English
Labels
1
HLL
HLL
W E B H O R I Z O N T A L L I F E L I N E
W E B H O R I Z O N T A L L I F E L I N E
Meets and exceeds requirements of
Meets and exceeds requirements of
EN 795:2012 Types B & C
EN 795:2012 Types B & C
PD CEN/TS 16415:2013 Types B & C - 2 Users
PD CEN/TS 16415:2013 Types B & C - 2 Users
RfU 11.096
70mm x 55mm
70mm x 55mm
= Cut Lines
Guardian
HLL WEB Horizontal LifeLine
Meets and exceeds requirements of
1
EN 795:2012 Types B & C
PD CEN/TS 16415:2013 Types B & C - 2 Users
RfU 11.096
Structure must withstand minimum force of 20 kN for one user, 22 kN for two users.
Anchorage connectors must withstand minimum force of 19.4 kN.
Always avoid all hazards, including, but not limited to, chemicals, corrosive substances, excessive heat,
electric shock, and sharp and abrasive edges and surfaces. Product lifetime is indefinite, as long as
product passes all inspection requirements. User must inspect prior to EACH use. Competent Person
must complete formal inspection every 12 months. Competent Person to inspect and initial.
If equipment fails inspection IMMEDIATELY REMOVE FROM SERVICE.
2
Materials: Polyester, galvanised steel, and zinc-plated steel.
DO NOT REMOVE LABELS
CE 0598 UKCA
Assembled in UK by by Checkmate Lifting & Safety Ltd T/A Guardian Fall, New Road, Sheerness, Kent,
ME12 1PZ United Kingdom
TENSION INDICATOR
RfU 11.096
= Cut Lines
2
Structure must withstand minimum
Structure must withstand minimum
force of 20 kN for one user, 22 kN for
force of 20 kN for one user, 22 kN for
two users.
two users.
Anchorage connectors must withstand
Anchorage connectors must withstand
minimum force of 19.4 kN.
minimum force of 19.4 kN.
Always avoid all hazards, including, but not
Always avoid all hazards, including, but not
limited to, chemicals, corrosive substances,
limited to, chemicals, corrosive substances,
excessive heat, electric shock, and sharp
excessive heat, electric shock, and sharp
and abrasive edges and surfaces. Product
and abrasive edges and surfaces. Product
lifetime is indefinite, as long as product
lifetime is indefinite, as long as product
passes all inspection requirements. User
passes all inspection requirements. User
must inspect prior to EACH use. Competent
must inspect prior to EACH use. Competent
Person must complete formal inspection
Person must complete formal inspection
every 12 months. Competent Person to
every 12 months. Competent Person to
inspect and initial.
inspect and initial.
If equipment fails inspection
If equipment fails inspection
IMMEDIATELY REMOVE FROM SERVICE.
IMMEDIATELY REMOVE FROM SERVICE.
Materials: Polyester, galvanised
Materials: Polyester, galvanised
steel, and zinc-plated steel.
steel, and zinc-plated steel.
DO NOT REMOVE LABELS
DO NOT REMOVE LABELS
Assembled in UK
Assembled in UK
by Checkmate Lifting & Safety Ltd
by Checkmate Lifting & Safety Ltd
/
Guardian Fall, New Road,
T
A
/
Guardian Fall, New Road,
T
Sheerness, Kent, ME12 1PZ
A
Sheerness, Kent, ME12 1PZ
United Kingdom
United Kingdom
TENSION
TENSION
INDICATOR
INDICATOR
100mm x 57mm
100mm x 57mm
Engraved on Tensioner Housing:
SERIAL NUMBER:
D.O.M:
MAX NO. OF USERS:
MAX USER WEIGHT:
PART NUMBER:
SYSTEM LENGTH:
8
0598
0598
INSPECTED BY:
INSPECTED BY:
Date:
Initials:
Date:
Initials:
Date of First Use:
Date of First Use:
guardianfall.com
guardianfall.com
