Personal Audio Docking System
©2011 Sony Corporation
Printed in China
RDP-M5iP
WARNING
To reduce the risk of fire or electric
shock, do not expose this apparatus to
rain or moisture.
To reduce the risk of fire, do not cover the
ventilation of the apparatus with newspapers,
tablecloths, curtains, etc. And do not place lighted
candles on the apparatus.
To reduce the risk of fire or electric shock, do not
expose this apparatus to dripping or splashing,
and do not place objects filled with liquids, such
as vases, on the apparatus.
Do not install the appliance in a confined space,
such as a bookcase or built-in cabinet.
Do not expose the batteries (battery pack or
batteries installed) to excessive heat such as
sunshine, fire or the like for a long time.
As the main plug of AC adaptor is used to
disconnect the AC adaptor from the mains,
connect it to an easily accessible AC outlet.
Should you notice an abnormality in it,
disconnect it from the AC outlet immediately.
The unit is not disconnected from the AC power
source (mains) as long as it is connected to the
wall outlet, even if the unit itself has been turned
off.
The nameplate and important information
concerning safety are located on the bottom
exterior of the main unit and on the surface of the
AC adaptor.
CAUTION
Danger of explosion if battery is incorrectly
replaced. Replace only with the same type.
Notice for customers: the following
information is only applicable to equipment
sold in countries applying EU directives
The manufacturer of this product is Sony
Corporation, 1-7-1 Konan, Minato-ku, Tokyo,
108-0075 Japan. The Authorized Representative
for EMC and product safety is Sony Deutschland
GmbH, Hedelfinger Strasse 61, 70327 Stuttgart,
Germany. For any service or guarantee matters,
please refer to the addresses given in separate
service or guarantee documents.
4-266-548-33(1)
Reference Guide
Precautions
 To disconnect the AC adaptor, pull it out by the
plug, not the cord.
 Since a strong magnet is used for the speaker,
keep credit cards using magnetic coding or
spring-wound watches, CRT-based TVs, or
projectors, etc., away from the unit to prevent
possible damage from the magnet.
 Do not leave the unit in a location near a heat
source such as a radiator or airduct, or in a
place subject to direct sunlight, excessive dust,
mechanical vibration, or shock.
 Allow adequate air circulation to prevent
internal heat build-up. Do not place the unit on
a surface (a rug, a blanket, etc.) or near
materials (a curtain) which might block the
ventilation holes.
 Should any solid object or liquid fall into the
unit, unplug the unit and have it checked by
qualified personnel before operating it any
further.
 Do not handle the unit with wet hands.
 Do not place the unit anywhere near water.
NOTES ON LITHIUM BATTERY
 Wipe the battery with a dry cloth to assure a
good contact.
 Be sure to observe the correct polarity when
installing the battery.
 Do not hold the battery with metallic tweezers,
otherwise a short-circuit may occur.
Note
 In this Reference Guide, "iPod" is used as a
general reference to functions on an iPod or
iPhone, unless otherwise specified by the text
or illustrations.
Disposal of Old Electrical &
Electronic Equipment (Applicable
in the European Union and other
European countries with separate
collection systems)
This symbol on the product or on its packaging
indicates that this product shall not be treated as
household waste. Instead it shall be handed over
to the applicable collection point for the recycling
of electrical and electronic equipment. By
ensuring this product is disposed of correctly, you
will help prevent potential negative consequences
for the environment and human health, which
could otherwise be caused by inappropriate waste
handling of this product. The recycling of
materials will help to conserve natural resources.
For more detailed information about recycling of
this product, please contact your local Civic
Office, your household waste disposal service or
the shop where you purchased the product.
Applicable accessory: Remote Commander.
Disposal of waste batteries
(applicable in the European
Union and other European
countries with separate
collection systems)
This symbol on the battery or on the packaging
indicates that the battery provided with this
product shall not be treated as household waste.
On certain batteries this symbol might be used in
combination with a chemical symbol. The
chemical symbols for mercury (Hg) or lead (Pb)
are added if the battery contains more than
0.0005% mercury or 0.004% lead.
GB
By ensuring these batteries are disposed of
correctly, you will help prevent potentially
negative consequences for the environment and
human health which could otherwise be caused
by inappropriate waste handling of the battery.
The recycling of the materials will help to
conserve natural resources.
In case of products that for safety, performance or
data integrity reasons require a permanent
connection with an incorporated battery, this
battery should be replaced by qualified service
staff only.
To ensure that the battery will be treated properly,
hand over the product at end-of-life to the
applicable collection point for the recycling of
electrical and electronic equipment.
For all other batteries, please view the section on
how to remove the battery from the product
safely. Hand the battery over to the applicable
collection point for the recycling of waste
batteries.
For more detailed information about recycling of
this product or battery, please contact your local
Civic Office, your household waste disposal
service or the shop where you purchased the
product.
If you have any questions or problems concerning
your unit, please consult your nearest Sony dealer.
Others
Troubleshooting
General
The power is not on.
Make sure the AC adaptor is connected to the wall outlet
firmly.
Make sure the batteries are inserted correctly.
Replace all the batteries with new ones if they are weak.
There is no audio.
Adjust VOLUME +/− (VOL +/− on the remote
commander).
Noise is heard.
Ensure that the unit is not in the vicinity of in-use
portable phones, etc.
The two different music sources will be
mixed together during playback.
Disconnect the iPod or external component.
The OPR/BATT indicator flashes.
OPR/BATT
The
indicator flashes when the remote
commander's command is received, or when the batteries
are weak. In this case it does not mean any error or fault.
iPod
There is no audio.
Make sure the iPod is connected firmly.
Operation is not performed.
Make sure the iPod is connected firmly.
The iPod does not charge.
Make sure the iPod is connected firmly.
Make sure the AC adaptor is connected firmly.
Audio-in
There is no audio.
Make sure the audio connecting cable is connected
firmly.
The sound is low.
Confirm the volume of the connected external
component.
Remote commander
The remote commander does not function.
Replace the battery in the remote commander with a new
one if it is weak.
Make sure that you are pointing the remote commander
at the remote sensor on the unit.
Remove any obstacles in the path of the remote
commander and the unit.
Make sure the remote sensor is not exposed to strong
light such as direct sunlight or fluorescent lamp light.
Move closer to the unit when using the remote
commander.
If the problem persists, consult your nearest Sony dealer.

Specifications

Section for iPod
DC out: 5 V
MAX: 1 A
General
Speaker
Approx. 5.0 cm dia. 6 Ω
Input
AUDIO IN jack (ø 3.5 mm stereo minijack)
Power output
2 W + 2 W (at 10% harmonic distortion)
Power requirements
DC IN 6V
Dimensions
Approx. 226 mm × 165 mm × 164 mm (w/h/d)
Mass
Approx. 1.1 kg (not including batteries)
Supplied accessories
Remote commander (1)
AC adaptor (1)
Universal Dock Adapter  for iPhone (1)
Universal Dock Adapter  for iPhone 3GS/
iPhone 3G (1)
Universal Dock Adapter  for iPhone 4S/
iPhone 4 (1)
Design and specifications are subject to change
without notice.
