Tip

Playing an iPod

 The Reaction indicator flashes three times
when the volume is set to either maximum or
minimum volume.

Compatible iPod models

The compatible iPod models are as follows.
Update software of your iPod to the latest version Connecting optional
before using it with this unit.
components
iPod touch (4th generation)
iPod touch (3rd generation)
You can enjoy the sound from an optional
iPod touch (2nd generation)
component, such as a portable digital music
iPod nano (6th generation)*
player, through the speakers of this unit. Be sure
iPod nano (5th generation)
to turn off the power of each component before
iPod nano (4th generation)
making any connections.
iPod nano (3rd generation)
1
Firmly connect the line output jack of a
iPod classic
portable digital music player (or other
iPhone 4S
iPhone 4
component) to the AUDIO IN jack on the
iPhone 3GS
back of the unit, using a suitable audio
iPhone 3G
connecting cable (not supplied).
iPad 2
2
Press  to turn on the unit.
iPad
* T he iPod nano (6th generation) cannot be 3
Turn the connected component on.
controlled by the remote when the command of
4
Press AUDIO IN to select the source.
"MENU, " ", " ", " and "ENTER" is pressed.
5
Play the connected component.

On copyrights

The sound from the connected component is
iPhone, iPod, iPod classic, iPod nano, and iPod
output from the speakers of this unit.
touch are trademarks of Apple Inc., registered in
the U.S. and other countries. iPad is a trademark
Notes
of Apple Inc.
 The audio connecting cable required depends
"Made for iPod, " "Made for iPhone, " and "Made
on the external equipment. Make sure the cable
for iPad" mean that an electronic accessory
is correct for the external equipment to be
has been designed to connect specifically to iPod,
connected.
iPhone, or iPad, respectively, and has been
 If the volume is low, adjust the volume level on
certified by the developer to meet Apple
the connected equipment first. If the volume is
performance standards. Apple is not responsible
still too low, adjust the volume level on the unit.
for the operation of this device or its compliance
with safety and regulatory standards. Please note
that the use of this accessory with iPod, iPhone,

About App

or iPad may affect wireless performance.
To set an iPod on the Docking
A dedicated dock app for iPod touch, iPhone, and
iPad available at Apple App Store.
Tray
Search for "D-Sappli" and download the free app
to find out more about the functions.
1
Press the Docking Tray on the front of

Features

the unit to open it.
 The Sound EQ function allows you to create
2
Set your iPod on the Dock connector.
your own equalizer settings. You can select
equalizer presets, or customize settings to your
taste.
This function is available only when the iPod
touch/iPhone/iPad is set on the Dock
connector.
Note
 If a pop-up message appears on the display of
the iPod touch/iPhone/iPad, see "About App. "

To close the Docking Tray

1
Remove the iPod from the Dock
 D-Sappli includes two timer functions: Music
connector.
Play Timer and Sleep Timer.
2
Press the Docking Tray on the front of
The Music Play Timer allows you to play/pause
the unit until it is locked. desired music at a desired time. The Sleep
Timer allows you to specify a time at which to

To play back

stop music playback. The Music Play Timer and
Sleep Timer work in combination with the
Press .
power supply of the unit.
The iPod begins to play back.
 D-Sappli also includes a clock display enlarge
You can operate the connected iPod via this unit
feature.
or the iPod itself.
Notes
Notes
 If the App to link with this unit is not
 Remove the case or cover from your iPod
downloaded to your iPod touch/iPhone/iPad, a
before setting it in the Docking Tray to ensure a
pop-up message prompting you to download
stable connection.
D-Sappli may appear repeatedly.
 When placing or removing the iPod, hold the
Deactivate the App's link function to stop the
iPod at the same angle as that of the connector
pop-up message.
on this unit, and do not twist or bend the iPod
 To deactivate the App's link function: Connect
as it may result in connector damage.
the AC adaptor, and then press / to turn on
 Do not carry the unit with an iPod set on the
the unit. Remove your iPod touch/iPhone/iPad
Docking Tray. Doing so may cause a
from the Dock connector, and then press and
malfunction.
hold VOLUME − and  simultaneously for
 When placing or removing the iPod, hold the
more than 2 seconds. (The indicator for iPod
Docking Tray securely.
flashes rapidly when deactivated.)
 Before disconnecting the iPod, pause playback.
 To re-activate the App's link function, repeat the
 If the battery of your iPod is extremely low,
above steps. The indicator for iPod will flash
charge it for a while before operation.
slowly.
 Sony cannot accept responsibility in the event
 When you remove the iPod touch/iPhone/iPad
that data recorded to an iPod is lost or damaged
from the docking tray, the Sound EQ function
when using an iPod connected to this unit.
setting will return to the default.
 For details of environmental conditions for
 When the sound volume is high, the Sound EQ
operating your iPod, check the website of Apple
function may not be effective.
Inc.
To adjust the volume
Press VOLUME +/− (VOL +/− on the remote
commander).

Additional Information

Specifications

AUDIO POWER SPECIFICATIONS

Troubleshooting

POWER OUTPUT AND TOTAL HARMONIC
DISTORTION:
With 8 ohm loads Satellite channels and with 4
General
ohm loads Subwoofer channel driven, from
100 Hz - 10,000 Hz; rated 10 watts per channel
The power does not turn on when the AC
minimum RMS power, with no more than 10%
adaptor is connected.
total harmonic distortion.
Make sure the AC adaptor is connected to the wall outlet

firmly. Section for iPod
There is no audio.
DC out: 5 V
Adjust VOLUME +/− (VOL +/− on the remote
 MAX: 2.1 A
commander).
General
Noise is heard.
Ensure that the unit is not in the vicinity of in-use Speaker

portable phones, etc.
Satellite: 4.8cm (1
Resetting the unit (default setting).
Subwoofer: 9.0cm (3
Press / to turn on the unit. Remove your iPod from the

Input
Dock connector, and then while holding down VOLUME
AUDIO IN jack (ø 3.5 mm stereo minijack)
−, hold down /. (Hold both buttons down for at least 5
seconds.) After resetting, the / indicator flashes for 2 Power output
seconds.
15 W + 15 W + 30 W (at no more than 10%
All indicators flash and no buttons can be
harmonic distortion)
operated.
Power requirements
Remove the AC adaptor and connect it again.

DC IN 19.5 V
iPod Dimensions
Approx. 401 mm × 176 mm × 160 mm (w/h/d)
There is no audio.
(15 / inches × 7 inches × 6
7
8
Make sure the iPod is connected firmly.

Mass
Update your iPod to use the latest software beforehand.

Approx. 3.15 kg (6 lb 15 oz)
Make sure the iPod is compatible.

Supplied accessories
Make sure the function for iPod is selected.

Remote commander (1)
Operation is not performed.
AC adaptor (1)
Make sure the iPod is connected firmly.

AC power cord (1)*
The iPod does not charge.
Reference Guide (this document) (1)
Make sure the iPod is connected firmly.

Startup Guide (1)
Make sure the AC adaptor is connected firmly.

CR2025 lithium battery (1) (Pre-installed in the
AUDIO IN
remote commander for trial use)
There is no audio.
* T he supplied AC power cord may differ to the
Make sure the audio connecting cable is connected

illustration depending on the country.
firmly.
Make sure the AUDIO IN function is selected.

Design and specifications are subject to change
The sound is low.
without notice.
Confirm the volume of the connected external

component.
Remote commander
The remote commander does not function.
Replace the battery in the remote commander with a new

one if it is weak.
Make sure that you are pointing the remote commander

at the remote sensor on the unit.
Remove any obstacles in the path of the remote

commander and the unit.
Make sure the remote sensor is not exposed to strong

light such as direct sunlight or fluorescent lamp light.
Move closer to the unit when using the remote

commander.
If the problem persists, consult your nearest Sony dealer.
/ inches) dia. 8Ω
15
16
/ inches) dia. 4Ω
5
8
/ inches)
3
8
