RS422BSS4 RS-422 Four Port Buffered Smart Switch Power Master Port BSS4 Remote Port Expander The Slave Ports A, B, C and D on the BSS4 correspond to the Remote #A, Remote #B, Remote #C, and Remote #D ports on the Communications Setup Menu of the Synergy switcher.
Page 164 Disconnect the BSS4 Power Supply from the BSS4 to cycle the power Off. Reconnect the BSS4 Power Supply to the BSS4 to cycle the power On. Press Continue on the Synergy control panel. Note If you press Cancel, a warning message will be displayed and you will have to perform the setup of the BSS4 again.
Page 165: Custom Device Setup
Custom Device Setup The Custom Device Setup procedure allows you to set up communications parameters with custom external devices. Note The Custom Device Setup is an advanced feature requiring technical knowledge of serial protocols. Refer to Appendix F, “Custom Device Serial Protocols”, for detailed information and set up procedures.
Page 166: Peripheral Interface Ii Protocol Setup
PIP-II device that can control up to 24 peripheral devices from a single remote port on the Synergy switcher. Ensure that the Peripheral Interface II Protocol option is installed. If not, please contact Ross Video for details. Refer to the section “Installed Options Menus” on page 2–37 for instructions on verifying the status of installed options.
Page 167 Press Com Settings to display the Com Settings Menu. Communications — Com Settings Menu Set the communications protocols for the PIP-II device as follows: Note Refer to your PIP-II device documentation for the specific Baud and Parity settings of your PIP-II device. •...
Page 168 Communications — Extra Options Menu 11. Select the type of querying command for the PIP-II device as follows: • Use the Com Port knob to select the PIP-II device you want to set the querying command type for. Use the Option knob to select Query Cmd. •...
Page 169: Serial Tally Protocol Setup
Before proceeding to the sections below, ensure that the Serial Tally software option is installed. If not, please contact Ross Video for details. Refer to the section “Installed Options Menus” on page 2–37 for instructions on verifying the status of installed options.
Page 170 Select the tally system you want to assign to the tally system communications port as follows: Use the Com Port knob to select the communications port you want to assign a • specific tally interface to. • Use the Device knob to select the type of tally interface that is connected to the port.
Page 171 10. Press Extra Options to display the Extra Options Menu. 11. Assign an update rate to the tally interface as follows: Communications — Extra Options (Rate) Menu • Use the Com Port knob to select the tally interface you are setting the rate for. •...
Page 172: Look Ahead Serial Tallies Protocol Setup
This completes the procedures for setup of the Contribution Serial Tally Protocol option. If you require further information on the various options and their associated values, contact Ross Video Technical Support at the number listed in the front of this guide.
Page 173 Press Type to display the Type Menu. Communications — Type Menu Assign a com port to the tally system as follows: • Use the Com Port knob to select the remote port on the Synergy switcher that is connected to the tally system. Use the Device knob to select Serial Tally.
Page 174 This concludes the procedure to configure the L.A.S.T. protocol option. If you require further information on the various options and their associated values, contact Ross Video Technical Support at the number listed in the front of this guide.
Page 175: Dsk 3/4 (Cdk-111A-M) Communications Setup
DSK 3/4 (CDK-111A-M) Communications Setup The DSK 3/4 Communication Setup procedure allows you to set up communications with the CDK-111A-M Downstream Keyers. Once the procedure is completed, you will have full functionality of an additional one or two DSK 3/4s on your Synergy switcher. Use the following procedure to set up communications with a CDK-111A-M in Downstream Keyer mode: Ensure that the CDK-111A-M boards are installed.
Page 176 • Use the Device knob to select the type of DSK that is connected to the peripheral port. You can chose between the following: NONE — Select this option to not assign a DSK to the selected port. Note If the CDK-111A-M card is not being used and is removed from the frame, you must set the middle Device knob to NONE.
Page 177: Custom Control Basics
Custom Control Basics In This Chapter This chapter provides basic instructions for setting up and naming custom control banks, and programming, naming, and editing your custom control buttons. The following topics are discussed: • Custom Control Banks Menu Tree • Custom Controls Menu Tree •...
Page 178: Custom Control Banks Menu Tree
Custom Control Banks Menu Tree The following figure illustrates the portion of the Synergy menu tree that is used for setting up Custom Control banks. Use this figure for reference throughout the following chapter. Main Menu 1 Main Menu 2 Custom Preview MORE...
Page 179: Custom Controls Menu Tree
Custom Controls Menu Tree The following figure illustrates the portion of the Synergy menu tree that is used for programming custom control buttons. Use this figure for reference throughout this chapter. Main Menu 1 Custom Preview Controls Disk Attributes Help Overlay Effects Custom Controls Menu...
Page 180: Custom Controls
Custom Controls The Custom Control function allows you to program sequences of keystrokes (called “macros”) and other special switcher functions — and store them in dedicated buttons and banks in the Custom Control group. Once programmed, a macro can be played back simply by pressing one button in the Custom Control group.
Page 181 • Synergy 4 — The following figure illustrates the Custom Control Group for the Synergy 4, 2003 edition panel. A total of 35 registers are provided, up to eight of which can be assigned as banks to increase the total number of available registers. INTRO INTRO CUSTOM...
Page 182 • DVE Functions — Using the primary DVE, a custom control button can be programmed to perform a specific DVE command such as play effect, frame advance, and stop. The DVE Send and Remote Control Option must be installed. • Time Clock Functions —...
Page 183: Custom Control Banks
Custom Control Banks Before programming the actual Custom Control buttons themselves, you must determine whether or not you want to enable custom control “Banks.” This feature effectively multiplies the total number of custom control buttons that you have available. Two types of banks are available: Normal and Audio. Normal banks are for storing normal custom controls dealing with typical switcher video functions.
Page 184: Naming Custom Control Banks
• Use the Type button to select the Custom Control Bank type you are creating. Audio — Use this option for macros that communicate with remote audio mixers. Operating When an Audio Bank button is pressed and held, the PGM/PST buses operate in Audio Custom Control Mode.
Page 185 Press Modify Bank Names to display the Custom Control Bank Names Menu. Custom Control Bank Names Menu 1-2 Note If the Mnemonic Display option is purchased and installed, the Mnemonic field displays the bank name as it will appear in the associated mnemonic display.
Page 186: Customizing Mnemonic Displays - Banks
Change Name Confirmation Screen • Press Continue to proceed without saving the changes you made to the name. • Press Cancel to return to the previous menu and accept the new name. Repeat for each bank that you want to name. Operating It is recommended at this point that you name each bank.
Page 187 Press MORE to display the Custom Control Bank Names Menu 2-2. Custom Control Bank Names Menu 2-2 Operating A Standard PS/2 keyboard can be used to perform the same actions as pressing or rotating the System Control buttons and knobs. Refer to the section, “Using The Keyboard”...
Page 188 None — Select this option to turn the display off. Select which character of the bank name will be the first one to appear in the mnemonic display as follows: • Use the Bank number knob to select the desired Bank Number. •...
Page 189: Programming Control Panel Functions
Programming Control Panel Functions Use the following procedure to program a normal custom control button with basic functions: Operating If you are programming long or looping custom controls, you should keep at least one unprogrammed custom control. Pressing an unprogrammed custom control button, one with no macros recorded on it, will stop a running custom control macro.
Page 190 Note Press Cancel Recording to terminate the programming procedure. The macro will not be recorded. With the recording in progress, press the buttons on the control panel that you would like to have played back — in order. All subsequent keystrokes will be remembered, in the exact order that you press them.
Page 191 • Router Custom Controls — Refer to the section “Router Custom Controls” for more information. • Robotic Camera Controls — Refer to the section “Robotic Camera Custom Controls” for more information. • Monitor Wall Controls — Refer to the section “Monitor Wall Custom Controls” for more information.
Page 192: Relative Custom Controls
Relative Custom Controls Important Relative Custom Controls can only be properly recorded and recalled on upper MLEs that are re-entered onto the PGM/PST MLE. If the MLE is not re-entered, you will not be able to properly record or recall a relative custom control.
Page 193: Programming A Relative Custom Control
Programming a Relative Custom Control Use the following procedure to program a relative custom control button with basic functions: Set up your MLE re-entry configuration to record the relative custom control at the Re-entry level you want. Note You must record a relative custom control on an MLE that is re-entered onto the PGM/PST MLE for it to run properly.
Page 194 Insert any special functions you want as follows: • Press Insert Special to display the Insert Special Menu 1-2. • Refer to the section “Programming Special Functions” on page 8–19 for information on inserting special functions. Press Finish Recording when you have finished recording the macro. Operating You can also stop the recording by pressing the flashing custom control button that was selected on the panel.
Page 195: Programming Special Functions
Programming Special Functions The following sections describe how to program your custom controls with various other special functions. Refer to the section “Editing Custom Control Macros” on page 8–47 for more information on inserting events into existing custom control macros. The following functions are covered in this section: •...
Page 196 Navigate to the Insert Time Clock Menu as follows: • Press Start Recording Insert Special Time Clock. This menu allows you to choose specific Time Clock control functions to assign to the button. Insert Time Clock Menu Select a Time Clock function to insert as follows: •...
Page 197: Special Functions
Once your custom control buttons have been programmed, be sure to properly name them. Refer to the section “Naming Custom Controls” on page 8–42 for more information on naming custom control buttons. To play back your macro, exit the Custom Controls Menu and press the custom control button on the control panel that you recorded the custom control macro to.
Page 198 control panel. Remember that buttons marked with an asterisk (*) in the list have already been programmed. Operating As a recommendation, keep special functions grouped together on your physical custom control buttons. Navigate to the Special Menu as follows: • Press Start Recording Insert Special Special.
Page 199 Custom Controls Menu Select the custom control button you want to record to as follows: • Use the Bank knob to select the custom control bank you want to record the custom control to. • Use the Button knob to select the custom control button that you want to record a custom control macro to.
Page 200 Press Finish Recording, or the flashing custom control button, to finish recording to the selected custom control. The custom control button will stop flashing. Once your custom control buttons have been programmed, be sure to properly name them. Refer to the section “Naming Custom Controls”...
Page 201 Insert Special — Special Menu Assign an automation function to the selected custom control macro as follows: • Use the Selection knob to select Automation. • Use the Command knob to select the command you want the macro to perform. You can select between the following: Keys Off Air —...
Page 202 Navigate to the Custom Controls Menu as follows: • Press HOME Custom Controls. Custom Controls Menu Select the custom control button you want to record to as follows: • Use the Bank knob to select the custom control bank you want to record the custom control to.
Page 203 Border — Select this option to display the S&T Border Menu for the active Fly Key when the custom control is run. Sequence — Select this option to display the S&T Sequence Menu 1-2 for the active Fly Key when the custom control is run. Pre Processor —...
Page 204 Select the custom control button you want to record to as follows: • Use the Bank knob to select the custom control bank you want to record the custom control to. • Use the Button knob to select the custom control button that you want to record a custom control macro to.
Page 205 Key1+2 Off — Select this option to have both Key 1 and Key 2 dissolve off-air when the custom control is run. Key1 On — Select this option to have Key 1 dissolve on-air when the custom control is run. Key2 On —...
Page 206 Custom Controls Menu Select the custom control button you want to record to as follows: • Use the Bank knob to select the custom control bank you want to record the custom control to. • Use the Button knob to select the custom control button that you want to record a custom control macro to.
Page 207 To play back your macro, exit the Custom Controls Menu and press the custom control button on the control panel that you recorded the custom control macro to. Any recorded custom control can be edited. Refer to the section “Editing Custom Control Macros” on page 8–47 for details. Roll VTR Mode The Roll VTR Mode determines how the ROLL VTR button behaves when a VTR is selected.
Page 208 Custom Controls Menu Select the custom control button you want to record to as follows: • Use the Bank knob to select the custom control bank you want to record the custom control to. • Use the Button knob to select the custom control button that you want to record a custom control macro to.
Page 209 Armed Always — Select this option to have the ROLL VTR always active, the button is always lit. The clip will play when it is taken on-air when you press the assigned crosspoint button. Press Insert to enter the change in Roll VTR Mode into your custom control macro. Press UP ONE to return to the Custom Controls Recording Menu.
Page 210 Operating As a recommendation, keep special functions grouped together on your physical custom control buttons. Navigate to the Special Menu as follows: • Press Start Recording Insert Special Special. Insert Special — Special Menu Assign a Custom Control Hold as follows: •...
Page 211 Custom Controls Menu — Custom Control Held Pop-up Press Insert to enter the Custom Control Hold into your custom control macro. Press UP ONE to return to the Custom Controls Recording Menu. Press Finish Recording, or the flashing custom control button, to finish recording to the selected custom control.
Page 212 control panel. Remember that buttons marked with an asterisk (*) in the list have already been programmed. Operating As a recommendation, keep special functions grouped together on your physical custom control buttons. Navigate to the Special Menu as follows: • Press Start Recording Insert Special Special.
Page 213: Peripheral Interface Ii Custom Controls
Peripheral Interface II Custom Controls A custom control button can be programmed to send messages to devices using the Peripheral Interface II Protocol. Note Ensure that the Peripheral Interface II Protocol (PIP-II) option is installed and that the PIP-II device you want to control is properly connected and configured with the Synergy switcher.
Page 214 Assign a command to a PIP-II device for the custom control as follows: • Use the top knob to select the PIP-II device you want to assign a command to. You can select between the following: Note The Ports are identified by the remote port on the Synergy control panel that the PIP-II device is connected to.
Page 215: Copy Mle Custom Controls
Copy MLE Custom Controls The Copy MLE function allows you to copy the contents, including crosspoints, matte generator values, fader positions, on-air status, key active status, and key over priorities, of an MLE to another MLE location on the switcher. You can record a Copy MLE function to a custom control button using the Custom Controls Menu.
Page 216: Notes On Using The Copy Mle Function
• Press and hold the BKGD button in the Program/Preset Transition Group of the destination MLE. BKGD KEY1 KEY2 • Press the BKGD button in the Program/Preset Transition Group of the source MLE. • Release both buttons. Press Finish Recording, or the flashing custom control button, when you have finished recording the macro.
Page 217 If you copy an MLE that has its TRANS LIMIT button enabled to the Program/Preset MLE, the Program/Preset MLE does not have a TRANS LIMIT button. If you copy the Program/Preset MLE with its PST BLACK button enabled to an MLE, the MLEs do not have a PST BLACK button.
Page 218: Naming Custom Controls
Naming Custom Controls A custom control button can be named for ready identification in the menus, and in the mnemonic displays if that option is installed. Once your custom control buttons have been programmed, be sure to properly name and label them. Refer to the section “Pushbutton Inserts”...
Page 219 Note If the mnemonic option is purchased and installed, the Mnemonic field displays the custom control name as it will appear in the associated mnemonic display. Further mnemonic display configurations are discussed in section “Customizing Mnemonic Displays — Banks” on page 8–10. Assign a New Name to the custom control as follows, or continue to the next step to enter a Preset Name: •...
Page 220: Customizing Mnemonic Displays - Buttons
• Use the middle knob to select a preset name (a prefix) from the list of typical custom control names. • Press Select to accept the preset name, or Cancel to return to the previous menu. Operating You can edit a preset name on the Custom Name Menu just as you would a New Name you entered.
Page 221 • Use the Font knob to select the size of the font. You can select from the following: Standard — Select this option to use the default mnemonic format as set from the Personality Menu. Small — Select this option to use a small font that permits up to 6 characters per line.
Page 222 Change Name Without Saving Message • Press Continue to proceed without saving the changes you made to the name. • Press Cancel to return to the previous menu and accept the new name. This completes the procedure for naming and customizing the look of your custom controls. 8–46 •...
Page 223: Editing Custom Control Macros
Editing Custom Control Macros After your custom control buttons have been programmed, you may wish to review and edit the contents. Events can easily be inserted or deleted through the Custom Controls Menu. The Custom Controls Menu displays the following information: •...
Page 224: Modifying Events
Edit Custom Control Menu Note If your macro includes pauses or holds, a timeline will be displayed showing these events. You can select between the following editing functions: • Go To Start — Select this function to go to the start of the macro. •...
Page 225 Custom Controls Menu Select the Custom Control bank and button that you want to edit to as follows: • Use the Bank knob to select the custom control bank that you want to edit the custom control on. • Use the Button knob to select the custom control that you wish to edit. Note Only buttons with an asterisk (*) or an “at”...
Page 226: Inserting Events
Press Insert to save your changes. Press UP ONE to display the Inserting Menu. Custom Controls — Recording Menu Press Finish Inserting to finish inserting to the selected custom control. Operating Press Cancel Inserting to return to the previous menu without recording any of the insertions you made.
Page 227 Press Edit to display the Edit Custom Control Menu. Edit Custom Control Menu Go into the Inserting Mode as follows: • Use the middle knob to highlight the event that you want to insert an event before. • Press Insert Events to display the Inserting Menu. Edit Custom Control —...
Page 228 Custom Controls — Recording Menu • Press Finish Inserting to finish inserting to the selected custom control. Operating Press Cancel Inserting to return to the previous menu without recording any of the insertions you made. This completes the procedure for inserting events into your custom control. 8–52 •...
Page 229: Deleting Custom Controls
Deleting Custom Controls Use the following procedure to delete a custom control function from a button: Navigate to the Custom Controls Menu as follows: • Press HOME Custom Controls. Custom Controls Menu Select the Custom Control bank and button that you want to delete to as follows: •...
Page 230: Saving And Recalling Custom Controls
Saving and Recalling Custom Controls For archive purposes and to keep safe backup copies of your valuable macros, it is recommended that you store your custom control functions to a storage device such as a floppy disk or USB key. This also allows you to keep a library of custom functions that can be recalled as required for your current production configuration.
Page 231: Additional Installation Setups
Additional Installation Setups In This Chapter This chapter provides instructions for additional installation setup procedures. The following topics are discussed: • Installation Setup Menu Tree • Aux Bus Setup • Modifying Aux Bus Names • Output Setup • Standard GPI Setup •...
Page 232: Installation Setup Menu Tree
Installation Setup Menu Tree The following figure illustrates the portion of the menu tree that is used for additional installation setup procedures. Use this figure for reference throughout this chapter. Main Menu 1 Main Menu 2 MORE Custom Preview Clips Aux Bus Logo Setup...
Page 233: Aux Bus Setup
Aux Bus Setup The Aux Bus Menu 1-2 allows you to set up Aux (Auxiliary) panels, and assign certain “rights” to those panels. The setups procedures cover both local and remote Aux panels. • The “Local” Aux panel consists of the Aux Bus (on the Switcher control panel), plus the Aux Bus Assign Group of the switcher, as displayed in the following figure (on the Synergy 4): AUX BUS ASSIGN...
Page 234: Modifying Aux Bus Names
Modifying Aux Bus Names Each Aux Bus can be named to represent the function that it will actually control. You can modify the Aux Bus names using the Aux Bus Names Menu: • The Main Area of the Aux Bus Names Menu provides an array of letters and numbers. The reverse video highlight indicates the “selected”...
Page 235: Setting Up Local Aux Panels
Press Accept New Name to register the Aux Busses new name in memory. The new name is transferred to the Current Name Field. Repeat for each additional Aux Bus that you want to name. Note If you exit the installation menus without first pressing Accept New Name, the following screen is displayed.
Page 236 Assigning MLE Crosspoints to the Local Aux Panel The Aux Bus Setup Menu allows you to set specific switching parameters (or “rights”) for each of the 12 Aux Buses that are accessible from the control panel in the Aux Bus Assign Group. Each bus can be set up individually.
Page 237 In Appendix D, refer to the “Bus Mode Setup” section for detailed instructions on Bus Follow mode and the associated Bus Assign softkey on the Bus Follow Menu. Note In Bus Follow mode, the user is “locked out” of the designated Aux Bus and can not make selections on the Aux Bus panel itself.
Page 238 • Use the Mode knob to select Regular. An Aux Bus must be set to Regular Mode in order to assign a crosspoint on the local Aux Panel to a BNC. • Use the Xpt mapping knob to select Definable. Press MORE to display the Aux Bus Menu 2-2.
Page 239: Assigning Router Follow
Press Select Output to display the Select Output Menu. Note On Ross Routing Systems, the matrix is controlled by breakaways that have the different levels assigned to them. Refer to your router documentation for information on assigning different levels to a breakaway.
Page 240 Use the Level knob to select the router output level. Zero on the list will correspond to the first level on the router. Note On the Ross Routing Systems, this is the Breakaway knob and you can only select from 1 through 8. Press Input Matrix to display the Input Matrix Menu.
Page 241: Assigning Aux Bus Tallies
Assigning Aux Bus Tallies When an Aux Bus is used to route video to an external device (such as a DVE or a VTR), this procedure sets up the method for tallying that bus. By selecting certain parameters, you can tally the bus (lighting the Aux panel’s red “ON”...
Page 242: Setting Up Remote Aux Panels
Note The GPI & XPT On function is specifically designed for external DVEs that can generate a GPI trigger each time a different input source is used in an effect (e.g., in a rotating effect in which different sources are used on the front and back sides of the image). For additional information, refer to Appendix B, “DVE Specifics.”...
Page 243 On newer models of assignable panels, this mode is set automatically to match that of the main Control Panel. For details on older model panels, contact Ross Video Technical Support. Note Special modes such as the PGM/Key SHIFT mode are not available on remote panels.
Page 244 another user), but you cannot change crosspoints from the current panel. The button’s light is flashing. • Repeat the last step for each of the 12 Aux Buses. Assign the rights for a dedicated panel for each dedicated panel connected to the frame as follows: •...
Page 245: Output Setup
Output Setup The Output Setup Menu allows you to set up six specific output parameters: • MLE Tally Setup • MLE Aspect Ratio Setup • Clean Feed Setup • Fade to Black Setup • Ancillary Data • Trigger Field Setup Each topic is discussed in the following sections.
Page 246: Mle Aspect Ratio Setup
MLE Aspect Ratio Setup The MLE Aspect Ratio Menu allows you to assign an output aspect ratio to a selected MLE. This parameter is valid only when the Aspectizer option is installed. This feature is primarily designed for the Synergy 2, 3, and 4 switchers, in which one MLE can be assigned as 4:3 and another MLE assigned as 16:9 —...
Page 247: Fade To Black Setup
Use the MLE knob to select the single MLE from which the feed originates. Only one MLE can be selected. Use the Type knob to select the point from which the output is taken in the MLE’s video path. You can select between the following: •...
Page 248: Ancillary Data
• Press HOME MORE Setup Installation Output Fade to Black. Fade to Black Menu Toggle the desired MLEs On or Off, as required. This completes the procedure to select the MLEs that you want to fade to black. Ancillary Data The Ancillary Data Menu allows you to select lines in the vertical/horizontal blanking area of the video stream, which can then be stripped or passed.
Page 249 Output — Ancillary Data Menu Ancillary Data menu components: • Legend with colors indicating whether a line is: Passed — When a line is passed, the original line data is preserved. Stripped — When a line is stripped, the switcher substitutes black for that line. Stripped (Switching Line) —...
Page 250: Trigger Field Setup
(refer to the following example). Ancillary Data Menu with Additional Lines Stripped Contact Ross Video Technical Support for any additional assistance with Ancillary Data setup. Trigger Field Setup The Trigger on feature allows you to select when the Synergy switcher will trigger a transition from one video source to the next.
Page 251 Output Menu Toggle the Trigger on softkey to select F1 or F2. • F1 — Select F1 (Odd Field/Field 1) to trigger the transition to the next video source after the Odd Field of the first source. This is the default setting. •...
Page 252: Standard Gpi Setup
Standard GPI Setup The GPI Setup Menu allows you to set up your 12 “standard” GPI Input ports and 12 GPI Output ports. All 24 ports are provided on the GPI I/O connector. Refer to the section “Standard GPI Connections” on page 9–33 for wiring instructions. Before setting up your GPIs, please complete the following worksheets.
Page 253: Standard Gpi Output Worksheet
Standard GPI Input Worksheet Standard GPI Input # Event Type Event Area Polarity Sample GPI Input #1 Auto MLE 1 Sample GPI Input #2 Fade to black High Sample GPI Input #3 Cust Ctrl Custom08 1 #08 High Standard GPI Output Worksheet Complete the following “standard”...
Page 254: Programming Standard Gpi Inputs
Standard GPI Output Worksheet Standard GPI Output Output Name Trigger Type Trigger Level Sample GPI Output #1 PrevStill Edge Sample GPI Output #2 Roll VTR Level High Programming Standard GPI Inputs The GPI Input Setup Menu allows you to associate each GPI Input with an area and button on the switcher that you would like to trigger, when that specific GPI input pulse is received from an external device.
Page 255 Assign a function to the GPI Input port as follows: • Use the GPI Input knob to select the GPI Input port (1 to 12) to which you want to assign a switcher event type and location (area). • Use the Function knob to select a specific function. You can select between the following: Operating The label of the bottom knob changes depending on the selection made...
Page 256 FADE TO BLACK FRAMES FADE AUTO GPI Transition Type and Trigger Locations — Fade to Black Group Assign the polarity for the GPI input port as follows: Press GPI Polarity to display the GPI Input Polarity Menu. • GPI Input Polarity Menu •...
Page 257 Use the following procedure to allow a GPI input to trigger a custom control: Navigate to the GPI Setup Menu as follows: • Press HOME MORE Setup Installation GPI I/O. Press Inputs to display the GPI Input Setup Menu. GPI Input Setup — Custom Controls Menu Use the GPI Input knob to select the GPI Input port (1 to 12) to trigger the custom control.
Page 258 • Use the GPI Input knob to select the GPI Input port (1 to 12) for which you want to set the polarity. • Use the Polarity knob to select the polarity of the port; refer to the Polarity column of your Standard GPI Input Worksheet. Refer to your source device’s documentation for details on the specific type of GPI pulse that the device provides.
Page 259: Programming Standard Gpi Outputs
• Use the Memory knob to select a memory that can be recalled by triggering a GPI input. Assign the polarity for a GPI input port as follows: • Press GPI Polarity to display the GPI Input Polarity Menu. GPI Input Polarity Menu •...
Page 260 scroll knobs. The Current Name and New Name fields are located below the array. In the New Name field, the reverse video highlight indicates the “active” character — the one that you are changing. • The Label Area provides an array of tools for naming and editing your physical GPI Output names.
Page 261 Press Accept New Name to register the output port’s new name in memory. The new name is transferred to the Current Name Field. Repeat for each additional GPI output port that you want to name. Note If you exit the installation menus without first pressing Accept New Name, the following screen is displayed.
Page 262: Tally On Gpis
• When Level is assigned, the GPI output port’s line is held at the selected state (low or high) until triggered, whereupon the line switches to the opposite state — and holds there. • When Edge is assigned, the GPI output port’s line is held at the selected state (low or high) until triggered, whereupon the line switches to the opposite state momentarily —...
Page 263: Standard Gpi Connections
Refer to Appendix A “Specifications” for standard GPI connector specifications. The GPI connector is located on the rear of the frame as shown below: EDITOR INPUTS SERIES DIGITAL PRODUCTION SWITCHER ROSS VIDEO LTD. MODEL ISSUE SERIAL# GPI I/O CAUTION: DISCONNECT POWER...
Page 264: Remote Aux Panel Gpi Setup
Remote Aux Panel GPI Setup New versions of the Dedicated and Assignable Remote Aux Panels include a feature that allows the manual override of the Aux panel selection via GPI triggers. For purposes of camera matching or monitoring, the feature overrides the selected Aux Bus crosspoint and manually switch to a camera’s BNC —...
Page 265 Remote Aux Panel GPI Input Worksheet Remote GPI Group / Offset / Assigned Assigned Type/Edge Physical Physical GPI Aux Bus Connection Sample Aux GPI 5 Group 1, Offset 0, GPI 5 Aux Bus 1 5 (Cam 4) Cam 4 Joystick Group 1, Offset 0, GPI 1 Group 1, Offset 0, GPI 2 Group 1, Offset 0, GPI 3...
Page 266 Remote Aux Panel GPI Input Worksheet Remote GPI Group / Offset / Assigned Assigned Type/Edge Physical Physical GPI Aux Bus Connection Group 5, Offset 4, GPI 1 Group 5, Offset 4, GPI 2 Group 5, Offset 4, GPI 3 Group 5, Offset 4, GPI 4 Group 5, Offset 4, GPI 5 Group 5, Offset 4, GPI 6 Group 5, Offset 4, GPI 7...
Page 267: Remote Aux Panel Gpi Connection
Remote Aux Panel GPI Connection In this section, you will wire each Remote Aux Panel GPI port to the designated joystick switch on selected camera CCUs. If you wish to connect GPIs on more than one panel to different CCU joysticks, each connector must be wired at this time.
Page 268 Aux Bus Remote Panels Setup Menu Go to the first assignable or dedicated Aux panel that you want to program. Ensure that the panel is in “programming” mode (with the on-air LED flashing). Press CLEAN FEED to switch the panel from “assignment” programming mode to “GPI”...
Page 269: Setting Up Ccu Joystick Aux Control
Note also that when each GPI is shorted to ground, the corresponding GPI Icon on the Remote Panels Menu will light. Refer to section “Monitoring CCU Joystick Selections” on page 9–41 for details on GPI icons. When programming for this panel is complete, on the Remote Panels Menu press Accept to store all new settings and exit the programming mode.
Page 270 Note The text above the Remote GPI Type label indicates the type of trigger selected for the highlighted remote GPI. This information tracks each GPI as you rotate the top Remote knob. Press Remote GPI Type to display the Remote GPI Type Menu. Remote GPI Type Menu Set up the desired remote GPI trigger type as follows: •...
Page 271: Monitoring Ccu Joystick Selections
Verifying BNC Selection Use the following procedure to verify that the proper BNCs have been selected: Go to each of the assignable or dedicated Aux panels (on which you have assigned override crosspoints). Select BLACK on the Aux Bus panel. Press each CCU joystick button in succession, and verify that the desired BNC is selected —...
Page 272 • The middle column indicates the status of each GPI port, using two types of GPI icons. Important GPI icons are numbered from left to right, starting at GPI 8 and counting down to GPI 1. These correspond to the 8 available ports on each Aux panel.
Page 273: Switcher Calibration
Switcher Calibration The Calibration Menu allows you calibrate all analog controls on the switcher panel, including the faders, the XYZ positioner, and all knobs (excluding those to the right of the display). The Calibration Menu includes the following information: Caution Use this mode with caution.
Page 274 • Calibrate the Y-Axis by moving the joystick fully up and down. Repeat this procedure two or three times. • Calibrate the Z-Axis by twisting the joystick knob fully clockwise, then counterclockwise. Repeat this procedure two or three times. As you move the joystick, you will see a series of numbers appear in the Main Area, under the POSITIONER heading.
Page 275: Dsk Setup
DSK Setup The following DSK procedures are discussed in this section: • Programming DSK Crosspoints • Storing DSK Crosspoint Assignments • DSK 3/4 (CDK-111A-M) Setup Each procedure is explained in detail in the following sections. Programming DSK Crosspoints This setup procedure allows you to select the key type (and the key source) for each Key Bus button on Downstream Keyer (DSK) 1 and DSK 2.
Page 276 DOWNSTREAM KEYER 1 DSK 3 MATTE MASK FILL AUTO BORD BORD SHDW OUTL TRANS SOURCE SOURCE SOURCE SOURCE SOURCE SOURCE SOURCE DSK 3 Key Bus SELECT DSK 1 (and DSK 2) Key Bus on Synergy 3 and 4 Switchers The figure below illustrates the two Downstream Key Bus locations on the Synergy 2 switcher. Note that sample crosspoint names are used.
Page 277 Press the DSK Key Bus button that you just programmed, and look at the display. Verify that the following choices are correct: DSK Key number (1 or 2) • • DSK Key Bus crosspoint (labeled as DSK Button) • Key type (labeled in the upper left corner) •...
Page 278: Storing Dsk Crosspoint Assignments
Sample DSK 1 PST Key Setup Menu Repeat steps 1 through 7 for each DSK Key Bus button — in both of your switcher’s DSKs. This completes the procedure to program each crosspoint on the DSK’s Key Bus. Notes on Programming DSK Key Bus Buttons Please note: •...
Page 279: Dsk 3/4 (Cdk-111A-M) Setup
The Synergy switcher can utilize up to two optional DSK 3/4s (CDK-111A-Ms) that are installed in Ross Video’s DFR-8110A-C and DFR-8104A-C DA frames. Each DSK 3/4 has Self and Auto Select key capabilities only. Borders, DVE Send transitions and Squeeze and Tease capability are not provided with external DSKs.
Page 280 CDK-111A-M Downstream Keyer Each DSK 3/4 (CDK-111A-M) has independent PGM and PV serial digital video outputs and four serial digital video inputs – BKGD1, BKGD2, KeyVideo and KeyAlpha. The BKGD1 input is also used as the reference and, therefore, must always be present for the card to provide a video output. The following DSK 3/4 procedures are discussed in this section: •...
Page 281 Setting up Communications Use the following procedure to set up communications with a CDK-111A-M external downstream keyer: Note After setting up communications between a Synergy switcher and an DSK 3/4, the button that was designated as SOURCE 8 in the Downstream Keyer 1 panel area is now DSK3 SELECT (and DSK4 SELECT for Downstream Keyer 2).
Page 282 10. If you have two CDK-111A-M keyers installed, repeat steps 8 and 9, rotating the top Com Port knob to select Periph2 (P2) and the middle Device knob to select the second CDK111. Note If, for any reason, the CDK-111A-M card is not being used and is removed from the frame, you must access the Select Device Menu and reset the middle Device knob to NONE.
Page 283 • CDK111 V 2 • CDK111 A 2. The capital “V” stands for “video” and the “A” for alpha. The numbers indicate the CDK-111A-M card that you are feeding, with 1 being the card connected directly to the PGM and PV outputs, and 2 being the card that is cascaded from the first. If required, repeat steps 3 and 4 to assign the required Aux Buses for the other CDK-111A-M video and key outputs.
Page 284: Chroma Key Setup
Chroma Key Setup Chroma keying is a standard feature in every Synergy switcher’s keyer, including both downstream keyers. Each chroma keyer features internal 4:4:4 chroma channel interpolation — from any input. This means that no special input setup procedures are required in order to perform a chroma key — you can chroma key off of any serial digital input as required.
Page 285: Favorite Cg Setup
Favorite CG Setup This setup procedure allows you to select a “favorite” CG that you want to place on the CHAR GEN button in each MLE’s Key 2 Group. The location of the button is shown below: MLE 1 KEY 2 SELF AUTO CHROMA...
Page 286: System Timing
System Timing This section provides information regarding Synergy system timing. The following topics are discussed: • Auto-timing Technical Overview • Non-Sync LEDs • Key Timing • Reference Delay Adjustment Auto-timing Technical Overview Within the Synergy switcher, auto-timing does not occur on the input card. Instead, it occurs on the input buses that feed each individual MLE.
Page 287: Non-Sync Leds
must be delayed by (or ¼) of a line. If the Deserializer Module can only delay a video signal from zero to one line, adding this ¼ line delay to the reference reduces the auto-timing window by ¼ line. This occurs because MLE 1 does not see this delay, and a signal has to auto-time to both MLE 1 (at the start of the switcher) and a timed Aux Bus (at the end of the switcher) —...
Page 288: Key Timing
Key Timing The Synergy switcher provides no adjustments for key timing. All key timing adjustments must be made at the source. Reference Delay Adjustment The Reference Menu lists the: • MLE Delay for each MLE, • the Timed Aux Delay, •...
Page 289: Peripheral Control Setup
Four connectors are provided for future peripheral control capability, as illustrated in the figure below: Peripheral 1 Connector B INPUTS SERIES DIGITAL PRODUCTION SWITCHER PERIPHERAL 1 Peripheral 1 ROSS VIDEO LTD. MODEL Connector A ISSUE SERIAL# CAUTION: DISCONNECT POWER PERIPHERAL 2...
Page 290: Tally Connections
Tally Connections In Chapter 6, you used the Tally Setup Menu to select the tally relays that are activated when control panel buttons are pressed. In this section, using the Tally Column on your “Input Worksheet” as a guide, you will wire each tally that you have assigned. All four tally connectors are located on the rear of the control panel as shown below: REMOTE TALLY...
Page 291: Aspect Ratio
Aspect Ratio In the Output Menu, the MLE Aspect Ratio function allows you to change the aspect ratio of each MLE. Affected switcher modes include: • A circle wipe in 4:3 remains a circle in 16:9. • 3D flown keys may change shape from squares to rectangles. Use the following procedure to set the MLE output: Navigate to the MLE Aspect Ratio Menu as follows: Press HOME...
Page 292 9–62 • Additional Installation Setups Synergy Series Installation Guide (v18)
Page 293: Completing Setup
Completing Setup In This Chapter This chapter provides instructions for storing switcher configurations on a storage device, such as a floppy disk or USB key, and resetting the switcher to factory default values if required. The following topics are discussed: •...
Page 294: Disk Menu Tree
Disk Menu Tree The figure below illustrates the portion of the menu tree that is used for saving and recalling switcher setups. Use this figure for reference during the following procedures. Main Menu 1 Custom Preview Controls Disk Attributes Help Overlay Effects Disk Menu...
Page 295: About The Synergy File Storage System
About the Synergy File Storage System The Synergy file storage system arranges those portions of the switcher that are software-configurable (and user-configurable) into the following categories of registers. These registers can then be saved to a storage device such as a floppy disk or USB key. •...
Page 296: Using The Disk Menu
• VTR Clip Registers This category stores and recalls VTR clip registers (in timecode format). When saved to a storage device, the filename VTR.SYN is used. • Installation Registers This category stores and recalls all setup and configuration settings. When saved to a storage device, the filename INSTALL.SYN is used.
Page 297: Notes On Using A Usb Key
A delay can be expected when saving files to a USB key with limited memory space. • You may receive a “USB Upgrade Failed” error message when the Synergy control panel is powered on. Should you receive this error message, contact Ross Video Technical Support for instructions on how to correct the error. Storage Errors When you access a storage device, or store a configuration to a storage device, the Synergy switcher performs a validation to ensure that the contents have not been corrupted.
Page 298 Check Disk or Scan Disk from a computer to ensure there are no other problems with the storage device. Note If any of these problems persist, contact Ross Video Technical Support. 10–6 • Completing Setup...
Page 299: Saving Configurations
Saving Configurations Once all of your switcher assignments and configurations have been completed, it is strongly recommended that you save these important setups to a storage device, such as a floppy disk or USB key. Because the Synergy installation procedure covers such a wide variety of information, the pertinent data spans three categories of registers —...
Page 300 Disk Store Menu 1-2 If a File Icon appears above a softkey label (such as Custom Controls), the storage device contains a file of that type. Press MORE to display the Disk Store Menu 2-2. If you wish to save all categories of registers to a storage device, press All. This action writes the following seven files to your storage device in succession: •...
Page 301 • Press Installation to save Installation Registers to a storage device. The file INSTALL.SYN is written to the storage device. Caution Do NOT remove the floppy disk or USB key from the switcher before the LED on the floppy drive or USB port goes out. Doing so may destroy the data on your floppy disk or USB key, as well as the data on the next one you insert into the switcher.
Page 302: Recalling Configurations
Recalling Configurations As required, you can recall all categories of configuration registers from a storage device, such as a floppy disk or USB key, or you can simply recall the desired individual category. Typically, you will use this procedure in the following situations: •...
Page 303 Disk Recall Menu 1-2 If a File Icon appears above a softkey label (such as Memories), the storage device contains a file of that type. Press MORE to display the Disk Recall Menu 2-2. If you wish to recall all categories of registers from a storage device, press All. This action reads in files from the storage device in succession: •...
Page 304: Setting Up Safe Title And Center Preview Overlay
Setting Up Safe Title and Center Preview Overlay The Safe Title/ Center Preview Overlay places a SMPTE standard Safe Title and Safe Action grid, Minimum Text lines, and Center Cross-hairs on the preview screen. The default positions of the Safe Title and Safe Action Grid, Minimum Text, and the Cross-hairs are modifiable.
Page 305: Center And Safe Title Setup
• The two small Minimum Text horizontal lines indicate the minimum font size that you can choose to ensure that text is legible on nearly all sizes of television receivers. • The Center Cross-hairs indicate the vertical and horizontal center of the screen. Center and Safe Title Setup The position and size of the following elements of the overlay can be configured and saved for recall from the Safe Title Setup Menu:...
Page 306 Reposition the Center Crosshairs as follows: • Use the X knob to reposition the Center Crosshairs along the horizontal x-axis. You can also move the Positioner left and right. • Use the Y knob to reposition the Center Crosshairs along the vertical y-axis. You can also move the Positioner up and down.
Page 307 Modifying the Bottom or Right Borders Use the following procedure to modify the location of the Bottom and Right borders of the Safe Title area: Navigate to the Safe Title Setup Menu as follows: • Press HOME Preview Overlay Safe Title/Center Pos. Press Bottom/Right to display the Safe Title Setup –...
Page 308 Safe Title Setup – Safe Text Menu Reposition the Safe Text within the safe title area as follows: Use the X knob to reposition the Safe Text borders along the horizontal x-axis. You • can also move the Positioner left and right. •...
Page 309 • Use the Space, Prev Letter, Next Letter and Default softkeys to edit the name as required. • A standard PS/2 keyboard can be used to perform the same actions as pressing or rotating the System Control buttons and knobs. Refer to the section, “Using The Keyboard”...
Page 310: Restoring Factory Default Settings
Restoring Factory Default Settings This section provides instructions for resetting the switcher to factory default values. These values are preset at the factory, and cannot be overwritten by the user. Typically, once all of your switcher setups and configurations have been completed and successfully saved to a storage device, such as a floppy disk or USB key, you will not need to perform this procedure.
Page 311 • Switcher Registers This set of registers stores default settings for the control panel, similar to those discussed in the section “Resetting the System” on page 3–12. When reset, the control panel (and all associated crosspoints, keyers, and MLE settings) is essentially cleared to zero.
Page 312: Recall Factory Menu Tree
Recall Factory Menu Tree The figure below illustrates the portion of the menu tree that is used for recalling factory default settings. Use this figure for reference during the following procedure. Main Menu 1 Main Menu 2 MORE Custom Preview Clips Aux Bus Logo...
Page 313 Warning — Reset Personality Settings • Press Yes to reset all Personality Settings to their default values. • Press No to retain the current set of Personality Settings and exit the menu safely. Use the following method to Reset your Memory Registers: •...
Page 314 Warning — Reset Installation Registers • Press Yes to reset all Installation Registers to their default values. • Press No to retain the current set of Installation Registers and exit the menu safely. Use the following method to Reset your Custom Control Registers: •...
Page 315 Warning — Reset NV-RAM • Press Yes to reset the contents of the NV-RAM. • Press No to retain the current NV-RAM and exit the menu safely. 12. Use the following method to Reset all the S&T 3D Card memories and sequences: •...
Page 316: When Configuration Is Complete
When Configuration is Complete Once the entire switcher configuration process is complete, please heed the following important note: Important Place the Installation Enable Jumper (JP10) on the front edge of the Frame CPU Board in the Up position. This position restricts access to installation settings as follows: •...
Page 317: Still Stores
Before you begin, ensure that the Still Store (Aprisa) Interface option is installed. If not, contact Ross Video for details. Refer to the section “Installed Options Menus” on page 2–37 for instructions on verifying the status of installed options.
Page 318: Supported Still Stores
Supported Still Stores The Synergy switcher has been tested with a number of Still Stores to ensure the highest standard for compatibility and reliability. The following Still Stores are currently supported by your Synergy switcher: • Chyron Aprisa 100 Stillstore 11–2 •...
Page 319: Communications Connections
In order to properly complete this procedure you will need the following software options, cables, and equipment: • Still Store (Aprisa) Interface — This is the software option from Ross Video that allows your Synergy switcher to control a Still Store. •...
Page 320: Still Store Interface Cable Pinouts
Still Store Interface Cable Pinouts Use the information in this section to connect the Interface Cable from the Synergy switcher to the Still Store. Chyron Aprisa 100 Still Store Cabling The Synergy control panel connects to an Aprisa 100 Still Store via the remote ports on the Synergy control panel, and the RS-422 port or the RS-232 port on the rear of the Aprisa 100 Still Store.
Page 321: Communications Setup
Communications Setup This section will provide instructions for setting up the Still Store to communicate with the Synergy switcher. The following topics are discussed in this section: • Setting up the Switcher • Setting up the Still Store Setting up the Switcher In order to have the Synergy switcher communicate with a Still Store, the remote port on the control panel that the Still Store is connected to must be set up to communicate with the particular Still Store you have connected.
Page 322 Assign a specific Still Store to the remote port as follows: • Use the Com Port knob to select the remote port that the desired Still Store is connected to. • Use the Device knob to select the type of Still Store that is connected to the port. You can select between the following: NONE —...
Page 323: Setting Up The Still Store
Select the type of serial communication that will be used to communicate with the Still Store as follows: Use the Com Port knob to select the Still Store you want to set the communication • type for. • Use the Type knob to select the type of serial communications (RS-232, RS-422) for the selected port.
Page 324: Setting Up Still Store Bncs
Setting up Still Store BNCs The Still Setup Menu allows you to associate a Still Store BNC input with a particular Still Store communication port. In addition, you can select which channel on the Still Store is feeding the input BNC on the Synergy SD frame.
Page 325 • Use the BNC knob to select the BNC you want to assign the specific Still Store to. Operating Pressing the associated BNC crosspoint button lights the VTR CLIP button in the Global Memory System, and allows you to recall a specific still using the numeric keypad.
Page 326 11–10 • Still Stores Synergy Series Installation Guide (v18)
Page 327: Editors/Overdrive
Production Control System with your Synergy switcher. Before you begin, ensure that the Editor Interface option is installed. If not, contact Ross Video for details. Refer to the section “Installed Options Menus” on page 2–37 for instructions on verifying the status of installed options.
Page 328: Supported Editors
Supported Editors The Synergy Series Switcher has been tested with a number of Editor Protocols to ensure the highest standard for compatibility and reliability. The following Editor Protocols are currently supported by your Synergy switcher: • Thomson Grass Valley GVG4000 Protocol •...
Page 329: Editor Communications Connections
In order to properly complete this procedure you will need the following software options, cables, and equipment: • Editor Interface — This is the software option from Ross Video that allows your Synergy switcher to control a Editor. • Interface Cable — This is a 9-Pin cable with a 9-Pin, D-Type (DB9) male connector on one end, to connect to the editor port on the frame, and a connector on the other end to connect to your Editor.
Page 330 The Editor Port on the Synergy switcher Frame has the following pinouts: Synergy 422 Wiring Chart Synergy Control Panel Editor Port Signal TxA (Tx–) RxB (Rx+) Ground Ground TxB (Tx+) RxA (Rx–) This completes the procedure for connecting an Editor to the Synergy switcher. Refer to the section “Editor Communications Setup”...
Page 331: Overdrive Communications Connections
In order to properly complete this procedure you need the following software options, cables, and equipment: • Editor Interface — This is the software option from Ross Video that allows your Synergy switcher to control an Editor. • Control Panel Interface Cable — A 33ft RS-422 cable (Ross Part Numbers 4000C-301 or 4000CR-312) with a 9-Pin, D-Type connector on one end and a Telco RJ-12 connector on the other.
Page 332 Synergy Rack Frame INPUTS SERIES DIGITAL PRODUCTION SWITCHER ROSS VIDEO LTD. MODEL ISSUE SERIAL# Synergy Control Panel CAUTION: DISCONNECT POWER BEFORE SERVICING DVE 1 ATTENTION: COUPER LE COURANT AVANT L'ENTRETIEN DVE 2 AC POWER RATING: PRIMARY 85 - 250 V...
Page 333: Editor Communications Setup
Editor Communications Setup This section will provide instructions for setting up the Editor to communicate with the Synergy switcher. Refer to the section “OverDrive Communications Connections” on page 12–5 for information on setting up communications between an OverDrive Standard System and a Synergy switcher.
Page 334 • Use the Device knob to select the Editor Protocol used by the selected device. You can select from the following: NONE — Select this option when you are not connecting an Editor to the selected port. GVG4000 — Select this option when you are connecting an Editor using the Thomson Grass Valley GVG4000 Editor protocol.
Page 335 10. Press Extra Options to display the Extra Options Menu. • The GVG100 Editor Protocol has additional Extra Options that may need to be set, depending on the configuration you have. Refer to the section “GVG100 Editor Protocol Extra Options” on page 12–9 for more information. 11.
Page 336 Communications — GVG 100 (Editor Type) Extra Options Menu • Use the Com Port knob to select the Editor port that the Editor using the GVG100 Editor Protocol is connected to. • Use the Option knob to select Editor Type. •...
Page 337: Overdrive Communications Setup
OverDrive Communications Setup The OverDrive Production Control System is a highly flexible production control system that enables touch screen control over your Synergy switcher. For detailed instructions on connecting the OverDrive Production Control System to your Synergy switcher, refer to the OverDrive documentation.
Page 338 Communications — Editor Protocol Menu Assign the OverDrive Editor to the Editor Port as follows: • Use the Com Port knob to select EDITOR (ED). • Use the Device knob to select OverDrive. Press Com Settings to display the Com Settings Menu. Communications —...
Page 339: Setting Up The Aux 1 Port For Overdrive
Setting up the Aux 1 Port for OverDrive Use the following procedure to configure the Synergy Control Panel to communicate with an OverDrive Production Control System: Note Refer to your OverDrive documentation for information on how to set up the communications protocols on the OverDrive Production Control System.
Page 340 Communications — Com Settings Menu Set the communications parameters for the Remote Aux 1 port as follows: • Use the Com Port knob to select Automatn (A1). • Use the Baud knob to select 38400. • Use the Parity knob to select ODD. Press Com Type to display the Com Type Menu.
Page 341: Overdrive Custom Controls
OverDrive Custom Controls The OverDrive Production Control System can use certain custom controls, or types of custom controls, to perform operations on the Synergy switcher. Using these custom controls, the OverDrive Production Control System can have the Synergy switcher perform a transition of all on-air MLEs, or transition all Keys off-air.
Page 342 Insert Special — Special Menu Assign an automation function to the selected custom control macro as follows: • Use the top knob to select Automation. • Use the Command knob to select the command you want the macro to perform. You can select between the follow: Keys Off Air —...
Page 343: Relative Custom Controls
Relative Custom Controls Important Relative Custom Controls can only be properly recorded and recalled on upper MLEs that are re-entered onto the PGM/PST MLE. If the MLE is not re-entered, you will not be able to properly record or recall a relative custom control.
Page 344: Editor And Overdrive Operation
Editor and OverDrive Operation The Editor Interface button in the Global Memory System Group allows the Synergy switcher to be controlled by a remote editing system, using a GVG Editor Protocol, or the OverDrive Production Control System. Toggle the EDITOR button ON, lit, to enable control of the Synergy switcher from the editor or OverDrive system.
Page 345 • If a Key is flown in the memory recall on MLE 2, an S&T Wipe cannot be used to transition the memory on-air. This limitation applies whether the Key is on-air or not. • You will not be able to preview a transition on MLE 2 as you can on MLE 1. •...
Page 346 12–20 • Editors/OverDrive Synergy Series Installation Guide (v18)
Page 347: External Dves
External DVEs In This Chapter This chapter provides instructions for interfacing a generic Digital Video Effects system (DVE) with a Synergy switcher, and covers a variety of aspects such as technical requirements, connections, and programming. The following topics are discussed: •...
Page 348: Supported External Dves
Supported External DVEs The Synergy Series Switcher has been tested with a number of external DVEs to ensure the highest standard for compatibility and reliability. The following external DVEs are currently supported by your Synergy switcher: Note The Synergy switcher will support any external DVE that uses the Generic Sony Betacam Protocol.
Page 349: Primary And Secondary Dves
Primary and Secondary DVEs There are two types of external DVEs that can be connected to a Synergy switcher: • Primary External DVE Only one primary external DVE (either single or multi-channel) can be connected to a Synergy switcher at a time. The connection includes: Video and Key signal routed from the Aux Bus outputs of the Synergy switcher to the external DVE.
Page 350: Connection Diagrams
Connection Diagrams The diagrams in this section illustrate the typical connections used to interface the Synergy switcher with a primary and secondary external DVE. Use these figures for reference (for the appropriate DVE) during the interface procedures in this chapter. Refer to the documentation for your DVE or to the section “DVE Interface Specifications”...
Page 351 Secondary External DVE Connections The diagram “Secondary External DVE Interface Connections” on page 13–5 illustrates typical secondary external DVE interface connections: Synergy Switcher Secondary DVE Required Aux __ Out Video In Channel 1 Use any Required Aux __ Out Alpha In Channel 1 Optional * Aux __ Out Video In Channel 2...
Page 352: Communication Connections
Communication Connections You can connect only one primary external DVE to a Synergy switcher but as many secondary external DVEs as desired; the only limit is the number of Aux Buses available to route signals. The procedure for connecting external DVEs will depend on the type of DVE you have (single or multi-channel) and how many external DVEs you wish to connect to the Synergy switcher.
Page 353 Primary External DVE Input Connection Any Aux Bus outputs can be used for connecting the video and key channels of your primary external DVE. If you have not already done so, complete the Auxiliary Output Worksheet, which can be found in Chapter 4, “Preliminary Video Installation” in the Synergy Series Installation Guide Volume I.
Page 354: Dve Output Connections
Dual-channel Secondary External DVE This configuration routes two fill sources and two alpha (Key) sources to the primary external DVE. Image manipulation must be performed at the local control panel of the DVE. Effects can be triggered at the local control panel of the DVE, or from a GPI pulse (from the Synergy switcher). Use the following procedure to connect a dual-channel secondary external DVE: Connect an available switcher Aux Bus output to the Channel 1 video input on the secondary external DVE.
Page 355: Aux Bus Panel Programming
Follow all procedures outlined in the section “Communications Setup” on page 13-11. For each external DVE video and alpha input, these procedures allow you to perform the following tasks: • Name the BNC input • Set up the BNC type (DVE video or alpha) •...
Page 356: Gpi Output Connections
MLE for Keying. The mode also allows you to recall DVE effects from the switcher panel. Use the figure below for reference in the following procedures: INPUTS SERIES DIGITAL PRODUCTION SWITCHER DVE 1 DVE 1 ROSS VIDEO LTD. MODEL ISSUE Port SERIAL# DVE 2 CAUTION:...
Page 357: Communications Setup
Communications Setup The DVE Communications Setup procedures allow you to set up communications parameters with your primary external DVE. Once the procedures are completed, the “DVE Send” feature is operational, and custom control buttons can also be programmed to perform specific tasks such as Play, Stop, Go To Start, and Go To End.
Page 358: Setting Up Auto Keys
Use the following procedure to set your input types for your primary external DVE: Navigate to the BNC Menu 1-3 as follows: • Press HOME MORE Setup Installation BNC. Press BNC Type to display the BNC Type Menu. BNC — BNC Type Menu Assign a BNC input to an external DVE as follows: •...
Page 359: Setting Up Aux Bus Tallies
Use the following procedure to set up an Auto Key: Navigate to the BNC Menu 1-3 as follows: • Press HOME MORE Setup Installation BNC. Press Auto Key Setup to display the Auto Key Setup Menu. BNC — Auto Key Setup Menu Assign an alpha BNC to a BNC input as follows: •...
Page 360 Aux Bus – External Device Assignment Menu Assign the method by which the Aux Bus is tallied as follows: • Use the Aux Bus knob to select the Aux Bus whose output is physically connected to the input of the external DVE. •...
Page 361: Setting Up Clean Feed Output
Use the following procedure to set up communications with your primary external DVE: Ensure that the DVE Send and Remote Control Option is installed. If not, please contact Ross Video for details. Refer to the section “Installed Options Menus” on page 2-37 for instructions on verifying the status of installed options.
Page 362 Ensure that serial cable(s) are connected between the proper Synergy switcher port(s) and the primary external DVE. Refer to the section “Remote Control Connections” on page 13-10 for details. Navigate to the Communications Menu 1-2 as follows: • Press HOME MORE Setup Installation...
Page 363 Select DVE Protocol Menu Assign a specific DVE protocol to the DVE communications port as follows: • Use the Com Port knob to select the port that the primary external DVE is connected to. Use the Device knob to select the specific external DVE that is connected to the •...
Page 364 DVE Com Settings Menu Set the baud rate and parity as follows: • Use the Com Port knob to select the port that the primary external DVE is connected to. Use the Baud knob to select the baud rate for the primary external DVE. •...
Page 365: Setting Up Dve Send
Extra Options Setup The Extra Options Menu for an external DVE allows you to complete the communications setup for some of the external DVEs on the Synergy switcher. Grass Valley DPM-100 Protocol The Extra Options Menu for external DVEs using the Grass Valley DPM-100 Protocol allows you to specify the GVG Model that you are setting up.
Page 366 Personality Menu 3-4 Toggle the DVESend Bttn feature as follows: • Int — Select this option to use the DVE Send button for internal Squeeze & Tease wipes. • Ext — Select this option to use the DVE Send button for external DVE functions. This completes the procedure for setting to set the functionality of the DVE Send button to External.
Page 367: Dve Interface Specifications
DVE Interface Specifications This section provides interface and technical information for specific DVEs with which the Synergy switcher interfaces. Pinnacle DVEXtreme This section provides information that pertains to interfacing the Pinnacle DVEXtreme to the Synergy switcher — as the primary DVE. Once the interface is set up, you can perform a variety of DVEXtreme-specific functions directly from the Synergy control panel —...
Page 368 RS422-A DIGITAL I/O DIGITAL I/O DIGITAL I/O Connector OUTPUT OUTPUT OUTPUT VIDEO VIDEO VIDEO INPUT INPUT INPUT A / VIDEO B / KEY A / VIDEO B / KEY A / VIDEO B / KEY DVEXtreme DVE — Rear Panel Locate the connector marked DVE 1on the Synergy frame.
Page 369 DVEXtreme Remote Control Setup On the DVEXtreme, the Remote Control Menu controls the way the DVEXtreme operates when connected to an external device. Press Shift + Remote to display the Remote Control Menu. Default values are shown below: DVEXtreme — Remote Control Menu The following remote control settings must be utilized for proper operation with the Synergy switcher: •...
Page 370 In Chapter 5 of the DVEXtreme User’s Guide, refer to the “Remote Control” section for additional information on the “Vision Mixer Control” and “Relative Positioning” flags. GPI Output Connection (for Synergy Tally Mode) The Synergy Aux Bus Assignment function allows you to set up certain methods for tallying an Aux Bus, and lighting the red “ON”...
Page 371 Use the following procedure to connect GPI output lines: Using the pinout data from the table on the previous page, construct a cable that connects the desired GPI input ports (on the Synergy switcher) to the desired GPI output lines on DVEXtreme. Note For the Synergy side of the connection, refer to the section “Standard GPI I/O Connector Pinouts”.
Page 372: Accom (Abekas) Dveous
Pause CTRL DVEXtreme Control Panel — GPI Out Number Dialog Enter the number of the GPI output port that you wish to use, and press ENTER. Note Remember that two GPI output ports are available per DVEXtreme channel. Thus, on a single channel system, GPI output port numbers 1 and 2 are valid.
Page 373 In addition, once communication is properly set up with the Dveous, the “DVE Send” feature is operational. This feature allows you to perform fast and simple DVE transitions from the switcher panel — as easy as selecting a Dissolve or a Wipe. When you set up a DVE Send transition, you are electronically routing a specific set of signals from the selected MLE to the Dveous for processing —...
Page 374 Using the custom cable, connect the Editor connector on the Dveous DVE to the DVE 2 connector on the Synergy frame. This completes the procedure to connect the Synergy switcher to the Accom Dveous DVE. Dveous Setup Specifics This section provides information regarding specific Dveous setups. The following topics are discussed: •...
Page 375 If front-back signals are not needed, setting the Dveous to Tally mode will set the GPI outputs to tally (low active) for the 12 possible inputs on the Dveous frame (for example, GPI output 1 tallies low when input 1 to the Dveous is included in the output video). This “active” source tallying is the recommended mode for connection to Synergy where possible.
Page 376: Questech Charisma Vtl
Questech Charisma VTL This section provides information that pertains to interfacing the Questech Charisma VTL to the Synergy switcher — as the primary external DVE. Once the interface is set up, you can perform a variety of Charisma-specific functions directly from the Synergy control panel — via RS-422 serial control.
Page 377 Charisma VTL DVE — Rear Panel Locate the connector marked DVE 1 on the Synergy frame. Construct an RS-422 Null Modem cable using the following table as a guide. The cable must use standard male 9-pin “D” subminiature connectors at both ends. Synergy Frame to Questech Charisma VTL Wiring Synergy Control Panel Questech Charisma VTL...
Page 378: Grass Valley Dpm-700
Press the Editor Setup soft key. Using the first “modify” soft key below the screen, select SSVR protocol. Using the third “modify” soft key, select the Mainframe device. Press the SYSTEM button to return to the timeline display. This completes the procedure to set the Editor protocol to SSVR on the Charisma DVE. Next, the effect must be set up to enable key transitions to do a proper key transition with the Charisma.
Page 379 In addition, once communication is properly set up with the GVG DPM-700, the “DVE Send” feature is operational. This feature allows you to perform fast and simple DVE transitions from the switcher panel — as easy as selecting a Dissolve or a Wipe. When you set up a DVE Send transition, you are electronically routing a specific set of signals from the selected MLE to the GVG DPM-700 for processing —...
Page 380 Use the following procedure to reset the port on your GVG DPM-700: Insert the Diagnostic Software Disk into the DPM-700 drive. Power down the DPM-700. Power up the DPM-700 The DPM 700 STREAMLINE™ display will read DPM-700 System Diagnostics. Reset the port as outlined in your GVG DPM-700 documentation. This concludes the procedure to reset the port on your GVG DPM-700.
Page 381: Dve Betacam Protocol Specifics
The Decode NAKs option is enabled by default. The settings should only be modified if you encounter problems using the Play commands with your DVE device or as advised by Ross Video Technical Support. Use the following procedure to set up the Decode NAKs option: Navigate to the Communications Menu 1-2 as follows: •...
Page 382 Communications — Extra Options (Decode NAKs) Menu • Use the Value knob to select Yes or No as follows: Yes — Select this option to enable the Decode NAKs option. This is the default setting. No — Select this option to disable the Decode NAKs option. Set the number of fields the switcher will wait before assuming the last Play command failed or was not received as follows: •...
Page 383: External Dve Custom Controls
External DVE Custom Controls Once your primary external DVE has been connected, and once communication has been established, you can program one or more custom control buttons to perform specific DVE-related functions. These custom control functions are provided in addition to the DVE Send mode of the Synergy switcher, and the ability to recall DVE effects in the Pattern Control Group (in “shot box”...
Page 384 Navigate to the Insert DVE Menu as follows: • Press Start Recording Insert Special DVE. This menu allows you to choose specific DVE control functions to assign to the button. Insert DVE Menu Note If an error message is displayed stating that there are no communications ports assigned to DVE, ensure that the DVE you are trying to control has been properly set up on the Synergy DVE port.
Page 385: Special Functions
Operating DVE functions can be strung together (during the programming mode), allowing one custom control button to perform multiple functions when it is pressed. For example, you can have the Recall Effect 24 function followed by the Play function, allowing a single custom control macro to recall an effect and then run it.
Page 386 Custom Controls Menu Select the custom control button you want to record to as follows: • Use the Bank knob to select the custom control bank you want to record the custom control to. • Use the Button knob to select the custom control button that you want to record a custom control macro to.
Page 387 Press Finish Recording, or the flashing custom control button, to finish recording to the selected custom control. The custom control button will stop flashing. This completest the procedure to program a GPI reset custom control macro for your external DVE. Refer to the section “Naming Custom Controls”...
Page 388: Installing The Inserts
Assign the trigger GPI to a GPI output as follows: • Use the Selection knob to select Trigger GPI. Use the GPI Output knob to select the GPI output port you want to trigger. • Note The names that appear in the GPI Output list are programmed on the GPI Output Setup Menu.
Page 389: Completing The Dve Custom Control Worksheet
Completing the DVE Custom Control Worksheet When completing the DVE Custom Control Worksheet, remember that DVE functions can be strung together — on the same button and the numbering scheme is in ascending order, from left to right. Use the following procedure to complete your Custom Control Worksheet: Ensure you have programmed and named your DVE custom control buttons as outlined the section “DVE Functions”...
Page 390 DVE Custom Control Worksheet Custom Control Bank Name/ Number:_____________________________________ Custom Control Button Name DVE Custom Control Function(s) 13–44 • External DVEs Synergy Series Installation Guide (v18)
Page 391: Glossary Of Terms Gl
Glossary of Terms Active Video Lines — All video lines not occurring in the vertical blanking interval. The portion of the video signal that contains picture information. Aspect Ratio — The numerical ratio of picture width to height, for example, 4:3 or 16:9. Auto Transition —...
Page 392 Field Frequency — The rate at which one complete field is scanned, approximately 50 times per second in 625 video, or 60 times per second in 525 video. Frame — One complete picture consisting of two fields of interlaced scanning lines. GPI —...
Page 393 MIX — See Dissolve. MLE — An abbreviation for multi-level effects. PGM Output — The on-air video output of the system. Primary Input — Video sources selected by the control panel push-buttons for the crosspoint buses. These buses are normally labeled “KEY”, “PGM”, and “PST”. PV Output —...
Page 394 GL–4 • Glossary of Terms Synergy Series Installation Guide (v18)
Page 395: Index
Index setup menu............6-13 shaped............. 6-14 signal connection..........4-2 unshaped............6-13 Ancillary data menu ..........9-18 Animated Logo Generator See ALG Arm mode, ROLL VTR ....1-21 1-23 8-31 Numerics Aspect ratio in Outputs menu ..........9-61 1+0 DVE ..............1-6 MLE setup ............
Page 396 DVE outputs ......... 4-13 13-7 DVE panel programming........ 13-9 Backup system............2-33 external device assign ......9-11 13-13 Banks, custom control ........8-5 follow mode ............9-6 Basic troubleshooting ........... 3-16 GPI Tally Assign......... 9-11 13-14 Baud rate, PIP-II port ......... 7-11 7-14 local panel............
Page 397 ............9-17 13-15 Carrier board, input ......1-16 2-10 2-11 aspectized ............1-13 Catalog, Ross Video ..........1-16 aux panel programming mode......9-38 before keys ............. 9-17 joystick control menu ......9-39 9-40 between keys ..........9-17 joystick control, monitor GPI functions ..9-41 feature.............
Page 398 Com port standard GPIs..........9-33 DVE .............. 13-16 Connector editor ............... 12-7 AUX 1, 2, 3............2-6 Com port, CDK-111A-M......7-19 9-51 AUX 11, 12............. 2-13 Communications Aux outputs............. 2-13 CDK-111A-M setup........7-19 control panel ........... 2-15 Contribution Serial Tally Protocol setup ..7-13 DVE 1 .............
Page 399 jumper JP12, redundant power....... 2-28 Digicart clips ............ 8-5 jumper JP5, type ..........2-27 DVE functions..........8-6 jumper JP6, type ..........2-27 Editing .............8-6 8-47 jumpers ............2-27 Editing macros..........8-47 mounting screws..........2-19 finish recording ......8-15 8-18 8-40 standard features..........
Page 400 saving and recalling functions ......8-6 Digital reference connection ........ 13-6 Select Bank macro .......... 8-14 DIP Switch 1, frame configuration....... 2-29 Server functions ..........8-5 DIP Switch 2, Power Supply........ 2-29 Disk special functions ..........8-6 errors............... 10-5 STOP button ........... 8-13 menu ......
Page 401 external, communications setup ..... 9-51 program custom control functions....13-37 Dual Border Generator protocol............13-16 board............... 2-40 reference connection ........13-6 feature description .......... 1-19 remote control connections ......13-10 secondary..........1-6 13-3 1+0..............1-6 secondary connection ........13-7 1+1..............1-6 send..13-10 13-11 13-21...
Page 402 Editor Protocol auto key setup ..........13-12 GVG100..........12-8 12-9 aux bus panel programming ......13-9 GVG200............12-8 aux bus tallies setup ........13-13 GVG4000............12-8 Betacam protocol specifics ......13-35 OverDrive ............. 12-11 BNC setup............. 13-11 Editors ..............12-1 clean feed setup ..........
Page 403 pers.syn............10-3 I/O..............2-15 storage on disk..........10-3 icons ............9-39 9-42 vtr.syn ............. 10-4 information menu ........... 9-32 File System Timeout error, storage device... 10-6 input polarity menu ..... 9-26 9-27 9-29 Fly key..............1-19 input worksheet, standard....... 9-22 Follow mode, Aux Panel......9-13 9-14 inputs ..............
Page 404 interface ............13-32 VTR ..............6-10 GVG100 worksheet..........4-2 Extra Options ..........12-9 Input Carrier Board, installation......2-40 Extra Options, Editor Type ......12-9 Insert Extra Options, Pattern........12-10 device functions, custom controls ....8-14 Events in a custom control......8-50 hold, custom control ........
Page 405 remote Aux panel cables ........3-4 JP10, control panel ......... 2-28 remote Aux panels.......... 2-21 JP10, frame, installation ......2-29 10-24 reset registers..........10-21 JP11, control panel ......... 2-28 serial numbers .........2-3 2-37 JP11, frame, software upgrade ....... 2-30 Synergy control panel overview....... 2-4 JP11, software upgrade......2-34 2-35 Synergy frame overview ........
Page 406 SECONDARY FAIL ........2-9 DSK auto key setup ........9-47 Level trigger, GPI ..........9-31 DSK chroma key setup ........9-47 Local panel ............. 9-3 DSK self key setup ......... 9-47 LOCK MENU ............5-5 DSK setup............9-48 Lock/Unlock DSK crosspoints ......9-49 DSK Squeeze &...
Page 407 scroll area ............5-4 More Info Menu ............. 5-7 select DVE protocol ........13-16 select editor protocol ........12-7 setup, DVEXtreme ......13-24 13-25 N/S ............... 9-57 setup, exiting ..........6-19 N/S Disable software options ..........2-37 All Off ............6-19 standard GPI setup .........
Page 408 conversion frames........... 1-15 worksheet, special........... 4-13 custom main panel cable......... 1-25 OverDrive............. 12-1 Dual Aspectizer ..........1-17 cabling ............12-5 dual border generator........1-19 Communication Setup ........12-11 DVE Send and remote control...... 13-15 custom controls (automation) ....... 12-15 DVE send and remote control ......1-23 installation ............
Page 409 Preview connector ............2-12 MLE ............... 1-10 definition ............1-7 overlay ........... 1-9 1-16 2-13 PGM/Key Shift overlay delay ..........9-58 assigning............6-16 overlay option........... 8-6 using ............... 6-16 Preview Overlay Menu Tree ......10-12 PGM/Key Shift crosspoint buses ......6-17 Preview Tally ............
