hepco & becker 506998 00 01 Quick Start Manual

Advertisement

Quick Links

MagnetSystem
HONDA CMX 500 Rebel
ab Baujahr 2017 / from date of manufacture 2017
Artikel Nr.: / Item-no.:
998
506
00 01
schwarz/black
INHALT
CONTENTS
1
Montageset mit Tankring
2
Abdeckung Magnetdome
1
Linsenschraube M4x35
2
Senkkopfschraube M4x30
3
Aludistanz ø7,5 x ø4,5 x 5,5 mm
1
Gummipuffer
1
Klebepad rund
Dieses Tankring-Kit ist speziell für die HONDA CMX 500 Rebel
Nur für die Verwendung von Tankrucksack Royster und Daypack geeignet!
This tank ring kit is specially for HONDA CMX 500 Rebel
Only suitable for use with tank bag Royster and Daypack !
Wenn Sie sich nicht sicher sind, wie man eine bestimmte Arbeit ausführt, sollten Sie diese Ihrer Fachwerkstatt überlassen.
Ziehen sie alle zugänglichen Schrauben zuerst nur locker an. Nachdem alles montiert ist, werden die Schrauben dann
auf das entsprechende Anzugsmoment festgezogen. Dadurch wird sichergestellt, dass das Produkt spannungsfrei
angebaut ist. Anzugsmomente beachten! Nach der Montage alle Verschraubungen auf festen Sitz kontrollieren!
If you are not sure how to execute a determined action, you should ask your local distributor to do it. First, tighten all
screws only loosely. After mounting all parts, the screws should be tightened to the torque specified. This guarantees,
that the product is mounted without tension. Observe the tightening torques of the manufacturer! Control all screw
connections after the assembling for tightness!
Weiteres Zubehör auf unsere Homepage. More accessories: see our homepage.
Hepco & Becker GmbH
An der Steinmauer 6
D-66955 Pirmasens
Germany
1

Mounting set with tank ring

2

Cover magnetic dome

1

Filister head screw M4x35

2

Countersunk screws M4x30

3
spacer ø7,5 x ø4,5 x 5,5 mm
1

Rubber buffer

1

Round adhesive pad

Tel.:
+49 (0)6331 - 1453 - 100
Fax:
+49 (0)6331 - 1453 - 120
eMail: vertrieb@hepco-becker.de
www.hepco-becker.de
Daypack
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 506998 00 01 and is the answer not in the manual?

Questions and answers

Summary of Contents for hepco & becker 506998 00 01

  • Page 1 MagnetSystem HONDA CMX 500 Rebel ab Baujahr 2017 / from date of manufacture 2017 Artikel Nr.: / Item-no.: 00 01 schwarz/black INHALT CONTENTS Montageset mit Tankring Mounting set with tank ring Abdeckung Magnetdome Cover magnetic dome Linsenschraube M4x35 Filister head screw M4x35 Senkkopfschraube M4x30 Countersunk screws M4x30 Aludistanz ø7,5 x ø4,5 x 5,5 mm...
  • Page 2 MagnetSystem HONDA CMX 500 Rebel ab Baujahr 2017 / from date of manufacture 2017 Artikel Nr.: / Item-no.: 00 01 schwarz/black BENÖTIGTE WERKZEUGE TOOLS REQUIRED Ratsche/Ratchet Verlängerung/extension VORBEREITUNG PREPARING Den Zapfen an dem beiliegenden Gummistopfen mit geeignetem Werkzeug entfernen. Den Gummistopfen mit dem Klebepad an die Unterseite des Tankrings fest ankleben.
