- Page 1 Cover Interposer Tray CI5040 Machine Code: D3GA Field Service Manual Ver 1.0 Latest Release: March, 2019 Initial Release: March, 2019 Copyright (c) 2019 Ricoh Co.,Ltd.
- Page 3 Symbols, Abbreviations This manual uses several symbols and abbreviations. The meaning of those symbols and abbreviations are as follows: Symbol What it means Clip ring Screw Connector Clamp E-ring Flat Flexible Cable Timing Belt Short Edge Feed Long Edge Feed Black Cyan Magenta...
-
Page 5: Table Of Contents
Table of Contents Overview and Configuration ....................... 2 Basic Specifications ..........................2 Electrical Component Layout ......................... 3 Driving Layout ............................5 Rollers ..............................7 Paper Paths ............................8 Replacement and Adjustment ......................9 Pick-Up Roller, Feed Roller, and Reverse Roller ................... 9 Horizontal Registration Adjustment for Tray .................. -
Page 6: Overview And Configuration
1.Overview and Configuration 1. Overview and Configuration Basic Specifications Items Specification Notes Peripherals on which this cover Booklet Finisher SR5120 interposer tray can be installed Finisher SR5110 Multi-Folding Unit FD5020 Type Inserter Separation Method FRR separation and air assist Transport Method Roller Transport Paper Size A5/HLT - 13"... -
Page 7: Electrical Component Layout
1.Overview and Configuration Electrical Component Layout Name Name 1st Paper Near End Sensor 2 2nd Paper End Sensor 1st Lift Motor 2nd Paper Width Sensor 1st Paper Near End Sensor 1 2nd Paper Length Sensor 1st Lower Limit Sensor 2nd Paper Near End Sensor 2 1st Paper Length Sensor 2nd Lift Motor 1st Paper End Sensor... - Page 8 1.Overview and Configuration Name Name 1st Blower Fan 2nd Blower Fan 1st Pickup Solenoid 2nd Pickup Solenoid 1st Upper Limit Sensor 2nd Upper Limit Sensor 1st Transport Sensor 2nd Transport Sensor 1st Paper Feed Sensor 2nd Paper Feed Sensor...
-
Page 9: Driving Layout
1.Overview and Configuration Driving Layout Name Name 1st Paper Feed Motor 2nd Paper Feed Motor 1st Transport Motor 2nd Transport Motor 1st Vertical Transport Motor 2nd Vertical Transport Motor... - Page 10 1.Overview and Configuration Name Name 3rd Vertical Transport Motor Entrance Sensor Horizontal Transport Motor Front Door Open Switch Vertical Transport Cover Switch 3rd Vertical Transport Sensor 1st Vertical Transport Sensor URB (Double Feed Detect) (option) Double Feed Detect Sensor (Transmitting) (option) Exit Sensor Double Feed Detect Sensor (Receiving) (option) Main Controller Board...
-
Page 11: Rollers
1.Overview and Configuration Rollers Name Pick up roller Feed roller Reverse roller... -
Page 12: Paper Paths
1.Overview and Configuration Paper Paths Transport Path 1st Paper Feed Transport Path 2nd Paper Feed Transport Path Relay Transport Path... -
Page 13: Replacement And Adjustment
2.Replacement and Adjustment 2. Replacement and Adjustment Pick-Up Roller, Feed Roller, and Reverse Roller • Both the 1st paper feed [A] and 2nd paper feed [B] rollers can be replaced with the same procedure. Remove the paper feed cover [A]. Remove the pick-up roller [A] and feed roller [B]. - Page 14 2.Replacement and Adjustment Remove the face plate [A]. • When attaching the face plate, make sure that the face plate is set as shown below in the picture [A]. • Fix the face plate with a screw while holding it by hand and make it level. Do not make the face plate inclined as shown below in the picture [A].
- Page 15 2.Replacement and Adjustment Remove the reverse roller [A].
-
Page 16: Horizontal Registration Adjustment For Tray
2.Replacement and Adjustment Horizontal Registration Adjustment for Tray With the screws [A] at the rear of the tray, adjust the registration. To shift the tray to the front side, turn the screws clockwise. To shift the tray to the rear side, turn the screws counterclockwise. The tray moves 2 mm at a time.
