Labels

RETRACTABLE
All PFAS equipment must be selected and deemed compatible by Competent Person.
All installation, set-up, and use of this HLL must be done under supervision of Qualified Person.
Always avoid all hazards, including, but not limited to, chemicals, corrosive substances,
excessive heat, electric shock, and sharp and abrasive edges and surfaces.
Refer to instructions for compatible connections, installation
procedure, and fall clearance requirements.
CLEARANCE
SPAN/DEFLECTION
Deflection =
Tension lifeline until 6" of sag exists, measured at midpoint of span.
Always consider lifeline deflection in fall clearance calculations.
Maximum potential lifeline deflection increases with length of span.
Product lifetime is indefinite, as long as product passes all inspection requirements and
7
HLL
H O R I Z O N T A L L I F E L I N E
OSHA 1926 Subpart M
OSHA 1910.140
60' RETRACTABLE
HORIZONTAL LIFELINE
D.O.M: MM/YY Serial #:
Prior to use, read and understand all manufacturer's instructions
provided with equipment at time of shipment.
10' 20' 30' 40' 50' 60'
Span =
4.3' 5.6' 6.6' 7.4' 8.1' 9.1'
conforms with the latest OSHA standard revision.
User must inspect prior to EACH use.
Competent Person must complete formal
inspection every 12 months. Competent Person
to inspect and initial. If equipment fails inspection
IMMEDIATELY REMOVE FROM SERVICE
guardianfall.com
PATENT PENDING
00-SAMPLE Lot #: 0000X000000000
Specifications:
Maximum HLL length: 60'
Worker Capacity Range (including all equipment): 130-310 lbs
Maximum 2 workers per HLL.
Materials:
Aluminum, stainless steel, zinc-plated steel and galvanized steel.
INSPECTED BY:
Date:
DO NOT REMOVE LABELS
.
Assembled in USA
A D VA N C I N G
90871 (Rev. E)
F A L L P R O T E C T I O N
Part #: 04660
Initials:
Date of First Use:
85336 (Rev. D)
